Summary of Contents for GP:50 216/316
- Page 1 Pressure, Level & Temperature Transmitters & Transducers INSTALLATION MANUAL Models 216/316 TABLE OF CONTENTS 1. Introduction 1.1 Product Description 1.2 Warning 1.3 Unpacking/Inspection 1.4 Using this manual 2. Installation 2.1 Mounting/process connection 2.2 Power Supply 2.3 Wiring/Grounding 2.4 Environment 3. Operation &...
- Page 2 2. INSTALLATION Mounting/Process Connection Model 216/316 is a position sensitive device and its orientation may cause zero shift if mounted differently from the orientation the unit was calibrated in (standard orientation has the pressure ports in the horizontal position). Although this is the case, once determined, this shift can be adjusted for using the zero adjustment screw on the unit.
- Page 3 Pressure, Level & Temperature Transmitters & Transducers Properly tighten process connections before applying pressure to insure no leaks or mechanical failure can occur. Never insert sharp objects into diaphragm. This could cause permanent damage the sensor and / or mechanical failure/diaphragm rupture. Power Supply Connection Consult power requirements listed on the Calibration Recorded provided with each serialized individual unit.
- Page 4 3. OPERATION & MAINTENANCE Model 216/316 is designed to produce the respective output ( 0-5 Vdc, 4-20 mA) in direct proportion to pressure. Specific pressure range, input voltage requirements and electrical connections are marked on unit. Appropriate mating connections are required for proper installation and safety.
- Page 5 GP:50 warrants its products to the original customer/purchaser against defects in material and workmanship for a period of one (1) year from the date of delivery by GP:50, as shown in its shipping documents, subject to the following terms and conditions:...
- Page 6 AUTHORIZED TO GIVE ANY OTHER WARRANTY OR TO ASSUME FOR GP:50 ANY OTHER LIABILITY IN CONNECTION WITH THE SALE OF ITS PRODUCTS. GP:50 DOES NOT ASSUME THE COSTS OF REMOVAL AND/OR INSTALLATION OF THE PRODUCT OR ANY OTHER WORKMANSHIP, OR WILL GP:50 BE LIABLE FOR ANY CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OR INSALLATION OF ITS PRODUCT.
