- Page 1 2163 0108 All MODELS PARTS & OPERATORS MANUAL Shelbourne Reynolds Engineering Ltd Stanton Bury St Edmunds Suffolk IP31 2AR England Telephone: 01359 250415 Stores Direct : 01359 251231 Fax: 01359 250464 Stores Direct: 01359 252031 Issue 12 26/11/2018 www.shelbourne.com...
- Page 2 The machine, sub assemblies and optional kit numbers are listed in the front pages of your Operators manual, part no. 2163 0108. If you do not have these numbers please contact Shelbourne Reynolds Parts Department direct on (telephone) 01359 251231.
- Page 4 Check & tighten if necessary both main pivot securing nuts (Shear Bucket only). When the inspection is complete, THIS FORM MUST BE COPIED & RETURNED TO:- Shelbourne Ensure that the combined weight of the Shear Grab/Bucket and the heaviest silage...
- Page 6 EC Declaration of conformity for machinery (Machinery Directive 2006/42/EC, Annex II., sub. A) Manufacturer : Shelbourne Reynolds Engineering Ltd. Address : Shepherds Grove Industrial estate, Stanton, Bury St Edmunds, Suffolk. England. IP31 2AR Name and address of the person (established in the European Community/EEA)
- Page 7 Where as every effort has been made to ensure that the Shear Bucket conforms to Shelbourne Parmiters policy of quality, the machine cannot be expected to withstand abuse caused by...
- Page 8 Shelbourne by an authorised Shelbourne dealer within 15 days of the date of the repair on a Shelbourne Warranty Claim Form. The submission of a claim is not a guarantee of payment. Any decision reached by Shelbourne is final.
- Page 9 6 months. Shelbourne will at its option, either repair or replace the defective part free of charge. Original Purchaser shall be responsible for labour and all freight charges to and from the place where the warranty work is performed.
- Page 10 SPECIFICATIONS Volume Capacity Model Unladen Width Depth Height Weight (kg) Pressure SB150 530 kg 1,15 m 0,80 m 0,80 m 0,74 m3 455 kg 136 bar SB 200 570 kg 1,35 m 0,80 m 0,80m 0,86 m3 529 kg 136 bar SB 250 670 kg 1,68 m...
-
Page 16: Table Of Contents
List Of Kit Numbers For Shear Bucket Shear Bucket Assembly Parts List Shear Bucket Hydraulics Parts List 259901 01 SB300 Shear Bucket 259901 02 SB250 Shear Bucket 259004 03 SB300 Hydraulic Sub Assembly 259004 04 SB250 Hydraulic Sub Assembly 259004 05 SB150 &... - Page 18 Serrated Blade W/A (SB 300) 2160 2021 Centre Blade 2160 2062 Side Blade 3309 0192 Pivot Pin 40 dia. (SB 150 & SB 200) 3310 0322 Pivot Pin 40 dia. (SB 250 & SB 300) 2014 6118 Hex Bolt, M12 x 90 3309 0129 Headless Pin, 30 dia.
- Page 20 259004 03 – 07, further through this manual) Item No. Part No. Description Quantity 2131 1038 Ram (SB 150 & SB 200) 2131 1066 Ram (SB 250) CHECK RAM OUTSIDE DIAMETER 115mm (4.5” 2131 1086 Ram (SB250) CHECK RAM OUTSIDE DIAMETER 127mm (5”)
- Page 23 Shelbourne Reynolds Engineering Limited ASSY NUMBER: 259901 01 ASSY DESCRIPTION: SB300 SHEAR BUCKET ITEM PART NO DESCRIPTION ITEM PART NO DESCRIPTION 259007 01 SB300 BASE UNIT SUB ASSY 259004 03 SB300 HYDRAULIC SUB ASSY 259006 01 SB300 COMPLETING KIT...
- Page 24 Shelbourne Reynolds Engineering Limited...
- Page 25 Shelbourne Reynolds Engineering Limited ASSY NUMBER: 259901 02 ASSY DESCRIPTION: SB250 SHEAR BUCKET ITEM PART NO DESCRIPTION ITEM PART NO DESCRIPTION 259007 02 SB250 BASE UNIT SUB ASSY 259004 04 SG250 & SB250 HYDRAULIC SUB AS 259006 02 SB250 COMPLETING KIT...
- Page 26 Shelbourne Reynolds Engineering Limited...
- Page 27 Shelbourne Reynolds Engineering Limited ASSY NUMBER: 259004 03 ASSY DESCRIPTION: SB300 HYDRAULIC SUB ASSY ITEM PART NO DESCRIPTION ITEM PART NO DESCRIPTION 21311086 RAM (PAINTED) 21312085 SEAL KIT FOR RAM HHCE15005 HYDRAULIC HOSE ASSEMBLY HHCE11705 HYDRAULIC HOSE ASSEMBLY 21307501 SEALING WASHER...
- Page 28 Shelbourne Reynolds Engineering Limited...
- Page 29 Shelbourne Reynolds Engineering Limited ASSY NUMBER: 259004 04 ASSY DESCRIPTION: SG250 & SB250 HYDRAULIC SUB ASSY ITEM PART NO DESCRIPTION ITEM PART NO DESCRIPTION 21311086 HYDRAULIC RAM 21312085 SEAL KIT FOR RAM HHCE13605 HYDRAULIC HOSE ASSEMBLY HHCE10005 HYDRAULIC HOSE ASSEMBLY...
- Page 30 Shelbourne Reynolds Engineering Limited...
- Page 31 Shelbourne Reynolds Engineering Limited ASSY NUMBER: 259004 05 ASSY DESCRIPTION: SG100 & SG200 HYDRAULIC SUB AS ITEM PART NO DESCRIPTION ITEM PART NO DESCRIPTION 21311038 HYDRAULIC RAM 21312020 SEAL KIT FOR RAM HHCE11705 HYDRAULIC HOSE ASSEMBLY HHCE07505 HYDRAULIC HOSE ASSEMBLY...
- Page 32 Shelbourne Reynolds Engineering Limited...
- Page 33 Shelbourne Reynolds Engineering Limited ASSY NUMBER: 259004 07 ASSY DESCRIPTION: SB150 & SB200 HYDRAULIC SUB ASSY ITEM PART NO DESCRIPTION ITEM PART NO DESCRIPTION 21311066 HYDRAULIC RAM 21312067 SEAL KIT FOR RAM NOTE HHCE11705 HYDRAULIC HOSE ASSEMBLY THIS SUB IS FOR SERIAL NO’S...
- Page 34 Shelbourne Reynolds Engineering Limited...
-
Page 35: Sb300 Completing Kit
Shelbourne Reynolds Engineering Limited ASSY NUMBER: 259006 01 ASSY DESCRIPTION: SB300 COMPLETING KIT ITEM PART NO DESCRIPTION ITEM PART NO DESCRIPTION 250000 01 LOGO LARGE 21616339 LABEL “SHEAR BUCKET” 21616360 LABEL "SHARP BLADE" 21616343 LABEL "SAFETY MANUAL" 21616337 LABEL "GREASE SYMBOL"... - Page 36 Shelbourne Reynolds Engineering Limited...
-
Page 37: Sb250 Completing Kit
Shelbourne Reynolds Engineering Limited ASSY NUMBER: 259006 02 ASSY DESCRIPTION: SB250 COMPLETING KIT ITEM PART NO DESCRIPTION ITEM PART NO DESCRIPTION 250000 01 LOGO LARGE 21616339 LABEL “SHEAR BUCKET” 21616360 LABEL "SHARP BLADE" 21616343 LABEL "SAFETY MANUAL" 21616337 LABEL "GREASE SYMBOL"... - Page 38 Shelbourne Reynolds Engineering Limited...
- Page 39 Shelbourne Reynolds Engineering Limited ASSY NUMBER: 259007 01 ASSY DESCRIPTION: SB300 BASE UNIT SUB ASSY ITEM PART NO DESCRIPTION ITEM PART NO DESCRIPTION 250312 01 SB300 SUPPORT FRAME W/ASSY 250313 01 SB300 CUTTING FRAME W/ASSY...
- Page 40 Shelbourne Reynolds Engineering Limited...
- Page 41 Shelbourne Reynolds Engineering Limited ASSY NUMBER: 259007 02 ASSY DESCRIPTION: SB250 BASE UNIT SUB ASSY ITEM PART NO DESCRIPTION ITEM PART NO DESCRIPTION 250326 01 SB250 SUPPORT FRAME W/ASSY 250322 01 SB250 CUTTING FRAME W/ASSY...
- Page 42 Shelbourne Reynolds Engineering Limited...
-
Page 43: Load Holding Valve Kit
Shelbourne Reynolds Engineering Limited ASSY NUMBER: KIT-25020 ASSY DESCRIPTION: LOAD HOLDING VALVE KIT ITEM PART NO DESCRIPTION ITEM PART NO DESCRIPTION HMA-0057 ADAPTOR MALE/MALE HVB-27015 DUAL PILOT OPERATED CHECK HHCE02805 VALVE HYDRAULIC HOSE ASSEMBLY WSH-1010 DOWTY WASHER FIT-0251 BLANKING PLUG... - Page 44 Shelbourne Reynolds Engineering Limited...
-
Page 45: Pressure Relief Valve Kit
Shelbourne Reynolds Engineering Limited ASSY NUMBER: KIT-25021 ASSY DESCRIPTION: PRESSURE RELIEF VALVE KIT ITEM PART NO DESCRIPTION ITEM PART NO DESCRIPTION HMA-0057 ADAPTOR MALE/MALE HVB-27020 DUAL CROSS LINE RELIEF VALVE HHAE02805 HYDRAULIC HOSE ASSEMBLY WSH-1010 DOWTY WASHER FIT-0251 BLANKING PLUG... - Page 46 Shelbourne Reynolds Engineering Limited...
-
Page 47: Jcb Q Fit Bracket Kit
Shelbourne Reynolds Engineering Limited ASSY NUMBER: KIT-25050 ASSY DESCRIPTION: JCB Q FIT BRACKET KIT ITEM PART NO DESCRIPTION ITEM PART NO DESCRIPTION 250508 01 JCB Q FIT BRACKET LH W/A 250508 02 JCB Q FIT BRACKET RH W/A 260143 01... - Page 48 Shelbourne Reynolds Engineering Limited...
-
Page 49: Manitou Bracket Kit
Shelbourne Reynolds Engineering Limited ASSY NUMBER: KIT-25051 ASSY DESCRIPTION: MANITOU BRACKET KIT ITEM PART NO DESCRIPTION ITEM PART NO DESCRIPTION 250501 01 MANITOU BRACKET W/A 260143 01 CLAMP PLATE BLT-2334 HEX.HEAD BOLT NUT-0271 NYLOC NUT WSH-0024 PLAIN WASHER... - Page 50 Shelbourne Reynolds Engineering Limited...
-
Page 51: Merlo Bracket Kit
Shelbourne Reynolds Engineering Limited ASSY NUMBER: KIT-25052 ASSY DESCRIPTION: MERLO BRACKET KIT ITEM PART NO DESCRIPTION ITEM PART NO DESCRIPTION 250502 01 MERLO BRACKET W/A 260143 01 CLAMP PLATE BLT-2334 HEX.HEAD BOLT NUT-0271 NYLOC NUT WSH-0024 PLAIN WASHER... - Page 52 Shelbourne Reynolds Engineering Limited...
-
Page 53: Matbro Bracket Kit
Shelbourne Reynolds Engineering Limited ASSY NUMBER: KIT-25053 ASSY DESCRIPTION: MATBRO BRACKET KIT ITEM PART NO DESCRIPTION ITEM PART NO DESCRIPTION 250506 01 LH MATBRO BRKT W/A 250506 02 RH MATBRO BRKT W/A 260143 01 CLAMP PLATE BLT-2334 HEX.HEAD BOLT NUT-0271... - Page 54 Shelbourne Reynolds Engineering Limited...
-
Page 55: Claas Bracket Kit
Shelbourne Reynolds Engineering Limited ASSY NUMBER: KIT-25054 ASSY DESCRIPTION: CLAAS BRACKET KIT ITEM PART NO DESCRIPTION ITEM PART NO DESCRIPTION 250504 01 CLAAS BRACKET W/A 260143 01 CLAMP PLATE BLT-2334 HEX.HEAD BOLT NUT-0271 NYLOC NUT WSH-0024 PLAIN WASHER... - Page 56 Shelbourne Reynolds Engineering Limited...
-
Page 57: Euro Bracket Kit
Shelbourne Reynolds Engineering Limited ASSY NUMBER: KIT-25055 ASSY DESCRIPTION: EURO BRACKET KIT ITEM PART NO DESCRIPTION ITEM PART NO DESCRIPTION 250510 01 LH EURO BRACKET W/A 250510 01 RH EURO BRACKET W/A 260143 01 CLAMP PLATE BLT-2334 HEX.HEAD BOLT NUT-0271... - Page 58 Shelbourne Reynolds Engineering Limited...
-
Page 59: Loader Bracket Plate Kit
Shelbourne Reynolds Engineering Limited ASSY NUMBER: KIT-25056 ASSY DESCRIPTION: LOADER BRACKET PLATE KIT – WELD OWN BRKT ITEM PART NO DESCRIPTION ITEM PART NO DESCRIPTION 250303 01 BRACKET PLATE (UNPAINTED) 260143 01 CLAMP PLATE BLT-2334 HEX.HEAD BOLT NUT-0271 NYLOC NUT... - Page 60 Shelbourne Reynolds Engineering Limited...
-
Page 61: Jcb Tool Carrier Bracket Kit
Shelbourne Reynolds Engineering Limited ASSY NUMBER: KIT-25061 ASSY DESCRIPTION: JCB TOOL CARRIER BRACKET KIT ITEM PART NO DESCRIPTION ITEM PART NO DESCRIPTION 250514 01 LH JCB TOOL CARRIER BRKT W/A 250514 02 RH JCB TOOL CARRIER BRKT W/A 260143 01... - Page 62 Shelbourne Reynolds Engineering Limited...
