Table of Contents
Summary of Contents for Reka 15991
- Page 1 Boombox with Radio, Cassette, Bluetooth , & SD/MMC/USB Ports ® MODEL NUMBER: 15991 USER GUIDE After Sales Support UK/N.IRELAND HELPLINE N 01270 508538 REP.IRELAND HELPLINE N 1800 995 036 WEBSITE: www.quesh.co.uk EMAIL: enquiries@quesh.co.uk...
-
Page 2: Table Of Contents
Contents Welcome Section 14-15 • MP3 Mode 2-3. Information & Safety Instructions • Pairing The Bluetooth • Bluetooth Controls Contents & Features • Preparing A USB/AS/MMC • USB/SD/MMC Autoplay 5-6. Controls & Layout • USB/SD/MMC Controls Connecting Power EQ Controls •... -
Page 3: Welcome Section
Welcome Section Congratulations! You have made an excellent choice with the purchase of this quality REKA product. ® By doing so you now have the assurance and peace of mind which comes from purchasing a product that has been manufactured to the highest standards of performance and safety, supported by the high quality standards of Quesh Ltd. - Page 4 General information & Safety Instructions This product uses 4 x ‘D’ 1.5V sized batteries (not included). Do not dispose of batteries in your household waste. Please contact your local authority for details on safe disposal. • Never throw batteries into a fire or expose to excessive heat sources. •...
- Page 5 General information & Safety Instructions Please read the following safety information before use. C A U T I O N RISK OF ELECTRIC SHOCK DO NOT OPEN • To avoid risk of electric shock do not attempt to open this appliance. •...
-
Page 6: Contents & Features
Contents & Features Contents 1 x Boombox 1 x 240V/13A, 1.5m Mains Lead Features • Bluetooth V5 • FM Band (87MHz-108MHz) • AM Band (530KHz - 1600KHz) • SW Band (8.0MHz - 16.0MHz) • USB Port • SD/MMC Card Port •... - Page 7 Layout Digital Controls Bass Dial SD/MMC Play/ Tuning Band Port LED Next Pause Prev. Dial Aerial Selector Function USB Port Selector Treble Bass Volume Pause Stop/ Fast Rewind Play Record Dial Dial Dial Eject Forward Cassette Controls Frequency Cassette Microphone Scale Cradle Speaker...
- Page 8 Layout Power Handle Aerial Input Battery Power On/Off Headphones Port After Sales Support UK/N.IRELAND HELPLINE N 01270 508538 REP.IRELAND HELPLINE N 1800 995 036 WEBSITE: www.quesh.co.uk EMAIL: enquiries@quesh.co.uk...
-
Page 9: Connecting Power
Connecting Power Mains Lead This boombox uses a 13A, 2 pin mains power lead (supplied). Plug the mains lead into a suitable mains socket and connect the lead to the power input on the back of the boombox. Batteries This boombox uses 4 x 1.5V ‘D’ cell type batteries (not supplied). Do not keep batteries in the boombox for long term storage. -
Page 10: On/Off
On/Off Turning The Boombox On/Off Once the boombox has power either supplied by the mains or batteries, the boombox can be turned on or off via the power switch located on the back of the boombox. Please Note: There is a small draw on batteries is they are left in. It is recommended you removed the batteries for long term storage. -
Page 11: Radio Mode
Radio Mode Using The Radio The radio is able to receive FM, AM and SW band radio signals. The ‘BAND’ selector switch will allow you to switch between the following: SW - 8.0MHz - 16.0MHz (Short Wave) AM - 530KHz - 1600KHz (Amplitude Modulation) FM - 87MHz - 108MHz (Frequency Modulation) Tuning The Radio Fully extend the telescopic aerial carefully and make sure the... -
Page 12: Tape Mode
Tape Mode Using A Cassette To use a cassette move the ‘FUNCTION’ switch to ‘TAPE’. Press the ‘STOP/EJ.’ button on the cassette controls to open the cassette cradle and insert the cassette facing downwards exposing the cassette ribbon to the top and that your chosen side letter is facing outwards. -
Page 13: Cassette Tape Deck Controls
Tape Mode Cassette Tape Deck Controls PAUSE Pause the cassette tape while playing or recording. STOP/EJ. Stops the current action / Eject the cassette tape. F.F. Fast Forwards the inserted cassette tape. REW. Rewinds the inserted cassette tape. PLAY Plays the inserted cassette tape. Records on the inserted cassette tape. -
Page 14: Recording From The Radio
Tape Mode Recording From The Radio Once the cassette tape is ready and inserted you will need to setup the boombox. Make sure the function switch is set to ‘RADIO’ and fully extend the telescopic aerial. Tune the radio into the station you want to record and make sure the signal is as clear as you can get it. -
Page 15: Recording From A Bluetooth Source
Tape Mode Recording From A Bluetooth Source Once the cassette tape is ready and inserted you will need to setup the boombox. Make sure the function switch is set to ‘MP3 ’. In this mode you will be able to record from a bluetooth connected device like a smart phone or tablet. - Page 16 LED light flashing blue and red. Turn on the bluetooth of the device that you want to pair with boombox and search for ‘REKA AUDIO’. Select ‘REKA AUDIO’ from the available device list and the bluetooth will automatically finish the pairing procedure.
- Page 17 Preparing A USB/SD/MMC The boombox will play MP3 and WAV audio formats. These files must be DRM (Digital Rights Management) free. Transfer the tracks to either a USB drive or an SD card that is no bigger than 32GB that has been formatted to the FAT32 file system. This can be done through a PC or laptop.
- Page 18 EQ Controls Using The Equalizer This boombox has a separate treble and bass control feature. Turn either dial clockwise or anti clockwise to increase or decrease the audio bias of the treble and bass. The arrows on the each dial will indicate the current level in use. After Sales Support UK/N.IRELAND HELPLINE N 01270 508538...
- Page 19 Problem Cause Solution Bluetooth dropping out after Full device cache. Manually clear the device’s cache & restart the device. a few minutes. Low Power. Replace the batteries Stuttering/delay music. Too many processes running Close unused apps. on device. Corrupt bluetooth profile. Unpair &...
- Page 20 Specification Boombox with Radio, Cassette, Bluetooth, SD/MMC/USB Ports General Chipset/Solution: BEKEN Approx Weight: 1.6Kg Approx Dimentions: 355mm x 110mm x 140mm Mains Adaptor: 240V/13A Bluetooth Bluetooth Ver: Frequency Range: 2.4GHz Bluetooth Protocol: A2DP Bluetooth Range: Battery Battery Type: 4 x ‘D’ 1.5V (not supplied) Talk/Play Time: Up to 8 hours Speaker...
- Page 21 Intentionally Left Blank...
- Page 22 Warranty Certificate Warranty This product is warranted to be free from defects in workmanship and parts for a period of 36 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour.
- Page 23 Warranty Card Boombox with Radio, Cassette, Bluetooth , & SD/MMC/USB Ports ® Model Number: 15991 Please keep your purchase receipt together with your warranty card Name: Address: Date of purchase: Location of purchase: Fault Description: Office Use: Repaired Replaced Other We recommend that you attach a photocopy of your receipt, showing the date of purchase, to this warranty card and keep it for your reference.
- Page 24 The Bluetooth word mark and logos are registered trademarks owned by ® Bluetooth SIG, Inc., and any use of such marks is under license. Other trademarks and trade names are those of their respective owners.
