Part number
DEALER
USER MANUAL
PDA
for Maintenance
date of commissioning:
position / system reference:
service:
.......................................................................................
.......................................................................................
.......................................................................................
Advertisement
Table of Contents
Related Manuals for Argal PDA 75
Summary of Contents for Argal PDA 75
- Page 1 USER MANUAL Part number DEALER for Maintenance date of commissioning: ..................position / system reference: ..................service: ..................
-
Page 2: Table Of Contents
TABLE OF CONTENTS 2 TABLE OF CONTENTS 3 IDENTIFICATION CODE 5 LEGEND 6 GENERAL NOTES 6 OPERATING PRINCIPLE 7 INSTALLATION AND USE INSTRUCTIONS 7 INSTALLATION 9 START UP 9 STOP 7 STORAGE INSTRUCTIONS 7 TRANSPORT 9 USE 10 MAINTENANCE 10 DISASSEMBLY 10 INSPECTION 11 SAFETY RULES 12 INSTALLATION AND START-UP PERSONNEL... -
Page 3: Identification Code
IDENTIFICATION CODE materials connection range model chambers diaphragm o-ring tipe ATEX □ □ □ X □ H □ N □ G GFR-PP keyflex (NBR) filetto BSP (3/4”) ® □ □ □ X □ M □ V CF+PVDF santoprene (FKM) (1”) ®... - Page 4 MODEL 75 MODEL 100-150 MODEL 200...
-
Page 5: Legend
LEGEND Disassembling steps sequence note ref. pos. Description Q.ty 10 11 910.1 connections dampener casing ● 102.1 Air side casing ● 135.1 Wet side diaphragm ● 102.2 Wet side casing ● 412.1 O-ring ● 412.2 O-ring ● 135.2 Air side diaphragm ●... -
Page 6: General Notes
GENERAL NOTES The”PDA” dampeners are accessories for the AODD pump and have used for dampen the variations in flow and pres- sure in the AODD pump discharge. The dampener performances (flow rate, head, and minimum pressure) are decided in the ordering phase and indicated on the nameplate Make sure that the physical-chemical characteristics of the fluid have been correctly evaluated The maximum temperature referred to water in continuous operation depends on the version of the materials (indicated... -
Page 7: Installation And Use Instructions
INSTALLATION AND USE INSTRUCTIONS TRANSPORT • cover the hydraulic connections • lift the hydraulic plastic parts without mechanical stress • for transport on irregular roads, cushion the bumps with suitable support plane • blows and impacts may damage parts that are important for the machine operation and safety STORAGE INSTRUCTIONS •... - Page 8 hydraulic connections pneumatic connections • do not install the dampener (built with thermoplastic material) near heat sources • do not install the dampener in places with risk of fall of solids or fluids • do not install the dampener close to fixed workplaces or visited areas •...
-
Page 9: Start Up
• ascertain that the fluid treated does not contain or cannot contain large solids or solids for a dangerous shape • ensure that the intake or delivery ports are not obstructed • also ascertain that the connection piping is strong enough and cannot be deformed by the dampener’s weight or by the intake. -
Page 10: Maintenance
MAINTENANCE • all the operation must be carried out by qualified personnel • do not carryout maintenance and/or repairs with the air circuit under pressure; only the air supply must be used to stop the dampener by closing the three-way valve to discharge any residual pressure from the dampener’s pneu- matic circuit •... -
Page 11: Safety Rules
SAFETY RULES WARNING! CHEMICAL RISK. Pumps are intended for operation with different types of fluids and chemical solutions. Follow the specific internal instructions for decontamination during the inspection or maintenance operations. WARNING: the diaphragms (into contact with the product and external) are components extremely subject to wear. Their duration is strongly affected by the conditions of employments and by chemical and physical stresses. -
Page 12: Installation And Start-Up Personnel
WARNING: the use of dampeners for flammable liquids is forbidden if they are made of non-conductive materials that charge statically (plastic materials) and without suitable grounding danger of explosion caused by static charges WARNING: Aggressive, toxic or dangerous liquids may cause serious injuries or damage health, therefore it is forbidden to return a dampener containing such products to the manufacturer or to a service center. -
Page 13: Personnel Responsible For Repairs
trical and chemical features of the plant being fed by the pump and of the pump itself): • verification of environmental conditions • verification of the condition of the liquid being pumped • inspections of the control/stop devices of the pump •... - Page 14 TECHNICAL DATA DIMENSIONS 75 - 100 air inlet ØA ØA air inlet air inlet...
- Page 15 model air inlet discharge ØA 3/4” 3/8” 1/4” 1” 1/2” 1/4” 1 1/2” 3/8” 1/4” 2” 1/2” 1/2” (WR-FC-AL) 200 (SS) 2” 1/2” 1/2”...
- Page 16 REV.1 - 02/13 The INSTRUCTION MANUAL must be delivered to the pump-user , who © Copyright 2012 - ARGAL srl takes diligent note of it, fills in data for Maintenance Department (page Draw and text total or partial duplication is 1), keeps the file for subsequent reference.Possible modifications do not...
