SPEEDMATE KNOTMETER/LOG Operating Instructions

S
PEED
KNOTMETER/LOG
OPERATING INSTRUCTIONS
S
PEED
10413 Deerfoot Drive, Great Falls, VA 22066 USA
Toll Free (800) 760-0004
S M R
PEED ATE
KT
NM
KNOTMETER/LOG
S M R
PEED ATE
KT
NM
KNOTMETER/LOG
2
SEC
NOTE: If you hold the button too long, you will enter
function/units selection (see box to the right). Simply release
the button on the desired function or display units.

CHOOSING TIME, MAX OR AVERAGE:

Hold the button for 1/2 second (until lower right window
changes) then release to select time, max or average display.
Display mode can be changed at any time.
S M R
PEED ATE
KT
NM
KNOTMETER/LOG
1/2
SEC
S M R
PEED ATE
KT
NM
KNOTMETER/LOG
1/2
SEC
S M R
PEED ATE
KT
NM
KNOTMETER/LOG
1/2
SEC
R
M
ATE
T I
ECH NSTRUMENTS
ON/START/STOP:
Push and release the button to
turn the unit on.
Push and release AGAIN to start
unit.
Push and release again to stop
unit.
ZEROING:
Hold the button for 2 seconds then
release to zero display and reset
speed memory.
Push and release AGAIN to start
unit.
1)
Time:
Displays running time from
start or the last time the unit
was zeroed.
2)
"MX":
Displays the maximum speed
achieved since start or the
last time the unit was zeroed.
3)
"AV":
Displays the average speed
since start or the last time the
unit was zeroed.

CHOOSING FUNCTIONS AND DISPLAY UNITS:

Pressing and HOLDING the button for more than 3
seconds will cause the display to roll through the
following choices:
S M R
PEED ATE
KNOTMETER/LOG
4
SEC
HOLD
S M R
PEED ATE
KNOTMETER/LOG
HOLD
S M
R
PEED ATE
KNOTMETER/LOG
HOLD
S M R
PEED ATE
KT
NM
KNOTMETER/LOG
HOLD
S M R
PEED ATE
MPH
SM
KNOTMETER/LOG
HOLD
S M R
PEED ATE
KHM
NM
SM
KM
KNOTMETER/LOG
HOLD
S M R
PEED ATE
M/S
NM
SM
KM
KNOTMETER/LOG
HOLD
S M R
PEED ATE
KNOTMETER/LOG
HOLD
1
1)
Power Off:
Release the button to turn the
unit off. (Note: the unit will also
power down automatically
after 17 minutes of receiving no
button pushes or information
from the speed sensor.)
2)
6/3 Minute Countdown:
Release the button to engage
the 6-minute or 3-minute
Countdown Timers. See
"Countdown Timer", next page,
for more instructions.
3)
10/5 Minute Countdown:
Release the button to engage
the10-minute or 5-minute
countdown timers. See
"Countdown Timer", next page,
for more instructions.
4)
Knots Display:
Release the button to display
speed in knots ("KT") and
distance in nautical mile ("NM").
5)
MPH Display:
Release the button to display
speed in miles per hour
("MPH") and distance in statute
miles ("SM").
6)
KMH Display:
Release the button to display
speed in kilometers per hour
("KMH") and distance in
kilometers ("KM").
7)
M/S Display:
Release the button to display
speed in meters per second
("M/S") and distance in
kilometers ("KM").
8)
Calibration:
Release the button to enter
the calibration function. See
"Calibration", next page, for
more information.
