Summary of Contents for VELJAN VT67EB
- Page 1 Service Information SS4 - 00131 VT67EB Double vane pump...
- Page 3 Part No. Item Description VT67EB pos. Housing (UNC) V034-70263 Housing (Metric) C-034-03069 Mounting flange (UNC) V034-70265 Mounting flange (Metric) C-034-03070 End cap (UNC) (P2=3/4") V034-66533 End cap (Metric) (P2=3/4") H-034-66765 Mounting Screw V306-40111 Mounting Screw V306-40216 Retaining ring V356-30315 Shaft seal (S1-0.7 bar)
- Page 4 Part No. Item Description VT67EB pos. Rotor-insert ass'y VS24-30019 9m Screw V310-10340 Lockwasher internal tooth V348-10010 Dowel pin V323-82014 Sq. section seal V671-10259 Cartridge assembly B02 C.W (P2) VS24-51513 Cartridge assembly B02 C.C.W (P2) VS24-51514 Cartridge assembly B03 C.W (P2) VS24-51515 Cartridge assembly B03 C.C.W (P2)
- Page 5 Part No. Item Description VT67EB pos. Seal kit (S1 - 0,7 bar) VS24-10242 9f,9h Seal kit (S4 - 7 bar) VS24-10242-4 9j,9q Seal kit (S5 - 7 bar) VS24-10242-5 10f,10h 10j,10q Port plate - rear ass'y C.W. (P1) VS24-10214 Port plate - rear ass'y C.C.W. (P1)
