- Page 1 Network Controller Operating Manual KUT-NC08...
-
Page 2: Table Of Contents
Unpacking and Installations Features Operating elements of Front panel Operating elements of Rear panel System Connections Setting IP Address System Start System Menu Block Diagram Specifications Accessories Warranty Policy... -
Page 3: Unpacking And Installations
30 years, and can fully meet your demands. Before using, please read through this operating manual well in order to fully utilize the function of this product, and also use the product of KARAK Electronics for a long time with the correct way of use. -
Page 4: Operating Elements Of Front Panel
Operating elements of Front panel 1. USB Terminal It is a terminal to connect various USB Media. It is useful in playing the sound source in USB storage media. 2. POWER LED It shows the Power Supply status. The Light is switched on when the Power Source is normally authorized. -
Page 5: Operating Elements Of Rear Panel
Operating elements of Rear panel 1. This is an Input Terminal of Audio Signal of JK-55. 2. This is a Switch to select the Input of MIC/LINE. Division Content Button Pressed MIC Source Input Button Not Pressed LINE Source Input 3. - Page 6 9. This is an Ethernet Port to be connected with the Network where Internet is available. 10. This is a Power Switch of Embedded Controller. 11. This is an IP Setting Switch. KUT-NC normally set this as '03' 12. This is an Input Terminal of AC Power Source.
-
Page 7: Setting Ip Address
Setting IP Address System may not be normally operated if you change it thoughtlessly without understanding of the site, as IP Address is decided according to the site design. 1. There are 2 IP Setting Switches. 2. This means 1 digit of each hex. 3. - Page 8 Rotary Value Decimal Number...
-
Page 9: System Start
System Start 1. Connect Keyboard, Mouse, Touch USB. 2. Connect Monitor RGB Cable. 3. Connect JK-55 of the Source to input, and 4. Set the 4th Value of IP with Switch. set the MIC / LINE. * Refer to "Setting IP Address" for more details. 5. - Page 10 7. Connect the Power Cable and press 8. Check if POWER ON LED is lit up normally. the Switch for Power supply. 9. In case POWER LED does not brink 10. Check if IP address is normally displayed normally, press the POWER S/W as you set.
-
Page 11: System Menu
System Menu 1. Composition of Display Screen is as follows; MENU SECTION MENU INFORMATION SECTION 2. Menu Area - This is a Title on the Information to be displayed. 3. Information Area - This shows the Information on Title. 4. Menu Explanation Menu Area Explanation Model Name... -
Page 12: Block Diagram
Block Diagram... -
Page 13: Specifications
Specifications Feature Mentioned items 6CH(Audio Line In) with EM MIC Audio Input 2CH(System Use) Front 1Port Ext. USB port Back 4Port 10/100Base-TX 5Port (UTP) Network Port Gigabit SFP 3Port (Support Ring Redundancy) Audio Sampling 48kHz/20Bit Power AC 220V / DC 24V Power Consumption 483(W)×88(H)×415(D)mm 2H (With Bracket) Dimension... -
Page 14: Warranty Policy
Warranty Policy 1 Year Limited Warranty The Network Controller(KUT-NC08) is warranted to be free from defects in materials and workmanship in normal use for a period of one(1) year from the date of original purchase. During that period, as it option, repair or replace materials at no charge. Product must be delivered to your dealer or an authorized service center at freight prepaid with the original sales receipt or other proof purchase.
