BAMBI BUCKET
Models 6072 – 1821
SERVICE MANUAL
2019A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bambi Bucket BB1214 and is the answer not in the manual?

Questions and answers

Related Manuals for SEI Industries Bambi Bucket BB1214

Summary of Contents for SEI Industries Bambi Bucket BB1214

  • Page 1 BAMBI BUCKET Models 6072 – 1821 SERVICE MANUAL 2019A...
  • Page 2 This manual is also available on the SEI website. Register for manual update notifications at bambiupdate@sei-ind.com SEI INDUSTRIES LTD. 7400 Wilson Avenue Delta, B.C. Canada V4G 1H3 Phone: (604) 946-3131 Fax: (604) 940-9566 E-Mail: seisales@sei-ind.com Website: www.bambibucket.com COPYRIGHT © 2019 SEI INDUSTRIES LTD. ALL RIGHTS RESERVED...
  • Page 3 Version Revision Summary • General Revision 2019A...

  • Page 4: Table Of Contents

    Table of Contents Section 1: Introduction ......................1 Bambi System Drawing ..........................2 Dump Valve Operation ..........................3 Control Head Operation ..........................4 Section 2: Deploying the Bambi Bucket ................. 7 Attaching to the Cargo Hook ........................7 Connecting Power ............................. 8 Longlines ..............................
  • Page 5 Section 8: Repairs ........................31 Control Head Repairs ..........................31 Rigging Repairs ............................39 Valve Repair and Replacement ....................... 45 Shell Repairs ............................48 Section 9: Specifications and Parts ..................55 Capacity and Weight Specifications ....................... 55 Parts ................................ 56 Section 10: Drawings ......................72 Section 11: Warranty ......................76...

  • Page 6: Section 1: Introduction

    SEI Industries Ltd. offers complete parts supply and repair services for the Bambi Bucket. For a repair facility in your area, please contact SEI. For maintenance and repair purposes, parts diagrams and descriptions are provided in this manual.

  • Page 7: Bambi System Drawing

    Section 1: Introduction Bambi System Drawing Bambi Bucket Service Manual – Models 6072-1821...

  • Page 8: Dump Valve Operation

    Section 1: Introduction Dump Valve Operation The Bambi Bucket uses a tubular fabric valve to control the flow of water exiting the bucket. The lower end of the tube has a flange which is attached to a circular opening in the bottom of the bucket.

  • Page 9: Control Head Operation

    Section 1: Introduction Control Head Operation The control head regulates the operation of the dump valve by raising and lowering the riser cable. The upper end of the riser is attached to the lower end of the tripline assembly. The upper end of the tripline is attached to the spring reel which winds the tripline onto a cable drum.
  • Page 10 Section 1: Introduction When the bucket is filled with water, the pressure pulls down on the valve, riser and tripline until the upper end of the bullet assembly engages the mechanical catch. The mechanical catch is locked in place by the linkage arms. To dump the valve, an electrical signal is sent to the solenoid which pulls up on the linkage arms and unlocks the catch.
  • Page 11 Section 1: Introduction THIS PAGE INTENTIONALLY LEFT BLANK Bambi Bucket Service Manual – Models 6072-1821...

  • Page 12: Section 2: Deploying The Bambi Bucket

    Section 2: Deploying the Bucket Section 2: Deploying the Bambi Bucket Attaching to the Cargo Hook The Bambi Bucket is rigged for a lateral cargo hook. Correct attachment is indicated when the name plate on the control head faces forward in flight. This ensures that the ballast on the Bambi will face forward in flight.

  • Page 13: Connecting Power

    Section 2: Deploying the Bucket Connecting Power The Bambi Bucket requires a 24 VDC power source capable of supplying 5 A. There are four types of suggested wiring installations (see Section 10: Drawings): 1. Pilot control: The control is wired into the pilot’s control column through a relay. 2.

  • Page 14: Checking Tail Rotor Clearance

    Section 2: Deploying the Bucket Checking Tail Rotor Clearance WARNING Using a Bambi Bucket with insufficient tail rotor clearance could result in a tail rotor strike which could result in serious injury or death. When a Bambi Bucket is attached directly to the helicopter cargo hook or attached using a longline less than 50 ft (15 m) in length, it is important to confirm that there is adequate tail rotor clearance.

  • Page 15: Instant Deployment System (Ids)

    Section 2: Deploying the Bucket Instant Deployment System (IDS) The instant deployment system uses a hub and spoke mechanism to automatically expand the mouth of the bucket as soon as the weight of the Bambi Bucket is taken up by the suspension cables.

  • Page 16: Section 3: Accessories

    Section 3: Accessories Section 3: Accessories PowerFill Snorkel PowerFill Snorkel is a system which allows partial or complete bucket fills from a range of previously inaccessible water sources as shallow as 18” (0.46 m) including streams, ponds and low profile dip tanks.

  • Page 17: Foam Injection Systems

    Section 3: Accessories Foam Injection Systems Sacksafoam is a foam injection system that uses a pump to dispense a controlled amount of foam concentrate from a reservoir into the water in the bucket. The operation of the Sacksafoam is controlled by the pilot through a control unit, which is mounted in the cockpit.

  • Page 18: Section 4: Making Adjustments

    Section 4: Making Adjustments Section 4: Making Adjustments Adjusting the Dump Valve Udder Udder refers to the amount that the dump valve bulges out below the bucket shell, when the bucket is full. A properly adjusted dump valve will have a maximum of 2" (50 mm) of udder.

  • Page 19: Bb1214S

    Section 4: Making Adjustments To adjust a single string: 1. Simply adjust the tension of the string to equal that of adjacent strings. Repeat the knot shown three times for each purse string. To adjust all the strings: 1. Stand the bucket vertically. 2.

  • Page 20: Section 5: Packing And Storage

    Section 5: Packing and Storage Section 5: Packing and Storage Packing the Bucket 1. Collapse the IDS by pushing the hub into the bucket. 2. Grab the control head and pull the suspension lines taut. Tape the lines together in two bunches. 3.
  • Page 21 Section 5: Packing and Storage 5. Gather the suspension lines into a coil and stow inside the bucket. Place the control head outside of the bucket to prevent the possibility of the lines tangling. 6. Avoid any sharp folds along the base of the shell as this protects the shell from delamination which can occur if the Bambi Bucket is stored for a long period of time.

  • Page 22: Storing The Bucket

    Section 5: Packing and Storage 9. Take the carrying bag and drape it over the bucket. 10. Roll the bucket over and close the bag. Storing the Bucket Prior to storage, wash the bucket with fresh water and dry completely to prevent the growth of mildew and the corrosion of aluminium and steel parts.
  • Page 23 Section 5: Packing and Storage THIS PAGE INTENTIONALLY LEFT BLANK Bambi Bucket Service Manual – Models 6072-1821...

  • Page 24: Section 6: Troubleshooting Guide

    Section 6: Troubleshooting Guide Section 6: Troubleshooting Guide Valve Troubleshooting Leaking Dump Valve 1. Check that the bolts securing the valve and gasket to the shell are equally fastened. There should be approximately 2 threads exposed past each nut. If necessary, butyl rubber sealant can be used to seal stubborn leaks between the shell and the gasket.

  • Page 25: Control Head Troubleshooting

    Section 6: Troubleshooting Guide 4. Adjust the chain on the tripline so that the valve has approximately 2" (50 mm) of udder hanging below the shell when the bucket is full of water. Too much or too little udder will not allow the valve to seal optimally and may lead to other issues.
  • Page 26 Section 6: Troubleshooting Guide 7. Check that the spring link is resting on the body of the stop bolt and not on the head of the bolt, with the control head sitting vertically. 8. Check for rifling in the trip block and deformation on the top of the bullet.
  • Page 27 Section 6: Troubleshooting Guide Tripline Jams on Returning 1. Pull the tripline completely out. Check that the swaged sleeves at the end of the tripline are not fouling the cast guide lugs on the head and cover. 2. Round the end of the swage sleeves with a file. 3.

  • Page 28: Section 7: Repair Assessment Guide

    Section 7: Repair Assessment Guide Section 7: Repair Assessment Guide Overview of Repair Categories This section is intended to provide the user with information that will allow for the quick repair assessment evaluation of the Bambi Bucket. The repair assessment process is almost identical for all sizes of the Bambi Buckets, with some exceptions for minor bucket design variations between the models.

  • Page 29: Control Head Repair Criteria

    Section 7: Repair Assessment Guide Control Head Repair Criteria Category 1: Safety Cease operations and repair immediately. • Any visible crack or break on the base plate. • Visibly bent shackles or suspension line bolts. • Missing, broken or loose valve release mechanism parts. •...

  • Page 30: Cables Repair Criteria

    Section 7: Repair Assessment Guide Cables Repair Criteria Category 1: Safety Cease operations and repair immediately. • One or more broken suspension cables or end fittings. • Broken deployment cable. Category 2: Operational Repair before next day’s operation or eight hours flight time. If three or more individual suspension cables or the deployment cable have the following defects: •...

  • Page 31: M-Straps/Top Chains Repair Criteria

    Section 7: Repair Assessment Guide M-Straps/Top Chains Repair Criteria Category 1: Safety Cease operations and repair immediately. • Broken top chains. • Broken or missing shackles. • Two or more broken M-straps. Category 2: Operational Repair before next day’s operation or eight hours flight time. •...

  • Page 32: Ids Repair Criteria

    Section 7: Repair Assessment Guide IDS Repair Criteria Category 1: Safety Cease operations and repair immediately. • Cracks or breaks across the major section of the IDS hub. • Two or more broken or cracked spoke brackets. • Two or more broken or missing spokes, clevis pins, shell brackets. •...

  • Page 33: Bucket Shell Repair Criteria

    Section 7: Repair Assessment Guide Bucket Shell Repair Criteria Category 1: Safety Cease operations and repair immediately. • One or more broken top loop knots (M-strap attachment point to the shell). • Gross punctures through shell that cut or severely damage one or more panel strips. •...

  • Page 34: Cinch Strap Repair Criteria

    Section 7: Repair Assessment Guide Cinch Strap Repair Criteria Category 1: Safety Cease operations and repair immediately. • Broken or missing cinch strap. • Field-modified cinch strap. • Broken or missing cinch strap retaining brackets. • Broken or missing cinch strap hook or mating ring. Category 2: Operational Repair before next day’s operation or eight hours flight time.

  • Page 35: Valve Repair Criteria

    Section 7: Repair Assessment Guide Valve Repair Criteria Category 1: Safety Cease operations and repair immediately. • Broken valve restrainer cable. • Two or more broken purse strings. Category 2: Operational Repair before next day’s operation or eight hours flight time. •...

  • Page 36: Section 8: Repairs

    Section 8: Repairs Section 8: Repairs Control Head Repairs For proper operation of the control head, avoid the following modifications: • Do not use another type of bearing as a replacement for the ball bearing. • Do not use lock wire as a substitute for the swage blocks on the tripline. •...
  • Page 37 Section 8: Repairs 3. Secure the spring reel to prevent the reel from unwinding. This can be done by clamping a small pair of vice-grips onto the bottom flange of the reel, locking the reel against the solenoid. CAUTION Accidental release of a wound spring reel can result in injury to your hands. Wear gloves and use caution when winding the spring reel or pulling the tripline.
  • Page 38 Section 8: Repairs 6. The photo shows the tripline end being pulled from the reel. If the spring reel tension has been released, the spring reel must be re-wound before the new tripline is installed. To wind the spring reel, complete steps 7 and 8 below, otherwise continue to step 9. Wind the spring reel 24 revolutions total, or until the reel stops, in the direction indicated by the arrow stamped on the cover.
  • Page 39 Section 8: Repairs 10. Once the tripline has passed through the trip block, bend the end of the tripline into a tight spiral using a pair of pliers. 11. Insert the end of the tripline through the large centre hole of the drum. Fish the tripline out through the small hole to the right of the centre hole using a flat screw driver.
  • Page 40 Section 8: Repairs 14. Pull the line up and over the finger and into the slot between the finger and the drum. To assist in this step: • Bend a piece of lock wire into a U shape. • Insert the bent end of the U into the large centre hole of the reel. •...
  • Page 41 Section 8: Repairs 17. While holding the reel securely, release the temporary lock. Allow the cable to wind in gradually. Do not let the reel free-wheel. Use gloves to protect your hands from injury. 18. Release the catch by pushing the solenoid up, then pull the tripline out 3-4 ft and return it to the retracted position.
  • Page 42 Section 8: Repairs 4. Locate the spring reel locking nut on the back of the control head. Remove the locking nut and then the spring reel. Make sure to hold the threaded bolt with an Allen key when removing the nut. 5.
  • Page 43 Section 8: Repairs 3. The spring reel must be turned in the counter- clockwise direction to tension the spring. Disconnect the elastic band on the vinyl coated cable and slowly pull the cable off the reel. Count the revolutions of the reel as you pull out the cable NOTICE The new spring reel is supplied with a vinyl coated cable attached.

  • Page 44: Rigging Repairs

    Section 8: Repairs Rigging Repairs Suspension Line Replacement A suspension line should be replaced whenever it displays noticeable kinking or fraying. Factory replacement lines come pre-swaged with connection links to make replacing quick and easy. To remove the connecting link between the suspension line and the M-strap, follow these procedures: 1.
  • Page 45 Section 8: Repairs M-Strap Replacement Replace M-straps if they become noticeably worn. M-straps may be repaired, if frayed, by melting the fray with a lighter to stop the fray from spreading. The length of the M-strap is critical to the Bambi Bucket functioning correctly.
  • Page 46 Section 8: Repairs 4. Holding the pliers tight, turn your hand clockwise. Repeat the operation until the knot is loose enough to remove the strap. 5. Complete step ‘a’ or ‘b’ depending on whether the strap is short or long. a.
  • Page 47 Section 8: Repairs 7. Twist the strap loop eye 180°. 8. Rotate the eye to the opposite side. 9. Pull strap end through the eye. 10. Pull strap tight. Bambi Bucket Service Manual – Models 6072-1821...
  • Page 48 Section 8: Repairs 11. The M strap set should now look like this. suspension line attaches to the top of each M-strap set. IDS Replacement Shell Bracket Spoke The IDS can be replaced either as a complete kit or as individual pieces, as required. See Section 9: Specifications and Parts for detailed parts drawings.
  • Page 49 Section 8: Repairs 8. Once the IDS is fully installed, test for fit. You should be able to pull the hub past the midpoint position with a slight effort. If the IDS is either too loose or too tight, it will require adjustment.

  • Page 50: Valve Repair And Replacement

    Section 8: Repairs Valve Repair and Replacement Dump Valve Replacement Replacement dump valve assemblies come complete with new purse strings, bolts, nuts, washers and gasket. To replace a valve: 1. Remove the old valve, gasket and all butyl tape. 2. Stand the bucket up with the valve hole on the bottom.
  • Page 51 Section 8: Repairs Purse String Replacement The purse string set has eight strings, two that have green markings and six that have black markings. The green marked strings are placed at each end of the valve opening. The order of strings is GBBBBBBBBG.
  • Page 52 Section 8: Repairs 4. Take the free end of the string with the green mark and loop it through the metal ring. Centre the mark on the metal ring. Green and black tie marks 5. Tie the purse string to the metal ring at the mark with a round turn and three half hitches.

  • Page 53: Shell Repairs

    Section 8: Repairs Shell Repairs Please read these instructions carefully and follow them exactly to obtain a good repair. Failure to follow these instructions or poor repair workmanship can lead to failed repairs and/or more damage to the bucket. Temporary Repairs with Sealing Clamps Repair clamps are used for an immediate repair to prevent the loss of liquid through large rips or holes.
  • Page 54 Section 8: Repairs 4. Place the top of the clamp over the bolt, then install and tighten the wing nut. NOTICE Leaving the clamp’s string on makes it easier to remove the repair clamp when placing a permanent patch on the bucket. NOTICE Tightening the nut with tools may break the bolt away from the lower clamp.
  • Page 55 Section 8: Repairs NOTICE Try a test repair before attempting to repair the bucket. This will verify your technique without risking damage to the bucket. It is much harder to fix a repair once a failed attempt has been made as the hardened glue is difficult to remove.
  • Page 56 Section 8: Repairs 2. Scrub the damaged area with an abrasive pad dampened with solvent (isopropyl rubbing alcohol is recommended). Scrub vigorously to remove the cured surface. The area should be clean and dry with a dull matte finish. 3. Wipe with a rag, dampened with solvent, to remove any residue from cleaning. Check to see if the area is totally clean and all coated surfaces and edges are dull.
  • Page 57 Aquaseal® urethane adhesive is designed for use on fabrics like the Bambi Bucket shell. The shelf life of this adhesive is about one year. Fresh adhesive can be obtained directly from SEI Industries Ltd. Bambi Bucket Service Manual – Models 6072-1821...
  • Page 58 Section 8: Repairs Hot Air Gun Patching Hot air gun patching is the preferred method because it provides the most durable, permanent repair possible. Tools and materials required: • Patches • Plastic hand-held roller • Hot air gun with wide surface nozzle •...
  • Page 59 Otherwise, the repair is finished. Shell Repair Kits Repair kits contain some of the tools needed to perform repairs on Bambi Bucket shells. Urethane adhesive is not included in this kit. Urethane adhesive can be purchased separately from SEI Industries Ltd. Kit Contents: •...

  • Page 60: Section 9: Specifications And Parts

    Section 9: Specifications and Parts Section 9: Specifications and Parts Capacity and Weight Specifications Capacities and weights are accurate to within 5%. Specifications are subject to change. CAUTION The selection of a Bambi Bucket model for a specific aircraft is dependent on many factors including aircraft weight, fuel weight, operation elevation and atmospheric conditions.

  • Page 61: Parts

    Section 9: Specifications and Parts Parts Control Head Bambi Bucket Service Manual – Models 6072-1821...
  • Page 62 Section 9: Specifications and Parts Control Head (continued) ITEM MODEL PART # DESCRIPTION BB6072 008698 BB8096 005067 BB8096S 008698 BB9011 005067 BB9011S 008698 BB1012 005067 BB1012S 008698 HEAD, CONTROL BB1214 005067 BB1214S 008698 BB1518 005067 BB1518S 008698 BB1821 005067 BB1821S 008698 BB1821L 005067...
  • Page 63 Section 9: Specifications and Parts Control Head (continued) Bambi Bucket Service Manual – Models 6072-1821...
  • Page 64 Section 9: Specifications and Parts Control Head (continued) ITEM MODEL PART # DESCRIPTION BB6072 BB8096S BB9011S BB1012S 013055 BB1214S BB1518S BB1821S TRIPLINE, FLEX BB8096 BB9011 BB1012 BB1214 013056 BB1518 BB1821 BB1821L 005223 REEL, SPRING, ASSY 006348 TRIPBLOCK, LINKAGE, KIT 005220 SOLENOID, W/HARDWARE 002953 TERMINAL, BLOCK...
  • Page 65 Section 9: Specifications and Parts Suspension ITEM MODEL PART# DESCRIPTION BB6072 007676 BB8096 007677 BB8096S 007676 BB9011 007677 BB9011S 007676 BB1012 007677 BB1012S 007676 CABLE, SUSPENSION, SET BB1214 007677 BB1214S 007676 BB1518 007677 BB1518S 007676 BB1821 007677 BB1821S 007676 BB1821L 007678 Bambi Bucket Service Manual –...
  • Page 66 Section 9: Specifications and Parts Suspension (continued) ITEM MODEL PART# DESCRIPTION BB6072 005544 BB8096 005545 BB8096S 005544 BB9011 005545 BB9011S 005544 BB1012 005545 BB1012S 005544 CABLE, SUSPENSION, PAIR BB1214 005545 BB1214S 005544 BB1518 005545 BB1518S 005544 BB1821 005545 BB1821S 005544 BB1821L 005547 004057...
  • Page 67 Section 9: Specifications and Parts Bucket Shell ITEM MODEL PART # DESCRIPTION BB6072 005774 BB8096 005775 BB8096S BB9011 005776 BB9011S BB1012 005777 BB1012S SHELL, BAMBI, ASSY BB1214 005778 BB1214S BB1518 005779 BB1518S BB1821 BB1821S 005780 BB1821L STRAP, M, LOOP 16” 005467 STRAP, M, STRAIGHT 35”...
  • Page 68 Section 9: Specifications and Parts Bucket Shell (continued) ITEM MODEL PART # DESCRIPTION BATTEN, 20”, ASSY BB6072 014319 BB8096 006375 BATTEN, 22-3/4”, ASSY BB8096S BB9011 BB9011S 006419 BATTEN, 23-3/4”, ASSY BB1012 BB1012S BB1214 001101 BATTEN, 28-1/2”, ASSY BB1214S BB1518 001102 BATTEN, 32-5/8”, ASSY BB1518S BB1821...
  • Page 69 Section 9: Specifications and Parts Bucket Shell (continued) ITEM MODEL PART # DESCRIPTION BB6072 BB8096 BB8096S BB9011 BB9011S 006089 BB1012 BB1012S VALVE, DUMP, ASSEMBLY BB1214 BB1214S BB1518 BB1518S BB1821 006090 BB1821S BB1821L BB6072 BB8096 BB8096S BB9011 BB9011S 005614 BB1012 BB1012S STRING, PURSE, SET BB1214 BB1214S...
  • Page 70 Section 9: Specifications and Parts Bucket Shell (continued) ITEM MODEL PART # DESCRIPTION BB6072 BB8096 006182 BB8096S BB9011 BB9011S 006183 BB1012 BB1012S BALLAST, ASSY BB1214 BB1214S 006184 BB1518 BB1518S BB1821 BB1821S 006185 BB1821L Bambi Bucket Service Manual – Models 6072-1821...
  • Page 71 Section 9: Specifications and Parts Bucket Shell (continued) ITEM MODEL PART # DESCRIPTION STRAP, CINCH, INTERNAL 102” BB6072 005484 BB8096 STRAP, CINCH, INTERNAL 117” 005487 BB8096S BB9011 STRAP, CINCH, INTERNAL 125” 005488 BB9011S BB1012 STRAP, CINCH, INTERNAL 134” 005490 BB1012S BB1214 STRAP, CINCH, INTERNAL 126”...
  • Page 72 Section 9: Specifications and Parts ITEM MODEL PART # DESCRIPTION BB6072 005394 BB8096 005391 BB8096S 008821 BB9011 005392 BB9011S 008822 BB1012 007231 BB1012S 008823 IDS, ASSY BB1214 005395 BB1214S 008824 BB1518 005397 BB1518S 008825 BB1821 005397 BB1821S 008825 BB1821L 014825 Bambi Bucket Service Manual –...
  • Page 73 Section 9: Specifications and Parts IDS (continued) ITEM MODEL PART # DESCRIPTION BB6072 005357 BB8096 005359 BB8096S 008829 BB9011 005361 BB9011S 008830 BB1012 007225 BB1012S 008835 HUB/CABLE, ASSY BB1214 005365 BB1214S 008831 BB1518 005367 BB1518S 008832 BB1821 005367 BB1821S 008832 BB1821L 014824 BB6072...
  • Page 74 Section 9: Specifications and Parts IDS (continued) ITEM MODEL PART # DESCRIPTION BB6072 010913 BB8096 010914 BB8096S BB9011 BB9011S 010915 BB1012 BB1012S CABLE, IDS, RESTRAINER, W/SHACKLE BB1214 010929 BB1214S BB1518 BB1518S BB1821 010916 BB1821S BB1821L BB6072 010893 BB8096S BB9011S BB1012S 010907 BB1214S BB1518S...
  • Page 75 Section 9: Specifications and Parts Carry Bags MODEL PART # DESCRIPTION BB6072 004901 BB8096 BB8096S BB9011 004902 BB9011S BB1012 BB1012S BAG, CARRY, BAMBI BB1214 BB1214S BB1518 BB1518S 004093 BB1821 BB1821S BB1821L Spares Kits MODEL PART # CONTENTS BB6072 BB8096S BB9011S 006205 BB1012S BB1214S...
  • Page 76 Section 9: Specifications and Parts Shell Repair Supplies MODEL PART # CONTENTS 003613 KIT, REPAIR 003645 PATCH, FABRIC, 8"x10" 014858 PATCH, FABRIC, BULK, 24"x68" 004502 CLAMP, REPAIR, SMALL 004503 CLAMP, REPAIR, MEDIUM 004504 CLAMP, REPAIR, LARGE ADHESIVE, AQUASEAL, ¾ OZ 003090 003091 ADHESIVE, AQUASEAL, 8 OZ...

  • Page 77: Section 10: Drawings

    Section 10: Drawings Section 10: Drawings Pilot Controls Bambi Bucket Service Manual – Models 6072-1821...
  • Page 78 Section 10: Drawings Pilot Controls, US InterAgency Bambi Bucket Service Manual – Models 6072-1821...
  • Page 79 Section 10: Drawings Crew Controls Bambi Bucket Service Manual – Models 6072-1821...
  • Page 80 Section 10: Drawings Crew Controls – External Power Supply Bambi Bucket Service Manual – Models 6072-1821...

  • Page 81: Section 11: Warranty

    Section 11: Warranty Section 11: Warranty SEI Industries Ltd. (the company) agrees to grant a warranty for a period of one year from the date of purchase of Bambi Bucket systems on the following conditions: a) The company’s sole obligation under this warranty is limited to repairing or replacing, at the company’s sole discretion, any product shown to be defective.
