LogMaster-800

8-Channel Stand Alone Voice Logger

User's Manual

First Edition

（C）2018 Eletech Enterprise Co., Ltd

Table of Contents

Need help?

Do you have a question about the LogMaster-800 and is the answer not in the manual?

Questions and answers

Summary of Contents for Eletech LogMaster-800

Page 2: Table Of Contents
LogMaster-800 User’s Manual TABLE OF CONTENTS Introduction ........................2 Package Contents ......................3 Panel Descriptions ......................4 Typical Connection…………………………………………………………………….5 Touch Panel ........................6 Web Access ......................... 12 Telephone Access Flowchart ..................23 System Specifications ....................124...
Page 3: Introduction
It is capable of recording phone calls and storing them internally without the need for a host computer. The record data stored inside the LogMaster-800 can be searched and reviewed from a remote PC via the network, using just a web browser such as Internet Explorer, Chrome or Firefox. System configuration and management are also done in the same manner, requiring no proprietary software.
Page 4: Package Contents
LogMaster-800 User’s Manual 2. Package Contents QUANTITY ITEM DESCRIPTION LOGMASTER-800 RJ-11 Telephone Cord RJ-11 Y-splitter Connector RJ-45 Network Cable Power Adapter External Start (Manual Start) Cable Installation CD If any item is missing or broken upon opening of the package, please contact your dealer immediately.
Page 5: Panel Descriptions
3. Panel Descriptions Top Panel Touch Screen Logmaster-800 has a built-in LCD touch screen. Most operations, such as system setting, password changing, live monitoring, and record searching/playing can be done on the touch screen without needing a computer. Front Panel...
Page 6: Typical Connection
LogMaster-800 User’s Manual Rear Panel LAN: RJ-45 Ethernet jack for network connection. LINE1~LINE8: Each modular phone jack has connections for two analog phone lines or other analog audio sources. Use the included Y splitter to connect the lines. EXT. START: Connection for an optional external trigger button.
Page 7: Touch Panel
LogMaster-800 User’s Manual 3. Touch Panel A menu similar to the following will appear in about one minute after the system powers up. It offers functions such as system setting, live monitoring and record search/playback. The menu structure is several layers deep.
Page 8 LogMaster-800 User’s Manual Settings : Configure system settings. This menu is password protected and the default password is 999. Record: Set the record mode. Tap the target channel to cycle through Local Phone, VOX and Manual. Alarm: Set the Long Idle time and the Long Recording time.
Page 9 LogMaster-800 User’s Manual Network: Set IP address, Subnet Mask, Gateway and DNS server. Password: The default password for the Settings menu is 999. If a new password is set and later lost, use the reset button to restore the default password.
Page 10 LogMaster-800 User’s Manual Date & Time: Set system clock, NTP server IP and synchronization interval. Close: Quit and return to the Main menu.
Page 11 LogMaster-800 User’s Manual Monitor/Search : This menu is password protected and the default password is 123. Monitor: Tap on the target channel (which must be active - blue color) to monitor the call in real time. Only one channel can be monitored at one time.
Page 12 LogMaster-800 User’s Manual Password: The default password for the Monitor/Search menu is 123. . If a new password is set and later lost, use the reset button to restore the default password. Close: Quit and return to the Main menu...
Page 13: Web Access
LogMaster-800 User’s Manual 4. Web Access Device Login Open the web browser and go to the logger’s IP address (e.g. http://192.168.1.100). Enter the user name (default = admin) and the password (default = 123). Then click the Login button. A screen similar to the following will appear.
Page 14 LogMaster-800 User’s Manual Record Data Search: Click it to enter the Record Data Search window. Channel: Select the target channel or choose All to search all channels. Time Period: Select today, last 3/7/30 days or specify a time period. Click Search to start searching.
Page 15 LogMaster-800 User’s Manual Play Once: Play the target record one time then stop Repeat: Play the target record repeatedly Play All [Time Backward]: Play the entire list from the last file to the first file. Play All [Time Forward]: Play the entire list from the first file to the last file.
Page 16 LogMaster-800 User’s Manual Device Monitoring: Click it to enter the Device Monitoring window. The window shows storage, NTP synchronization and line status. System errors are listed in the error log.
Page 17 LogMaster-800 User’s Manual Channel Settings: Click it to enter the Channel Settings window. Each channel must be configured separately. Agent Name: Enter the name to be associated with this channel. Phone Number: Enter the phone/station number to be associated with this channel.
Page 18 LogMaster-800 User’s Manual Format: The file format of recordings. Currently only MP3 16kbps is available. VOX Level: This setting applies only when the VOX record mode is enabled. Enter a value from 0 – 9. If the VOX level is set too low, the system becomes too sensitive to line noise, resulting in bogus recordings. If the VOX level is set too high, the system is more likely to stop recording prematurely.
Page 19 LogMaster-800 User’s Manual Device Settings: Click it to enter the Device Settings window. Keep Records For (Days): This function is currently not implemented. Recycle When Less Than: Storage recycling starts when the free space drops below this threshold level. The...
Page 20 LogMaster-800 User’s Manual Device Name: Enter a unique name for your own reference. This name can be used to identify the unit in a system with multiple loggers. NTP Settings: NTP is used to synchronize the device time with a public time server in order to keep the device time accurate.
Page 21 LogMaster-800 User’s Manual Account Management: For changing the password. Click it to enter the Account Management window. Changing the password from default is highly recommended. If the new password should be lost, use the device’s hardware reset button to restore the default password.
Page 22 LogMaster-800 User’s Manual System Update: For firmware update. Click “Choose File” and select the target firmware (.bin) file on your local hard disk Enter Super User Password: 999 (this password can be changed via the logger) then click “Start Upgrade”. A window similar to the following will appear:...
Page 23 LogMaster-800 User’s Manual Select “English Language” for English version. Click “Device Reboot” to confirm the firmware upgrade. The upgrade will be done in about 1 minute.
Page 24: Telephone Access Flowchart
LogMaster-800 User’s Manual 5. Telephone Access Flowchart Welcome to the Logmaster system. Please enter the passcode (123) follow by the # key. The maximum number To search recordings, press 1. The passcode is invalid, of tries has been To check system time, press 2.
Page 25: System Specifications
LogMaster-800 User’s Manual 6. System Specifications i.MX 6Dual processors of the ARM®Cortex®-A9 core；1 GHz 4GB (1 GB DDR3-1066 SDRAM × 4) Sound File Format Ethernet 10/100/1000 Mbps；RJ-45×1 RS-232 SMDR Protocol Storage SD, SSD or hard disk; File System: FAT32 or NTFS Lines per Unit 8 (RJ-11×4)
