Albatross WTS Filtration System Operating Instructions
Water Drain
Set‐Up
Place the WTS under the washout booth .
The Pre‐Filter box is on the left tank. Line the
Pre‐Filter Box with screen mesh, this will serve as the first
stage of filtration, it also prolongs filter space and pump life.
When the mesh clogs, shake it out in a waste basket and
replace.
Make sure the filter caps are attached. Do not
Over tighten the caps.
Connect a hose to the Water Drain (by the pump)
Make sure the control box is switched off (to the left)
Plug the control box in
Fill the left tank with water
Turn on the control box. It will take a few minutes before the water fills the canisters and begins to
drain out of the system
The system will shut off when the water gets low.
The system is now ready for use.
Albatross USA
th
36‐41 36
St
Long Island City, NY 11106
Sales@albatross‐usa.com
Filters
1‐800‐233‐4468
1‐718‐392‐6272
(Fax) 718‐392‐2899
Advertisement
Table of Contents
Summary of Contents for Albatross WTS
- Page 1 Albatross WTS Filtration System Operating Instructions Filters Water Drain Set‐Up Place the WTS under the washout booth . The Pre‐Filter box is on the left tank. Line the Pre‐Filter Box with screen mesh, this will serve as the first stage of filtration, it also prolongs filter space and pump life. When the mesh clogs, shake it out in a waste basket and replace. Make sure the filter caps are attached. Do not Over tighten the caps. Connect a hose to the Water Drain (by the pump) Make sure the control box is switched off (to the left) Plug the control box in Fill the left tank with water Turn on the control box. It will take a few minutes before the water fills the canisters and begins to drain out of the system The system will shut off when the water gets low. The system is now ready for use. Albatross USA 1‐800‐233‐4468 36‐41 36 St 1‐718‐392‐6272 Long Island City, NY 11106 (Fax) 718‐392‐2899 Sales@albatross‐usa.com ...
- Page 2 Maintenance When a filter is full an alarm will sound and an indicator light on the control box will illuminate. On the back of the control box each green light is marked with the appropriate filter cartridge. The easiest way to change the filters is to pull the unit from under the booth and turn it on its side. Using a pipe wrench, open the cap and replace the filter. Re‐attach the cap. Make sure not to over tighten the cap. Replacement Filters Red #5025 Green #5026 Black #5028 Albatross USA 1‐800‐233‐4468 36‐41 36 St 1‐718‐392‐6272 Long Island City, NY 11106 (Fax) 718‐392‐2899 Sales@albatross‐usa.com ...
