Summary of Contents for Snugr SmartDrive MX
- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS SmartDrive MX driven by excellence May 2014 / 270746 / EN Snugr is a product of 4INCH sa...
- Page 2 General information General information Proof of amendment Version Date Changes April 2014 Initial preparation May 2014 Revision SmartDrive MX Version 1.1 - May 2014 Installation and operating instructions...
-
Page 3: Table Of Contents
Technical data ....................10 Environmental conditions................11 3 Transportation & Storage .................11 4 Assembly......................11 Checking the scope of delivery..............11 Insert batteries ....................12 Assembling the SmartDrive MX..............13 5 Commissioning....................14 Initialisation ....................14 6 Maintenance.......................14 7 Disposal......................15 8 Trouble shooting ....................15 Check list for breakdown ................15... -
Page 4: Safety
Proper use The electronic radiator thermostat SmartDrive MX described in this document has been designed for room temperature control and adapts the heat supply to the requirements of the individual rooms. It is designed exclusively for temperature control in closed interiors. -
Page 5: Product Specification
2 Product Specification 2 Product Specification The SmartDrive MX is designed for efficient room temperature control in private and commercial facilities. It provides wireless communication via bidirectional EnOcean standard radio protocol and boasts a large display screen as well as a dial for conventional manual control. -
Page 6: Dimensions
3 Display Symbol Explication Moving to installation position Adapting Teaching Reset to default setting Waiting for symbol display Empty battery Keyboard lock table 1 Symbol explanation SmartDrive MX Version 1.1 - May 2014 Installation and operating instructions... -
Page 7: Functions
The manual setting option for target temperature is available via the dial at all times. As soon as the dial is turned the SmartDrive MX will wake up and show the set target value on the display. This temperature is shown for a range of 10°C to 30°C in 0.5°C steps. - Page 8 • Keyboard lock It is possible for the SmartDrive MX to receive a command for key locking via the controller. In that case, you will no longer be able to set the target temperature for the SmartDrive MX manually. If key lock is enabled during the emptying of the batteries, it will be disabled for the new adapting process.
-
Page 9: Data Transfer
2 Product Specification Data Transfer The SmartDrive MX comprises a bidirectional EnOcean interface. This allows data transmission in either direction between the SmartDrive MX and the centre. The following data can be sent by SmartDrive MX : • Current valve position The current valve position is transmitted as a percentage value ranging from 0% to 100%. -
Page 10: Technical Data
Case ABS, PA6.6, PMMA Valve connection MS 58 (2.0401) Cap nut MS 58 (2.0401) Weight (including batteries) approx. 250 g Noise output level < 30 dB (A) table 2 Technical data SmartDrive MX Version 1.1 - May 2014 Installation and operating instructions... -
Page 11: Environmental Conditions
4 Assembly The Smart-Drive MX is easy to install. You do not have to drain the heating system, nor are there any interruptions to the heating system. The SmartDrive MX is suitable for all commercially available valves with M30x1.5 connection. -
Page 12: Insert Batteries
• When inserting the batteries pay attention to their polarity. ATTENTION Reattach the cover (06) of the battery compartment. A concluding symbol will appear on the display screen (02). Reattach the dial (03). SmartDrive MX Version 1.1 - May 2014 Installation and operating instructions... -
Page 13: Assembling The Smartdrive Mx
Assembling the SmartDrive MX diagram 5 on page 13 How to assemble the SmartDrive MX Screw the SmartDrive MX threaded connection (04) onto the heating valve. Tighten the threaded assembly. SmartDrive MX Installation and operating instructions Version 1.1 - May 2014... -
Page 14: Commissioning
Apart from battery replacement the SmartDrive MX does not require any maintenance by the user. Replace the batteries as soon as a weak battery status is indicated by the display or via the main device. The SmartDrive MX does not require continuous or periodical maintenance. -
Page 15: Disposal
7 Disposal 7 Disposal SmartDrive MX and batteries do not belong in domestic waste. They must be disposed of according to country-specific guidelines and laws. That way, you contribute to the protection of the environment and support sustainable recycling of raw materials.
