Summary of Contents for Big Sprinkler 4200HR
- Page 1 Model 4200HR Instruction Manual for Operation & Maintenance BigSprinkler.com | 15250 Sunshine Rd. Yukon, OK. 73099 | 1-855-805-7901...
- Page 2 Introduction Thank you for purchasing a Lay-Flat Hose Quick Reel Model 4200HR. Please read this manual carefully before operation in order to become familiar with all components and their function. Safety is the main priority and failure to follow these instructions may cause serious injury. Neither Lay-Flat Hose Quick Reel Model 4200HR nor BigSprinkler.com are to be responsible for machine failure or...
- Page 3 Machine Controls & Components Drum Mount - Side Plate Open Slot for (0255K) Bungee Strap Brake Band (0271K) Brake Drum (0270K) Brake Tension-Adjustment Knob (0272K) Nylon Spacer (0273K) Crank Handle (0265K) HDPE Hose Dividers (0267K) Frame - Side Plate (Crank Side) (0257K) Inner Hub - Spacer Frame - Side Plate (Non Crank Side)
- Page 4 Deployment of Hose To prevent injury, the operator should first check that the hand crank has been “REMOVED” from the reel before deploying hose. Care should be taken to ensure that the hose does not kink or get entangled while being taken off the reel. 1) ALWAYS REMOVE CRANK HANDLE • Depress the end of the crank in order for the handle to be slip off of the crank shaft.
- Page 5 Retrieval of Hose The water and pressure in the hose should be relieved and allowed to completely drain prior to rewinding. Care must be taken so that the hose does not kink or twist during winding. 1) Re-Attach crank handle to drum shaft as shown. •...
- Page 6 Bearings: Grease 1 time per year Options Quick Reel and ATV Trailer Model 4200HR-TM The Flatbed ATV cart has a sturdy 34 in. x 48 in. expanded metal deck with 16 gauge steel tube frame supporting up to a 1000 lb.
- Page 7 BigSprinkler.com Distributor, Dealer/Seller, Purchaser Agreement Limited Warranty and Remedy BigSprinkler.com is committed to providing our customers with quality irrigation products. If at any timea product falls short of your expectations due to defective workmanship or materials, the following will apply. Warranty BigSprinkler.com warrants to the original purchaser only of the products described in the face hereof as of the date of the original invoice, that the product is merchantable and free from defects in material and workmanship.
