GoMax Electronics CAP-302MJ User Manual

Usb 3.0 3g-sdi capture device with audio in
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CAP-302MJ
USB 3.0 3G-SDI Capture Device with
Audio in
User Manual
rev: 180326
Made in Taiwan

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CAP-302MJ and is the answer not in the manual?

Questions and answers

Related Manuals for GoMax Electronics CAP-302MJ

Summary of Contents for GoMax Electronics CAP-302MJ

  • Page 1 CAP-302MJ USB 3.0 3G-SDI Capture Device with Audio in User Manual rev: 180326 Made in Taiwan...

  • Page 2: Table Of Contents

    However, like all electronic equipments, the CAP-302MJ should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.

  • Page 3: Introduction

    3G/HD/SD-SDI signals. It adopts USB 3.0 interface, which can realize high-speed transmission. Users can capture 3G/HD/SD-SDI signals by this capture device. Besides, CAP-302MJ can capture and display original uncompressed 3G/HD/SD-SDI with more realistic color rendition. CAP-302MJ also uses large volume image buffer technology which effectively avoids the video tearing.

  • Page 4: Specifications

    SPECIFICATIONS Model Name CAP-302MJ Technical Role of usage Video Capture Device SDI standards SD-SDI, HD-SDI & 3G-SDI Input Video bandwidth 2.970 Gbit/s, 2.970/1.001 Gbit/s Output Video bandwidth Up to 350MBps (USB 3.0) Video support Up to 1080p60 SDI Embedded Audio Audio Input 3.5mm Analog Stereo Audio...

  • Page 5: Panel Description

    PANEL DESCRIPTION Front/Rear Panel USB OUT: Connect to a USB host (PC, NB, MAC…) Line IN: Connect to analog stereo audio source Slide Switch: Select the audio source from SDI embedded audio or analog stereo audio [Left] Analog Stereo Audio [Right] SDI Embedded Audio SDI IN: Connect to a 3G/HD/SD-SDI source LED: Signal LED indicator...

  • Page 6: Connection Diagram

    CONNECTION DIAGRAM...

  • Page 7: Usb Pin Definition

    USB PIN DEFINITION VBUS SSRX- SSRX+ SSTX- SSRX+ SHELL SHELL Shield...

  • Page 8: Limited Warranty

    SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the CAP-302MJ features and specifications is subject to change without further notice.
