Summary of Contents for SCAN domestic EMV 610
- Page 1 EMV 610 EMV 910 Brugermanual User manual Scandomestic A/S · Thrigesvej 2 · DK-8600 Silkeborg T + 45 7242 5571 · F + 45 8622 5571 · scandomestic.dk...
- Page 2 Dansk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 3 English .
- Page 3 Læs denne brugsanvisning omhyggeligt! med evt. transportskade. Evt. transportskader skal anmeldes omgående og senest 24 efter, at varen er leveret. I modsat fald Kære kunde! vil kundens krav kunne afvises. • Læs denne brugsanvisning før du tager produktet i brug Erhvervskøb: første gang.
-
Page 4: Installation
Advarsel Installation • Lad ikke børn bruge emhætten. 1 Emhætten skal placeres i en afstand • Din emhætte er kun til husholdningsbrug, og ikke velegnet på 65-75cm fra koge- til grillbarer eller anden kommerciel brug. pladen for at opnå • Alt installationsarbejde skal udføres af en autoriseret elek- den bedste effekt. -
Page 5: Rengøring Og Vedligeholdelse
5 Når både “LIGHT”-knappen og “SPEED”-knappen ikke virker; bruges “TIMER”-knappen til tidsindstilling. Tryk på “TIMER”-knappen i 2 til 3 sekunder; “12:00” bliver vist på LCD-skærmen og “12” blinker; hvilket viser timer. Tryk en gang på “SPEED”-knappen og tallet øges med 01. Fortsætte med at trykke på... -
Page 6: Udskiftning Af Pæren
Produt data Produktdataark til emhætte til husholdningsbrug i overensstem- melse med til forordning (EU). Nr. 65/2014 og 66/2014 Symbol Værdi Enhed Model identifikation EMV 610 / EMV 910 Årligt energiforbrug AEChætte 91,4 kWh/a Tidsforøgelsesfaktor Flydende dynamisk effektivitet FDEhætte 17,2 Energieffektivitet indeks EEIhætte... -
Page 7: Function And Feature
Warning Installation • Keep your children from using the cooker hood. 1 The cooker hood should be placed at a • Your cooker hood is for domestic use only, not suitable for distance of 65 - 75cm barbecue, roast shop and other commercial use. from the cooking • Any installation work must be carried out by a qualified surface for thebest electrician or competent person. effect. See Pic.1. 2 Install the hook on a • The cooker hood and its filter mesh should be cleaned regu- larly in order to keep in good working order. suitable place once the installation height • Before cleaning, always ensure that you have switched your is fixed, and keep cooker hood off. it in line. The fixed position of the inside • Clean the cooker hood according to the instruction manual chimney bracket is and keep the cooker hood from the danger of burning. the highest position • No fire for drying your cooker hood. of inside chimney. See Pic.2. • If there is any fault with your cooker hood, please call the service department appointed by agent for servicing. -
Page 8: Cleaning And Maintenance
5. When both “LIGHT” button and “SPEED” button don’t work; the “TIMER” button is used for time-setting. Press “TIMER” button for 2 to 3 seconds; “12:00” will be shown on LCD and “12” flashes; which represents hour. Press “SPEED” but- ton once the number adds by 01. Continue pressing “SPEED” button; it will display from “13;14… until 23”. When LCD shows “23”; it doesn’t work by pressing “SPEED” button. Press “LIGHT” button once; the number reduces by 01. When LCD shows “00”; it doesn’t work by pressing “LIGHT” button. After setting hour; you can start setting minute by pressing “TIMER” button again. “00” on LCD flashes; which repre- sents minutes. Press “SPEED” button once the number adds by 01. Continue pressing “SPEED” button; it will display from “01;02… until 59”. When LCD shows 59; it doesn’t work by pressing “SPEED” button. Press “LIGHT” button once; the number reduces by 01. When LCD shows 00; it doesn’t work by pressing “LIGHT” button. After setting hour and minute; press “TIMER” to confirm. When “SPEED” button doesn’t work; “TIMER” button is used for delay timer function. Delay timer function allows you to set the hoods automatically power off according to the delay timer you set from 1 minute to 60 minutes. Press “TIMER” button once; it enters for delay timer setting and LCD shows “05:00”. Press “SPEED” button once the number adds by Continue pressing “SPEED” button; it will display from “05:00; 06:00; 07:00… until 60:00” Press “LIGHT” button once; the number reduces by 01. After setting delay timer you want; press “TIMER” button to confirm. If you set delay Use your cooker hood: timer as 05:00; the LCD display will show from “05:00; LCD Electronic button 04:59… until 00:01 00:00”. When LCD shows “00:00”; the hood will automatically power off and LCD display will only show 24-hour system with blue backlight. -
Page 9: Product Data Sheet
• Put the carbon filter into the cooker hood, the instruction see Product data sheet Pic.9 Accordingly to regulation (EU). No. 65/2014 and 66/2014 Symbol Value Unit Model identification EMV 610 / EMV 910 Annual Energy Consumption AEChood 91,4 kWh/a Time increase factor Fluid Dynamic Efficiency FDEhood 17,2 Energy Efficiency Index EEIhood 79,6 Measured airflow rate at the QBEP 373,2 m3/h best efficiency Measured air pressure at best PBEP efficiency point Maximum airflow Qmax 637,0 m3/h Measured electric power input WBEP 180,0 W at best efficiency point Nominal power of the lighting To change the lamp:...
