Shinybow USA ANI-0108HC User Manual

HDMI 8 Ports Splitter Amplifier by Cat5 x1
Dear Customer
Thank you for purchasing this product. For optimum performance and safety, please read these instructions
carefully before connecting, operating or adjusting this product. Please keep this manual for future reference.
1.0 INTRODUCTION
This HDMI Splitter is an HDMI splitter with eight RJ45 outputs. It distributes the input of the HDMI signal into the
eight identical outputs simultaneously. Eight HDMI Extender Receivers by Cat5 x1 receive the distributed signal
from the splitter and transmit to displays individually.
Each receiver works with the splitter as a full functional module. Only buy the most inexpensive UTP cable with
cross stand inside the full functional module to extend the HDTV display up to 165 feet for 1080p.
This HDMI Splitter offers solutions for HDTV retail and show site, HDTV, STB, DVD and Projector factory, noise,
space and security concerns, data center control, information distribution, conference room presentation, school
and corporate training environments
1.1 FEATURES
This HDMI Splitter has many features that enable it to perform in a superior manner. Among those features you
will find:
 Easy to Use: Install in seconds.
 One pair as a full functional module.
 One piece of CAT-5e/6 cable can substitute HDMI cable to achieve long distance transmission.

Follow the standard of IEEE-568B.
 Transmission distance can be up to 165 feet for 1080p using UTP cable with cross stand inside.
 Supports HDMI1.2a.

Supports highest video resolution 1080p.
 Supports 165MHz/1.65Gbps per channel (4.95Gbps all channel) bandwidth.
 Supports 8bit per channel (24bit all channel) deep color.

Supports uncompressed audio such as LPCM.
ANI-0108HC
USERS GUIDE
1 of 4
HDMI 8 Ports Splitter Amplifier by Cat5 x1
