Instruction Manual
Alfa Laval BladeClean
Covering:
Standard Machines
First published: 2015-08
ESE032025-EN1
2015-08
Original manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BladeClean and is the answer not in the manual?

Questions and answers

Summary of Contents for Alfa Laval BladeClean

  • Page 1 Instruction Manual Alfa Laval BladeClean Covering: Standard Machines First published: 2015-08 ESE032025-EN1 2015-08 Original manual...
  • Page 3: Table Of Contents

    6. Technical Data ………............................6.1. Technical Data………............................6.2. Performance Data………..........................6.3. Dimensions ………............................7. Parts List and Service Kits ………........................7.1. BladeClean View ………..........................7.2. Assembly Drawings - 1 & 2 ………........................7.3. Parts List ………............................7.4. Service Kit ………........................... …………28...
  • Page 4: Ec Declaration Of Conformity

    EC Declarat ion of Conf ormity The designated company Alfa Laval Tank Equipment Inc. Company name 604 Jeffers Circle – Exton, PA – 19341, United States Address +1 610 408 9940 Phone no. hereby declare that Tank Cleaning Machine Alfa Laval Gamajet BladeClean...
  • Page 5: Safety

    1. Safety Unsafe practices and other important information are emphasized in this manual. Warnings are emphasized by means of special signs. Always read the manual before using the tank cleaning machine! Important information WARNING Indicates that special procedures must be followed to avoid serious personal injury. CAUTION Indicates that special procedures must be followed to avoid damage to the tank cleaning machine.
  • Page 6: Safety Precautions

    Always handle lye and acid with great care. When an Alfa Laval BladeClean is operating, there should be covers over every tank opening. These covers should be sealed well enough to withstand the full force of the jet striking the cover plate.
  • Page 7: Introduction

    Alfa Laval BladeClean. A positive metal stop is provided to prevent the plunger from being pushed down when the load of material within the tank would be acting on the top of the Alfa Laval BladeClean. A complete description of the...
  • Page 8: Installation

    3. Installation Unpacking/delivery Step 1 CAUTION Check the delivery for: Alfa Laval cannot be held responsible for incorrect unpacking. 1. Complete Cleaning Machine 2. Delivery note Step 2 Remove any packing material. Step 3 Inspect the tank cleaning machine for visible transport damage.
  • Page 9: Installation

    Location inside Tank The Alfa Laval BladeClean should be placed below the agitator blades. The cone of impact has a tangential force at the point of impact on the blade. This force cleans the area surrounding the exact impact cone. Depending on the length of the blade, more than one Alfa Laval BladeClean may need to be installed for sufficient cleaning.
  • Page 10 Alfa Laval BladeClean should be adjusted. Note: When in operation, the plunger of Alfa Laval BladeClean rises above the tank bottom to a height of about 5-7 mm. This might interfere with low level scrapers in certain tanks. Consult the nearest Alfa Laval office for more information.
  • Page 11 Any tank-cleaning machine can develop a static electric charge while in operation. If the tank being cleaned contains a combustible liquid or vapor having a risk of ignition or explosion, it is imperative to have the Alfa Laval Tank Cleaning Product...
  • Page 12: Recycling Information

    - At end of use, the equipment must be recycled according to relevant, local regulations. Beside the equipment itself, any hazardous residues from the process liquid must be considered and dealt with in a proper manner. When in doubt, or in the absence of local regulations, please contact your local Alfa Laval sales company.
  • Page 13: Operation

    Initial Startup Every Alfa Laval BladeClean that ships is accompanied by a Birth Certificate. This document indicates how the Alfa Laval BladeClean performed in our testing tank before it shipped based on the operating conditions supplied to Alfa Laval Tank...
  • Page 14: Troubleshooting

    WATER LEAKING OUT OF THE BOTTOM CAP The Alfa Laval BladeClean has a seal (9) on the main body (7) to prevent any water from going down into the bottom cap (10). If water is seen leaking from the weep holes on the bottom cap, check this seal for any damage. If damaged, replace the seal with a new one.
  • Page 15: Recommended Cleaning

    4. Operation The Tank Cleaning machine is designed for cleaning in place (CIP). CIP = Cleaning In Place. Study the instructions carefully and pay special attention to the warnings! NaOH = Caustic Soda, HNO3 = Nitric Acid. Recommended Cleaning Step 1 Caustic danger! Always handle lye and acid with great care.
  • Page 16: Maintenance

    Always read the technical data thoroughly. (See chapter 6 technical Data). Step 2 Recommended spare parts: Order service kits from the service kits list (See 7.4 Minor Service Kit & 7.5 Major Service Kit) Ordering spare parts: Contact your local Alfa Laval Sales Company.
  • Page 17: General Dismantling Set Up

    STORAGE The Alfa Laval BladeClean should be washed out with clean water after each use to remove any foreign material or soft substances left in the machine that may harden during storage. A clean water rinse through the Alfa Laval BladeClean will also wash out any residues of chemical cleaners or recirculated wash water that could adversely affect the seals and O-rings during prolonged contact in storage.
  • Page 18: General Dismantling

    Always keep Minor spare parts kit in stock. General Dismantling Step 1 Place a soft towel or an equivalent under the Alfa Laval BladeClean assembly to prevent it from getting scratched. Use a towel to hold the body extension tube. Step 2 Remove the Bottom Cap (10) using the 18”...
  • Page 19: Inspection And Service Of Components

    5. Maintenance Read the instructions carefully. The items refer to the parts list and service kits section. 5.4 Inspection and Service of Components Drawing 1 & 2 Inspect all machined features and windows to be sure they are clear and free of debris. Especially check for debris in slots of outlet screw (4).
  • Page 20: Reassembly

    Make sure the plunger moves smoothly in the body and then place the Bottom Cap (10). Put on the O-ring (6) on the outside of outlet screw (4). Now the Alfa Laval BladeClean can be attached to the tank adapter (15) with the clamp (16) provided.
  • Page 21: Technical Data

    It is important to observe the technical data during installation, operation and maintenance. Inform personnel about the technical data. Technical Data The Alfa Laval BladeClean Tank Cleaning Machine is a highly efficient machine at a range of pressures and flows. The instruction manual is part of the delivery. Read the instructions carefully. TECHNICAL DATA Lubricant .
  • Page 22: Performance Data

    6. Technical Data It is important to observe the technical data during installation, operation and maintenance. Inform personnel about the technical data. Performance Data Flow Rate Impact Throw Length Inlet Pressure Inlet Pressure Cone of Impact Distance from target Diameter (mm/ inch) (mm/ inch) 21/ 1...
  • Page 23: Dimensions

    6. Technical Data It is important to observe the technical data during installation, operation and maintenance. Inform personnel about the technical data. Dimensions Dimensions Dimensions...
  • Page 24: Parts List And Service Kits

    7. Parts List and Service Kits The drawing shows Alfa Laval BladeClean Tank Cleaning Machine BladeClean View...
  • Page 25: Assembly Drawings - 1

    7. Parts List and Service Kits The drawing shows Alfa Laval BladeClean Tank Cleaning Machine Assembly Drawings - 1 & 2 Drawing 1: Alfa Laval Bladeclean Assembly Exploded View...
  • Page 26 7. Parts List and Service Kits The drawing shows Alfa Laval BladeClean Tank Cleaning Machine Drawing 2: Alfa Laval BladeClean Assembly Exploded View...
  • Page 27: Parts List

    7. Parts List and Service Kits Parts List Pos. AL No. Gamajet No. Description 9614699602 AG-556 BODY EXTENSION TUBE 9614661603 401170 O- RING, EPDM, 2-022 9614661602 411060 O- RING, VITON, 2-022 9614661604 401180 O- RING, ZALAK, 2-022 TE52D561 TE52D561 OUTLET GASKET, OUTSIDE OUTLET, SCREW ON, 1”...
  • Page 28: Service Kit

    7. Parts List and Service Kits 7.4 Service Kit Article no: 9614699616 ALFA LAVAL GJ BLADECLEAN KIT - EPDM Pos. no. Part No. Gamajet Part No. Description 9614661603 401170 O-RING, EPDM, 2-022 pcs. 9614699606 AG-559 O-RING, EPDM, 2-118 pcs. 9614699607...
  • Page 29: Appendix A

    The instrumentation connection that fits this adapter is the Alfa Laval HTC connection, male part. For other information contact your local Alfa Laval office. Mount the O-ring gasket (5) that fits the BladeClean connections (or blind cap) O-ring groove.
