EasiWise Standard Quick Start User Manual

Welcome to EasiWise, the Intelligent Hot Water Solution for electric and solar geysers. The easy to
read LCD display will give you all the information you need to know of the status of your hot water at
any time, the hours your geyser has been on and KWh use.
EasiWise allows you to set up to four daily timers for weekdays and weekends. There is also a holiday
mode setting for when you go away or want your geyser off for a long period and a BOOST button,
which when pressed overrides the timer settings to instantly start the geyser.
Your installer will most likely have set the system to standard settings; however, you can change
these easily at any time to suit your lifestyle. The default settings are set to turn the geyser OFF during peak load
times, which are 5am to 9am AND 6pm to 9pm. The temperature of the geyser water is set to heat up to 55° (called
the geyser set point).
How to set up your personal preferences - Setting the unit is done by using a series of "long presses" (4 seconds) and
short, quick presses of the four display buttons, either singly or in a combination. This guide will take you through the
available settings and we have also provided you with a small card quick set guide which you can place behind
your unit for handy and easy reference to the combinations once you have the hang of it! If you wish, you may
download a full manual from the website, http://www.easiwise.co.za, support menu, select downloads and the
manual PDF.
• R
D
ESET TO EFAULT
To reset the unit to the default settings, which will clear timer settings: Long
press both the "SELECT" and "BOOST" simultaneously. The LCD backlight will
turn off and then on. The unit will take up to 10 seconds to reset.
R KW
•
ESET THE H AND HOURS COUNTER
To reset the KW/H and hours counter long press at the same time both the
"SELECT" and the "UP" switches. This will reset counters to zero.
C
•
HECK THE CURRENT TEMPERATURES OF YOUR
To get to the "temperature" menu, a sequential number of short presses of
the "UP" Button will take you to the various settings:
1 Press LCD shows "GEYSER" Temperature
2 Presses LCD shows "SOLAR PANEL" Temperature
3 Presses LCD shows "GEYSER SETPOINT" Temperature. The current temperature set with the timer ON/OFF profile will
be displayed. If this is during an OFF period, this will show 00
4 Presses LCD shows "GEYSER DELTA" Temperature. This refers to the temperature difference between the geyser
set point and the temperature at which the geyser will switch back on to begin reheating and off once
set point has been reached.
5 Presses LCD shows the "BOOST" Temperature which has been set, that is the temperature the geyser will heat the
water to when the "boost" is engaged.
6 Presses LCD shows "SOLAR SETPOINT" Temperature which is the geyser temperature at which the differential solar
pump will stop working.
7 Presses LCD shows "SOLAR DELTA" Temperature which is the temperature that the solar collector needs to be
above the geyser temperature setting for the pump to operate.
solar installs
To reset any of the above settings, one short press on the "UP" button.
• S
S D
ET YSTEM ATE AND
The date and time will have been pre-set at the factory and the system does have a backup battery which means
these setting will be held in memory even in the event of a power off but should you do need to reset date and time,
follow the procedure below.
Long press the "SELECT" button - the light at the top left of the display will
➢
go off, when it comes back on, release the "SELECT" button
1. Day will flash, press "UP" or "DOWN" until the correct day appears, then
press "ENTER"
2. Next the Month will flash, press "UP" or "DOWN" until the correct month appears, press "ENTER"
3. Next the Year will flash, press "UP" or "DOWN" until the correct year appears, press "ENTER"
4. Next the Hour will flash, press "UP" or "DOWN" until the correct hour appears, press "ENTER"
5. Next the Minutes will flash, press "UP" or "DOWN" until the correct minute appears, press "ENTER"
The date and time is now set. NOTE: It is extremely important that the date and time is set accurately!
EWT-UserQuickGuide-01
G
EYSER AND
NOTE: only applicable to PUMPED/SPLIT solar installs
T
IME
Quick Start User Guide
S P I
OLAR ANEL F INSTALLED
if applicable, solar installs only
NOTE: Applicable only to PUMPED/SPLIT
Page 1
