- Page 1 ArraySight Manual 1.7 en...
- Page 2 General information ArraySight Manual Version: 1.7 en, 04/2019, D2735.EN .01 Copyright © 2019 by d&b audiotechnik GmbH; all rights reserved. Keep this document with the product or in a safe place so that it is available for future reference. We recommend you to regularly check the d&b website for the latest version of this document.
- Page 3 Do not suppress eye-closure reflex. it is in use. The d&b ArraySight sender unit is shipped with the following label ENSURE that the meter unit is to hand at all times so that the affixed to the top surface. Do not remove this label under any beam can be switched off immediately if necessary.
-
Page 4: Table Of Contents
8.1 EU declaration of conformity (CE symbol)......22 8.2 WEEE Declaration (Disposal)..........22 8.3 Licenses and Credits ..............23 Appendix................25 9.1 Z5710.xxx d&b ArraySight sets..........25 9.1.1 Z5710.001 Mounting instructions........25 9.1.2 Z5710.002 Mounting instructions........26 d&b ArraySight Manual 1.7 en... -
Page 5: D&B Arraysight
D2735.EN .01 ArraySight Manual 1.2 Intended use The d&b ArraySight laser inclinometer system is intended to vertically aim an entire array in its operating position. It provides precision angle measurement over a wide measuring range of ±90 degrees. The sender unit uses a 3-axis MEMS accelerometer for data acquisition. - Page 6 ± 5 % . The corresponding values are displayed on the «Home» screen of the meter unit or, when integrated into the d&b Remote network, the values can be read out within R1. d&b ArraySight Manual 1.7 en...
-
Page 7: Technical Specifications
Meter unit W x H x D: 85 x 45 x 160 mm / 405 g (0.9 lb) Sender unit W x H x D: 48 x 44 x 120 mm / 295 g (0.65 lb) d&b ArraySight Manual 1.7 en... -
Page 8: Startup
Startup 3.1 Installing the batteries NOTICE! To power the ArraySight inclinometer system, professional high power Alkaline batteries (6 x AA - 1.5 VDC) must be used. 1. To insert and remove the batteries, undo the two M3 screws on the end of the meter unit and slide out the battery holder. -
Page 9: Switching On/Switching Off
Apart from that, the buttons have different functions within the various submenus. The current function is always indicated above each button (e.g. «BACK», SET, «CANCEL», «INC»...) The display is backlit for viewing in all light conditions. d&b ArraySight Manual 1.7 en... -
Page 10: The Menu Structure
(default), 2 min. and 5 min. Temp. unit Defines the temperature units. °C/°F Version Displays the currently installed firmware version of both the meter and the sender units. If the sender unit is not connected, «Offline» will be displayed instead. d&b ArraySight Manual 1.7 en... -
Page 11: Sender Settings
However, for maintenance reasons it might be necessary to re-calibrate the sender unit’s accelerometer. For this purpose, selecting «Calibrate» starts the calibration procedure for the connected sender unit as described in Þ Chapter 7.3 "Calibrating the accelerometer" on page 20. d&b ArraySight Manual 1.7 en... -
Page 12: Editing Ip And Remote Id Settings
↳ The meter unit switches back to the «IP settings» menu. If no changes have been made, the meter unit switches directly back to the «IP settings» menu as soon as you scroll to the last digit. d&b ArraySight Manual 1.7 en... -
Page 13: Resetting The Angle (Zeroing) And Laser Alignment
ArraySight Manual 1.7 en... -
Page 14: Aligning The Laser
The required accuracy is ± 5 mm (± 0.2" hor./vert.) which leads to a maximum deviation of 10 cm/100 m (3.94"/328 ft). 3. Adjust the screws until the laser dot aligns precisely. 4. Switch the laser off and disconnect the sender unit. d&b ArraySight Manual 1.7 en... - Page 15 5. Once alignment is complete, place a drop of thread-locking fluid on each of the screw heads to prevent loosening. d&b ArraySight Manual 1.7 en...
-
Page 16: Using The System
Using the system 5.1 Measuring the angle Once the array has been hoisted to its working height, ArraySight uses intelligent interpolating algorithms to determine the resting point of the array, while it is still moving after motor adjustment. This is important because it means you can make accurate measurements without waiting for the system to come to a complete rest after adjustment. -
Page 17: Using The Laser
5.5 Application example To take an example: ArrayCalc indicates a frame angle of –3.6° from vertical. 1. Using ArraySight to measure this angle, you raise the first array to its operating height and then check the meter unit screen. 2. The figures displayed settle as the meter compensates for the swing of the array. -
Page 18: Oca Integration (Ethernet)
This allows multiple sender units to be read out within R1. By factory default, the sender unit comes with the following ethernet and remote settings: Auto Þ DHCP+LL (Link Local) IP mode: IP address: 192.168.0.111 Subnet: 255.255.255.0 Gateway: 192.168.0.1 Remote ID: 0.01 d&b ArraySight Manual 1.7 en... -
Page 19: Maintenance And Care
This prevents the sender unit from damage due to: ▪ Ingression of moisture or liquids (e.g. water from rain) through the etherCON connector socket, ▪ corrosion of the connector socket's spring contacts. d&b ArraySight Manual 1.7 en... -
Page 20: Calibrating The Accelerometer
ENSURE the laser is switched off throughout this procedure. The ArraySight sender units are calibrated in the factory using precision calibration jigs. If this process is attempted without a level surface and a true 90° angle, then calibration information could be incorrect. - Page 21 This data is stored in the non-volatile EEPROM in the sender unit. Correctly calibrated, the sender unit will provide accurate angle measurements in all orientations. d&b ArraySight Manual 1.7 en...
-
Page 22: Manufacturer's Declarations
8.1 EU declaration of conformity (CE symbol) This declaration applies to: d&b Z5710 ArraySight set Including: ▪ Z5711 ArraySight sender unit ▪ Z5712 ArraySight meter unit Provided they correspond to the original technical version and have not been subject to any later design or electro mechanical modifications. -
Page 23: Licenses And Credits
ARISING IN ANY WAY OUT OF THE USE OF THIS 3. The name of the author may not be used SOFTWARE, EVEN IF ADVISED OF THE to endorse or promote products POSSIBILITY OF SUCH DAMAGE. derived from this software without specific prior written permission. d&b ArraySight Manual 1.7 en... - Page 24 OF THE POSSIBILITY OF SUCH DAMAGE. * Neither the name of the author nor the names of contributors may be used to endorse or promote products derived from this software without specific prior written permission. d&b ArraySight Manual 1.7 en...
-
Page 25: Appendix
(Mounting instructions): ▪ Z5710.001: d&b ArraySight set J-Series ▪ Z5710.002: d&b ArraySight set V-Series Apart from any other items, each ArraySight set includes the mechanical components (flying frame adapter) for two flying frames. Please verify the shipment for completeness and proper condition of the items. -
Page 26: Z5710.002 Mounting Instructions
Assembly 1. First attach the ArraySight sender unit [1] to the flying frame adapter [2]. 2. Fix the sender unit with the two panhead screws (M4 x 12) [3]. 3. As the sender unit assembly is mounted from the bottom of the J flying frame, turn frame by 180°. - Page 27 Assembly 1. First attach the ArraySight sender unit [1] to the flying frame adapter [2]. 2. Fix the sender unit using two panhead screws (M4 x 12) [3]. 3. Position the V flying frame onto an appropriate and flat surface.
- Page 28 www.dbaudio.com...
