Propur INLINE CONNECT FS10 Installation & Use Instructions

Pr pur
STANDARD INLINE SYSTEM
Designed to fit under sink or in basement. Do NOT install where the temperature could fall below
freezing as damage could result. No power required. For use with cold potable water only.
READ COMPLETELY BEFORE INSTALLING OR USE.
!
CAUTION: Before beginning the installation, turn OFF the cold water supply under your sink or your house supply at the meter.
Open the cold water faucet to release any water pressure.
WARNING: Do not use water source that is microbiologically unsafe or of unknown quality without adequate disinfection before or
!
after the system. For specific health requirements, consult your healthcare professional.
Check and comply with any installation state or local codes that may apply.
SHOULD YOU HAVE QUESTIONS ABOUT INSTALLING YOUR PROPUR SYSTEM, PLEASE CONTACT TECHNICAL SUPPORT
AT 800-544-3533 X27 OR EMAIL CUSTOMERSERVICE@PROPURUSA.COM FOR ASSISTANCE.
TM
WATER
PURIFICATION
SYSTEMS
Filter housing, 2-3/4"port x 3/8" brass (lead free)
compression fittings installed in housing,
mounting bracket attached to housing, ProMax™
FULL SPECTRUM™ filter cartridge installed in
housing, 30" x 3/8" compression fitting flex hose and
filter cartridge replacement wrench

Tools and Hardware Required

Adjustable wrench, screwdriver, Teflon tape,
4 - screws for mounting bracket to cabinet, 1/2" drill bit
when using optional faucet
•Overall height from bottom of housing to top of
bracket is 18.5". Diameter is 7.25"
•Type of installation: Under counter – Inline or with
optional separate faucet - for cold water use ONLY
•Space Requirement: System requires minimum of 2"
below sump(housing) for filter replacement
•Maximum Working Pressure: 860 Kpa (125 psig)
NOTE: Should your water pressure exceed 80 psig,
install a pressure reducing valve before installing the
system
•Minimum Working Pressure: 137 Kpa (20 psig)
•Minimum Working Temperature: 5° C (41° F)
•Maximum Working Temperature: 38° C (100° F)
•Recommended Flow Rate: 0.2 – 1.0 gpm
•Contaminant Reduction: Refer to Lab Reports
•Filter Life Expectancy: Up to 1 year with inline
installation and up to 2 years with separate faucet
installation
•Replacement filter: PM-FS10-RF
Under Counter Water Filter System with
ProMax™ FULL SPECTRUM™ Filter Technology
Installation & Use Instructions

Package Contents

System Specifications

INLINE CONNECT FS10
3
1. Face Plate
2. Large Rubber Washer
3. Small Rubber Washer
4. Plastic Washer
5. Star washer
6. Steel nut
7. Quick connect fitting
8. 3/8" tubing
T-Valve included. Shown in OPEN position
OPTIONAL SEPARATE
FAUCET KIT
1
2
4
5
6
7
8
1
