Stan's NoTubes BST Series Instruction Manual

1
Mount tire: Making sure to position the tire bead
in the center channel of the rim, mount one tire
bead beginning opposite the valve and finishing
at the valve. Once the first bead is mounted begin
mounting the second bead opposite the valve and
finish at the valve.
2
With a brush or sponge apply a generous amount
of soapy water to both beads of the tire to help it
slip onto the bead of the rim when inflating.
3
Rotate the valve to 12 o'clock and install a pump.
Inflate tire to 35psi to seat tire.
4
Add sealant: Once successful with inflation remove
the valve core to add Stan's sealant. Add 2–4 oz.
of sealant.
INSTRUCTION GUIDE : BST SERIES WHEELS

NEEDED:

Stan's NoTubes ZTR wheel set, 2 tires,
Stan's NoTubes Tire Sealant, core remover
tool, injector or 2 oz. bottle, floor pump or
compressor, soapy water, safety goggles.

WARNING:

Always wear safely goggles, Sealant can
stain clothes or furniture.

RECOMMENDED TIRE PRESSURE

5
Inflate to riding pressure; the chart above is a recommended
starting point. Always review the maximum pressure information
listed on both the rim and the tire and consider the lower of the two
numbers your maximum pressure. Do not inflate above the lower
of the two numbers.
6
YES
Bounce: hold the wheel vertically and gently bounce or "dribble"
it to disperse the sealant throughout the inside of the tire. Let it
drop from an inch or two, then rotate a few degrees and repeat.
Do this for several revolutions of the wheel.
NO
7
Lay tire on side and apply a thin sheen of soapy water around the
sidewall and the bead area. Look for suds occurring anywhere on
the tire or bead area. Suds bubbling out from the tire indicate
porous areas. Shake the sealant to those areas to seal them and
apply soap and water again. Check for suds forming on both sides
of the tire. Repeat until no suds remain. Install the cassette and
rotors according to the component manufacturer's recommendations.

IMPORTANT NOTE:

Never inflate any tire without a tube above
40psi unless it is specifically labeled for
tubeless use. Maximum pressure listed on
your rims may differ from maximum pressure
listed on your tires. Do not inflate above the
lower of the two numbers.
PSI / BAR
40 / 2.8
35 / 2.4
30 / 2.1
25 / 1.7
20 / 1.4
16 / 1.1
110 120 130 140 150 160 170 180 190 200 210 220
50 55 59 64 68 73
RIDER W EIGHT
LB
77 82 86 91 95 100 KG
