- Page 1 User Manual TC1350 TC1350 TURN 1 PC INTO 2…..10…….EVEN 100 BIS Approved: Self Declaration - Conforming to IS 13252 (Part 1): 2010, R- 41057215 www.eiratek.com...
- Page 2 User Manual TC1350 All rights reserved © EiRA TEK Without the company's written permission, no unit or individual can copy picking, copying some or all the content of this document, and cannot be disseminated in any form. www.eiratek.com...
-
Page 3: Table Of Contents
User Manual TC1350 Directory 1 Introduction to Terminal ................. 2 TC1350 Host interface and specifications ............2.1 TC1350 Host interface ................2.2 List of specifications ................3 Connection mode .................... 4 Instructions for use ..................4.1 Boot ....................... 4.2 Initializing network ................ -
Page 4: Introduction To Terminal
User Manual TC1350 1 Introduction to Terminal EiRA TC1350 thin client is a small cloud terminal equipment. It uses a high-performance ARM Cortex A53 quad-core 2.0GHz processor and runs the shared technology independently developed by Linux operating system. Main features are: ●... -
Page 5: Tc1350 Host Interface And Specifications
User Manual TC1350 2 TC1350 Host interface and specifications 2.1 TC1350 Host interface Fig 2-1 TC1350 PORTS Fig 2-1 TC1350 Monitor After hanging 5 / 33 www.eiratek.com... -
Page 6: List Of Specifications
User Manual TC1350 2.2 List of specifications System configuration information: System parameters Specific information ARM Cortex A53 ( 2.0GHz, 4Cores ) Memory DDR3 : 1GB Local storage NAND Flash: 4GB Ethernet (wired) 10/100/1000M Adaptive RJ45 Interface Wireless network Audio input MIC Input diameter 3.5mm... -
Page 7: Connection Mode
User Manual TC1350 3 Connection mode Fig 3-1 Connecting TC1350 cloud to a remote desktop server Note: Please use the correct qualified BIS power adapter (sold separately by EiRA), power adapter that does not match, may lead to irreparable equipment failure. -
Page 8: Instructions For Use
TC1350, monitors, keyboards, mice, cables and power supply. 4.1 Boot Host power up, enter the boot screen, the centre of the screen shows EiRA Logo then enter 4.2 section which describes "initializing network". Fig 4-1 boot screen Note: After the end of the boot screen, if the monitor shows black screen, refer to 6.1 section &... -
Page 9: Initializing Network
User Manual TC1350 4.2 Initializing network System load, hosts entered as in Figure 4-2 shows the network initialization stage, the network initialization phase detection network is available, the IP address configuration is normal, if the network initialization is successful, hosts into the 5.3 section describes automatic connection state. -
Page 10: Automatic Connection
User Manual TC1350 4.3 Automatic connection If automatic connection is not configured, the host will automatically skip the connection phase, into 4.4 section describes configuration centre. If automatic connection is configured, the host after successfully initialize the network, it will enter the figure 4-3a shown in the remote desktop connection automatically countdown. -
Page 11: Configuration Centre
User Manual TC1350 connection, if the connection is lost again in 4-3C shown in the automatic link with the countdown. Fig 4-3C Auto Connecting Retry Note: Automatic connection phase, automatic connection cancelled by the user or automatically reconnect, the system will enter 4.4 configuration Centre referred to in section. - Page 12 User Manual TC1350 Fig 4-4B Control Center Fig 4-4B shows, the Center is divided into three functional areas: ◆ Main menu: Center the menu list. ◆ Set the window: setting the host parameters area. ◆ Status bar: Displays current status information of the host.
-
Page 13: Connection Settings
User Manual TC1350 ◆ Network settings: Configure the network IP address, subnet mask, gateway, DNS, and so on. ◆ Network Diagnostics: provides network connectivity PING diagnostic operations. ◆ System: provides system-level operation interface and display information about the system. 4.5 Connection settings Enter the configuration Center main interface, the default display <... - Page 14 User Manual TC1350 Fig 4-5a Connection settings interface ■ Connection type TC1350 Cloud support two Remote Desktop Protocol: ◆ Deskpool Connection: Deskpool virtual desktop management system entry, defaults to using the Microsoft RDP Remote Desktop Protocol. ◆ Microsoft RDP Connection: MS RDP server connections, use Microsoft RDP Remote Desktop Protocol.
-
Page 15: New Microsoft Rdp Connection
User Manual TC1350 ◆ Connection type: Microsoft RDP, and Microsoft RDS ◆ Server address: the connection to the remote server address. ◆ Automatic connection: is set to auto connect, a host can set up an automatic connection. ◆ Action: "connection", "Edit", "delete" three action buttons. - Page 16 User Manual TC1350 Fig 4-6A added Microsoft RDP connection Set Microsoft RDP connection option as in Figure 4-7B shows, including personalized options and user desktop remotely, you need programs that run automatically. Fig 4-6B sets the Microsoft RDP options 16 / 33...
- Page 17 User Manual TC1350 Note: RemoteFX Option only and Hyper-V virtualization platform used in conjunction with Windows virtual desktops must be Windows 7 SP1 or later, or "start RemoteFX" option is invalid. When RemoteFX option is valid, the colour depth option is not available, RemoteFX defaults to 32 -bit colour depth.
-
Page 18: New Rds Connection
User Manual TC1350 4.7 New RDS connection Tap the "add RDS connection", you can see in Figure 4-8 is shown in the dialog box: Fig 4-7 added RDS connection Enter the "connection name" and the "server address”, click "add", you can add the RDS desktop sessions. If you tick the "remember account", users can enter an RDS desktop... -
Page 19: Display Settings
User Manual TC1350 4.8 Display settings Click on the center of the main menu "display settings" and enter the figure 4-8A shows the < display settings > interface. Fig 4-8A display settings ■ Set the resolution In the "resolution" in the list, select the appropriate display resolution, and then click the "Save"... - Page 20 User Manual TC1350 Click on the figure 4-8B "OK" button, the system will restart. After the restart is complete, appears as in Figure 4- 9C shows the prompt dialog box. Countdown 15 second expiration click "confirm" button. If you do not click the "confirm", and the system restarted when the countdown...
-
Page 21: Network Settings
User Manual TC1350 4.9 Network settings Click on the center of the main menu "network settings" and enter figure 4-10A is shown < wired network > interface. Fig 4-9A wired network settings Setting up a wired network 1) Configure your network for DHCP In the "configuration"... - Page 22 User Manual TC1350 "domain name server 1" and "domain name server 2” and click "Save". Attention: If you enter the IP address and other systems on the network by IP address conflict could lead to stable network connection is not available or the host cannot connect to the remote desktop, set static IP Qian, make sure the network address is conflict.
-
Page 23: Network Diagnostics
User Manual TC1350 sure, your account information is correct and connection to wide area networks. Click the "Save" button to save the current dial-up account information. Check the "connect automatically" option, you can each time the system starts automatically when you open the PPPoE connection, automatic dialling. -
Page 24: System
User Manual TC1350 Fig 4-10 Network Diagnostics In the address bar, enter the IP address or host name, and then click the "ping", you can start on the specified address for Ping operation. Ping results will be displayed in the area below. The user can modify the "parameter", specify the Ping packet size and number. - Page 25 User Manual TC1350 information", "cable card", "wireless network card", "mirror time", and so on. ● Software information In the "software" section, you can see the "operating system", "RDP " and so on. Figure 4-11B shows the < voice > page displays the...
- Page 26 User Manual TC1350 Fig 4-11c operation ● Restart the system Click on the "reset system", and confirmed, the system will automatically restart. ● System update System update feature used to upgrade system software. Please follow the following guidelines for host...
- Page 27 During the upgrade process, do not power off, reset and manipulating host. Otherwise it will cause the system to fail to start. ● Export log TC1350 Host support log, users can click on "export log" button, the current log file system administrator password. 27 / 33 www.eiratek.com...
- Page 28 User Manual TC1350 Figure 4-11d shows setup admin password dialog box, once you set the password, the system entered the "Center", it will prompt the user for an administrator password. The password is set to null, you can cancel the administrator password.
- Page 29 User Manual TC1350 Fig 4-11e Time Settings 29 / 33 www.eiratek.com...
-
Page 30: Frequently Asked Questions
User Manual TC1350 5 Frequently asked questions 5.1 How to fix monitor black screen problem If you selected the wrong too high-resolution monitor model or lead to display a black screen (out of range), you can use the system hot keys will be host to 800x600 factory setting. -
Page 31: How To Fix Google Chrome Browser Sound Issues
User Manual TC1350 Windows XP system, you need to either the local security policy is set to classic mode. ◎ Account reason: Microsoft remote desktop set whether to start the NLA authentication if the NLA authentication Terminal side of the RDP connection settings to open NLA option and fill in the correct account information. - Page 32 User Manual TC1350 2.Find the "[+] Details" button in the upper right to show the details of each installed plugin and click this button. 3.Find the flash plugin section in the list of plugins. There may be (1 file), (2 files) or (3 files) in this section.
- Page 33 User Manual TC1350 and install the Adobe Flash Plugin for non-Internet explorer browsers. 5.The first plugin listed in the flash section is the pepper flash implementation. You can tell that the first one is pepper flash by looking for "Pepper Flash" in the Location string. See yellow highlight below.
