  • Page 1 All manuals and user guides at all-guides.com 4 CH H.264 Multiplex DVR User Manual...
  • Page 2 All manuals and user guides at all-guides.com This symbol is intended to alert the user to the presence of unprotected “Dangerous voltage" within the product's enclosure that may be strong enough to cause a risk of electric shock. This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
  • Page 3 All manuals and user guides at all-guides.com All the safety and operating instructions must be read before the unit is operated. Make sure to switch the power off before you install the DVR. • There is the danger of an electric shock if the DVR is opened by an unqualified service •...

  • Page 4: Table Of Contents

    All manuals and user guides at all-guides.com TABLE OF CONTENTS Chapter 1 FEATURES ......................1 Chapter 2 PACKING DETAIL ....................2 Chapter 3 LOCATION AND CONTROL ................3 3.1 Front Panel Controls....................3 3.2 Real Panel Connectors...................4 3.3 Remote Controller....................5 3.4 Mouse Control ......................7 3.5 Playback Mode .......................9 3.6 PTZ Mode......................10 Chapter 4 INSTALLATION ....................12...

  • Page 5: Chapter 1 Features

    All manuals and user guides at all-guides.com Chapter 1 FEATURES H.264 compression ideal for saving HDD space Real time live display Up to 120FPS @ 360x240 recording (NTSC) Live display, record, backup, playback and network access at the same time...

  • Page 6: Chapter 2 Packing Detail

    All manuals and user guides at all-guides.com Chapter 2 PACKING DETAIL 1. DVR 2. Client Viewer Software CD 3. User Manual 4. Remote Controller 5. Power Cord 6. Power Adapter 7. Battery 8. SATA Cord 9. HDD Screws CONTENTS 1. DVR 2.

  • Page 7: Chapter 3 Location And Control

    All manuals and user guides at all-guides.com Chapter 3 LOCATION AND CONTROL 3.1 Front Panel Controls Item Description Exit various functions and menu screen ESC/ BACKUP Video data storage backup Enter search menu screen, use Up/ Down button to navigate SEARCH Press ENTER to access selected item Turn on picture-in-picture format, use Up/ Down button to navigate...

  • Page 8: Real Panel Connectors

    All manuals and user guides at all-guides.com 3.2 Real Panel Connectors Item Description MAIN MONITOR BNC port for the main monitor. VIDEO IN BNC input ports for cameras, 4 in total. AUDIO IN RCA input port for an audio signal NTSC／PAL SWITCH Switch between NTSC and PAL format.

  • Page 9: Remote Controller

    All manuals and user guides at all-guides.com 3.3 Remote Controller Remote Controller – Button Definition ○ LOCK Enable Keypad Function. ○ STATUS Display Status. ○ Start/ Stop Recording. ○ FREEZE Turn On/ Off Live Display FREZZE Function. Turn On/ Off Screen FREEZE Function. Enable/ Disable On Picture-In-Picture Format.
  • Page 10 All manuals and user guides at all-guides.com Enable/ Disable double screen size display. ○ ZOOM Use Directional button to navigate the screen display, and press Enter button to switch channels. ○ MENU/ Enable/ Disable Menu. Pause Playback. ○ / / / / Up Directional Button.

  • Page 11: Mouse Control

    All manuals and user guides at all-guides.com 3.4 Mouse Control Live Mode Single Channel Display Move the cursor to the desired channel and double left click. Change from Single-Channel Double left click to Multi-ChannelDisplay Mouse – Menu Mode Enter Menu setup Right click Select/ Enter Left click...
  • Page 12 All manuals and user guides at all-guides.com Full screen display, multiple clicking to switch channels Quad display. Mouse – GUI Hints and Tips Recording is on Live Audio is on Live Audio is off Motion detected on the channel Sensor triggered on the channel Video loss detected on the channel USB device detected DVR has been connected onto the Internet.

  • Page 13: Playback Mode

    All manuals and user guides at all-guides.com 3.5 Playback Mode Under the LIVE mode, the graphical icon [ ] will show up on the upper center of the screen and the operation panel (see below picture) will show up at right lower corner of the screen.

  • Page 14: Ptz Mode

    All manuals and user guides at all-guides.com 3.6 PTZ Mode Under LIVE mode, PTZ icon [ ] will appear on the upper left of the screen or be re-located on any place of your screen by dragging the mouse. PTZ – Remote Controller Control / SLOW Move PTZ up.
  • Page 15 All manuals and user guides at all-guides.com PTZ – Quick Function Icon Exit PTZ Mode and back to the LIVE mode Preset number N. (1~64) Go to preset number N. Set current PTZ location at preset number N. [TOUR] icon, click to activate preset tour Same as [PIP].

  • Page 16: Chapter 4 Installation

    All manuals and user guides at all-guides.com Chapter 4 INSTALLATION 4.1 System Configuration...

  • Page 17: Hard Disk Installation

    All manuals and user guides at all-guides.com 4.2 Hard Disk Installation Step 1 : Remove the 3 screws from DVR as cycled below (PIC 1). (PIC 1) Step 2 : Remove the front cover from DVR as indicated by the arrow (PIC 2). (PIC 2) Step 3 : Place the HDD on the HDD plate and connect the power and the SATA cables (PIC 3).
  • Page 18 All manuals and user guides at all-guides.com Step 4 : Screw the bottom of the DVR as indicated as cycled (PIC 4). (PIC 4)

  • Page 19: Chapter 5 Basic Operation And Menu Setup

    All manuals and user guides at all-guides.com Chapter 5 BASIC OPERATION and MENU SETUP 5.1 Main Menu Setup To enter the main menu and setup the DVR, please log-in account and enter user password. The default password of the administrator is “123456”. Please refer to “Account Setup”...

  • Page 20: Record Setup

    All manuals and user guides at all-guides.com 5.2 Record Setup Item Description Select STOP to stop recording or OVERWRITE to reuse the HDD when HDD is full. [Stop] ： Stop Recording HDD FULL [Overwrite] ： Start to overwrite beginning from the oldest data of HDD, and continue to record.

  • Page 21: Event Setup

    All manuals and user guides at all-guides.com 5.2.1 Quality & Frame Rate Setup Item Description Resolution Choose record resolution, this value will be used by all channels. You can setup quality and FPS separately for record type. Record Type Check/ uncheck the box will enable/ disable recording of that channel. Choose from Lowest/ Low/ Normal/ High/ Highest.
  • Page 22 All manuals and user guides at all-guides.com 5.3.1 Motion Setup Item Description Motion Detection Check the box to Enable/ Disable Motion Detection for all channels. Check the box to Enable/ Disable popup screen function for all channels. Motion Popup When motion is detected in LIVE mode, the detected channel image will popup in full screen display.

  • Page 23: Schedule Setup

    All manuals and user guides at all-guides.com 5.3.2 Sensor Setup Item Description Sensor Detection Check the box to Enable/Disable sensor detection for all channels. Sensor Popup Check the box to Enable/Disable popup screen function for all channels. When Sensor is detected in LIVE mode, the detected channel image will pop up in full screen display.

  • Page 24: Camera Setup

    All manuals and user guides at all-guides.com 5.4.1 Schdule Record Setup Click on the time icon on the left side. The setup menu will be displayed. You can have detail setup by dates, time and event. 5.4.2 Holiday Setup Since holidays are different between countries and regions, you can setup the holiday of your location accordingly (Maximum Setup: 50).

  • Page 25: Account Setup

    All manuals and user guides at all-guides.com Item Description 1 2 3 4 You can setup independently for each channel. Mask Check the box to Enable/ Disable mask function for LIVE mode Drag the white bar or press ◀ ▶ to adjust Brightness of your camera from Brightness value 1 to 255.

  • Page 26: Network Setup

    All manuals and user guides at all-guides.com NOTE! 1: When logged out automatically, you will have to operate in limited authority such as operations like: Freeze the screen, Picture in picture, Zoom in/ out, switch between channels…etc. If you need to enter the Setup menu, Search menu, backup menu, Record…etc, user’s account and password are required.
  • Page 27 All manuals and user guides at all-guides.com 5.7.1 Networking Setup The DVR supports DHCP, LAN and ADSL access for network connection. 5.7.1.1 DHCP If the DHCP option is used for DVR network connection, an IP address is assigned by the DHCP server automatically. 5.7.1.2 LAN Select LAN for network connection, the following information is required.
  • Page 28 All manuals and user guides at all-guides.com 5.7.2 HTTP Setup Item Description Enable HTTP Server Check to enable HTTP server. Users can remotely access into the DVR over the network if the HTTP function is activated. Port Enter a valid port value from 1 up to 65000. The default value is 80. 5.7.3 DDNS Setup Item Description...

  • Page 29: Ptz & Rs-485 Setup

    All manuals and user guides at all-guides.com 5.7.4 Mail Setup E-mail can be used as a form of notification when an event occurs (VLOSS, MOTION, and SENSOR). Item Description Enable E-mail Notification Check the box to enable/disable E-mail Notification function. Enter to set up SMTP Server name.

  • Page 30: System Setup

    All manuals and user guides at all-guides.com Item Description Enable PTZ Click the box to Enable/Disable PTZ function for each channel. Protocol Set up the protocol of PTZ cam. The supported protocol are PELCO-P, PELCO-D, and KND Click or press ◀ ▶ to set up PTZ ID. The valid ID value is from 1 to 64. PTZ ID Select Baud Rate for PTZ from 2400、4800、9600 Baud Rate...
  • Page 31 All manuals and user guides at all-guides.com 5.9.1 Display Setup Item Description Turn On / Off OSD display DVR Status Turn On / Off DVR illustration and record status display Date/Time Turn On / Off date and time display Channel Name Turn On / Off channel name display Set up the color of border in LIVE , PLAYBACK mode.（black, dark grey, Border Set...
  • Page 32 All manuals and user guides at all-guides.com 5.9.2.1 Change Date & Time Users are allowed to setup date and time of the DVR. 5.9.2.2 Time Zone Setup In time zone setup, users can change the time zone and activate Daylight Saving Time function according to your DVR location.
  • Page 33 All manuals and user guides at all-guides.com 5.9.3 Buzzer & Relay Setup Item Description KEY TONE Enable/ Disable keystrokes. Relay Switch Connection Set relay signal to be Normal Close (N.C.) or Normal Open (N.O.). Buzzer Duration Set up the duration from 1~999 seconds. Enable/ Disable buzzer operation when the alarm is triggered for sensor, ALARM BUZZER motion and vloss (Video Loss).

  • Page 34: Utility Setup

    All manuals and user guides at all-guides.com 5.10 Utility Setup Item Description HDD Initialization Select to enter hard disk initialization menu. Please stop recording before entering this menu. Enter the menu, system will show all the data (model/ volume) of HDD that is installed in the DVR. Check the HDD you’d like to initialize, then press “Start”.

  • Page 35: Diagnostic

    All manuals and user guides at all-guides.com 5.11 Diagnostic Item Description Version The current firmware version of DVR The connected IP address of DVR. If disconnected from network, the IP Address screen will display” NETWORK DISCONNECT”. MAC Address MAC Address of DVR HDD Volume The capacity of HDD HDD Used Rate...

  • Page 36: Chapter 6 Search & Backup

    All manuals and user guides at all-guides.com Chapter 6 SEARCH & BACKUP 6.1 Search Setup Item Description Press to enter event search menu. Event Search Time Search Press to enter time search menu. Select Playback Channels Check the desired channels to playback; uncheck channels to show LIVE video images.
  • Page 37 All manuals and user guides at all-guides.com Item Description Criteria Setup conditions of the event search function Page Convert pages of events Date/Time Date/ time when the event occurred. Event type, defined as following: : Video Loss VLOSS MOTION : Motion Detected SENSOR : Sensor Detected REMOTE IN...
  • Page 38 All manuals and user guides at all-guides.com 6.2.2 Time Search TIME SEARCH, you can search for a specific time of the recording data to playback. Dates with recording are shown by data marked with a red square [ □ ]. System will start playing back according to the date that you’ve selected.

  • Page 39: Backup Setup

    All manuals and user guides at all-guides.com 6.2 Backup Setup User can back-up any segment of recorded data in a specified time frame. To do so, connect a USB to the DVR. The format of backup file is IRF file and can be played by “DVRemoteDesktop.exe”...

  • Page 40: Chapter 7 Specification

    IR CONTROLLER DEVICE Supports SATA Hard Disk x1 STORAGE DVD WRITER DIVISION DISPLAY ZOOM Graphic OSD COMPRESSION H.264 720x480, 720x240, 360x240 (NTSC) RESOLUTION 720x576, 720x288, 360x288 (PAL) FRAME NTSC 30, 60, 120FPS RATE 25, 50, 100FPS QUALITY Highest/ High/ Normal/ Low/ Lowest...
  • Page 41 TCP/ IP, SMTP, HTTP, DHCP, DDNS, PPPoE INTERNAL EXTERNAL USB 2.0 (1 Port at Front Panel) : USB Flash Driver BACKUP NETWORK BACKUP FILE H.264 Compression MONITORING Software Watchdog RECOVERY Auto-Reboot By Watchdog FIREWARE USB 2.0 Port (1 Port at Front Panel)

  • Page 42: Chapter 8 Network Surveillance

    All manuals and user guides at all-guides.com Chapter 8 NETWORK SURVEILLANCE AP software:「DVR Remote Desktop」can allow you to remotely access and control the DVR from the PC 8.1 AP Software Installation and Setup Step 1：Enter the IP address of the DVR in the IE browser. Step 2: A window will pop-up.
  • Page 43 All manuals and user guides at all-guides.com Step 4: Run or Save our AP software. Step 5: If you choose to run the software, “Start” window will be shown. Please enter the information for the login DVR: IP, Port, Username and Password, or choose “Play Recorded File”...

  • Page 44: Ap Software Operation

    All manuals and user guides at all-guides.com 8.2 AP Software Operation Open the file “DVRemoteDesktop.exe”; enter the information of the DVR “IP address”, “Port” “Username” and “Password” and click “OK”. You should be able to login the DVR successfully and start to use the software. The default username and password is [admin/ 123456].
