Page 1: User Guide
USER GUIDE THERMAL TRANSFER LABEL PRINTER MODEL: 50244 www.qoltec.com... - Page 2 Introduction Thank you for purchasing our thermal transfer label printer. The printer meets the real-time and batch label printing requirements, via serial, parallel, USB and Ethernet. The device provides thermal transfer or transfer printing. This printer model supports a wide range of printing paper types. The printer is specially packed to prevent possible damage during transportation.
-
Page 3: Front Panel
APPEARANCE Front panel LED indicators FEED button Upper cover opening switch Paper outlet Rear panel Upper cover opening switch Inside Printhead opening switch Upper cover Spindle ribbon Printhead opening switch Paper guide Paper feed roller... -
Page 4: Printer Installation
Bottom External paper inlet Power button Parallel communication interface Power input Cashbox Serial Note: Illustrative image. The back panel of the device differs depending on the type of printer you have. Please refer to your device. INSTALLATION Printer installation Power adapter 1. - Page 5 Installation of thermal transfer tape 1. Press the switches at the left and right of the top cover at the same time to open it. 2. Place the roller on the spindle of the feeder. 3. Press to the left and then to the right. 4.
-
Page 6: Label Installation
Paper assembly diagram Ribbon take up hub Printing head Used ribbon roll Thermal transfer ribbon Paper guiding device Paper roll Ribbon move Black mark sensor Inner paper move Outter paper move Label installation 1. Press the switches at the left and right of the top cover at the same time to open it. 2. - Page 7 4. Adjust the width of the guides to the width of the label paper. 5. Close the print head by pulling the cover with both hands down. Make sure the print head is completely closed. LED functions Sound signal Problem Flashes 2 times 2 times Mechanism error...
- Page 8 Please refer to the table below for more information on each feature. Function: Instruction Power on self-test A. Disconnect the printer from the power supply. B. Make sure the printer has the paper loaded and then plug the printer back to power supply. The printer will start printing a test page after releasing the paper load button.
-
Page 9: Troubleshooting
1. Turn off the power. 2. Open the cover and press the FEED button, then turn the power off and hold down the FEED button for about 10 seconds. 3. When all the LEDs are off, release the FEED button. The printer will restart and complete the initialization. Troubleshooting. - Page 10 Print the auto test page to verify that the printer head is damaged. If it is, replace it with a new one. Change the tape and label paper to fit properly. Make sure the printer head is completely closed. Label size is incorrect or incomplete. Change size When you change the paper to labels, the sensor does not Paper jump when...
- Page 11 Image format Graphics Support BMP/PCX/BAS Temperature Working 5-45°C, Storage: -10~50°C Specification of the environment Humidity Working : 25%~85% ; Storage 10%~90% Power Input AC 110V/240V, Output: DC24V/2.5A,60W Memory Dimensions 223*286*169mm Weight 2.35kg Producer: ntec Ul. Chorzowska 44B 44-100 Gliwice Poland www.qoltec.com...
