Summary of Contents for BALAY 3EB920L
- Page 1 All manuals and user guides at all-guides.com...
- Page 2 All manuals and user guides at all-guides.com...
-
Page 3: Table Of Contents
All manuals and user guides at all-guides.com Table of contents Safety information ......Safety instructions . - Page 4 All manuals and user guides at all-guides.com Table of contents Basic settings ......Accessing the basic settings .
-
Page 5: Safety Information
All manuals and user guides at all-guides.com Safety information Read these instructions carefully. Only after doing this will you be able to operate your appliance properly. Keep the operating and assembly instructions in a safe place. If the appliance is given to another person, ensure the appliance documentation is also included. - Page 6 All manuals and user guides at all-guides.com Cooking using a water bath Cooking using a water bath involves cooking food inside a pot which is in turn placed in another larger pan which contains water. In this way, the food is heated gently and constantly and it is the hot water, not the direct heat of the hotplate, which cooks the food.
- Page 7 All manuals and user guides at all-guides.com Taking care of the cooling This hob is fitted with a fan in the lower section. Risk of malfunction! If a drawer is fitted beneath the hob you must not keep small objects or paper in it as, if they are picked up, they could damage the cooling fan or affect the cooling system.
-
Page 8: Causes Of Damage
All manuals and user guides at all-guides.com Causes of damage The base of the pans The rough bases of pans may scratch the hob. Avoid leaving empty pans on the hotplates. These may cause damage. Never rest hot pans on the control panel, the indicator Hot pans area or the hob surround. -
Page 9: Advice On Saving Energy
All manuals and user guides at all-guides.com Advice on saving energy Use a pan with thick flat base. Curved bases increase energy consumption. Place a ruler on the base of the pan, if there are no gaps, the base of the pan is completely flat. The diameter of the base of the pan should fit the size of the hotplate. -
Page 10: Induction Cooking
All manuals and user guides at all-guides.com Induction cooking Advantages of Induction cooking involves a radical change to the induction cooking traditional method of heating, as the heat is generated directly in the pan. For this reason, it offers a number of advantages: Greater speed in cooking and frying;... - Page 11 All manuals and user guides at all-guides.com Unsuitable pans Never use pans made from: standard, high quality steel glass earthenware copper aluminium Characteristics of the base The characteristics of the base of the pan can affect of the pan the evenness of the cooking. Pans which are made from heat-diffusing materials (such as "sandwich"...
-
Page 12: Getting To Know Your Appliance
All manuals and user guides at all-guides.com Getting to know your appliance The operating instructions are valid for a range of cooking hobs. A general overview of the models is provided on page 2. The control panel Control surface for Control surface for Indicators for T time program function... -
Page 13: Residual Heat Warning Light
All manuals and user guides at all-guides.com Residual heat warning light The hob has a residual heat warning light for each hotplate to show those which are still hot. Avoid touching the hotplate when this warning light is on. Although the hob is switched off, the warning light will stay lit while the hotplate is hot. -
Page 14: Adjusting The Hotplate
All manuals and user guides at all-guides.com Adjusting the hotplate Select the required heat setting using the + and - symbols. Heat setting 1 = minimum Heat setting 9 = maximum Each heat setting has an intermediate step. This is marked with a dot. -
Page 15: Cooking Table
All manuals and user guides at all-guides.com Cooking table Some examples are given in the following table. The cooking times depend on the type, weight and quality of the food being cooked. For these reason, results may vary. Slow cooking Duration of level slow cooking... - Page 16 All manuals and user guides at all-guides.com Slow cooking Duration of level slow cooking in minutes Pan-frying Fillets, with or without pastry or breadcrumb coating 6 10 min Frozen fillets 8 12 min Chops, with or without breadcrumb coating 8 12 min Steak (3 cm thick) 8 12 min Breast (2 cm thick)
-
Page 17: Childproof Lock
All manuals and user guides at all-guides.com Childproof lock The cooktop can be protected against being accidentally turned on to ensure that children do not switch on the elements. Switching the temporary childproof lock on and off You can lock the hob on just one occasion, for example if you have young children visiting you. -
Page 18: The Powerboost Function
All manuals and user guides at all-guides.com Ñ Switching the hob on Press the until the beep sounds and the Ñ indicator goes out. The permanent childproof lock is deactivated. The hob can now be used. The Powerboost Function Use this function to heat up the contents of the pan faster than by using the heat setting j. -
Page 19: It Is Activated As Follows
All manuals and user guides at all-guides.com It is activated as Follow the steps below: follows 1. Select heat setting j. 2. Press the + symbol. The letter n appears on the hotplate display. The function has now been activated. It is deactivated as Follow the steps below: follows... - Page 20 All manuals and user guides at all-guides.com 2. Press the + or - symbols for the selected hotplate. indicator lights up with the ? symbol on the selected hotplate. The basic settings are displayed. + symbol: 30 minutes - symbol: 10 minutes 3.
-
Page 21: The Timer
All manuals and user guides at all-guides.com The timer This can be used to time periods up to 99 minutes. It is independent of the other settings. Programming instructions 1. Press the j symbol. The a and 00 indicators light up on the time program function display. -
Page 22: Basic Settings
All manuals and user guides at all-guides.com Basic settings The hob offers various basic settings. Some of these settings can be modified. k childproof lock deactivated* Permanent childproof lock b childproof lock activated The hob is automatically locked once switched off. k majority of beeps Deactivating the beep Short beep to confirm... -
Page 23: Accessing The Basic Settings
All manuals and user guides at all-guides.com Accessing the basic settings Follow the steps below: Switch on the hob using the main switch. In the next 10 seconds, press the Ñ symbol until a beep sounds to confirm this and o b lights up on the time program function display, (see diagram). -
Page 24: Care And Cleaning
All manuals and user guides at all-guides.com Care and cleaning The recommendations and warnings given in this section are designed to help you clean and maintain your cooking hob in optimum condition Cooking hob Cleaning Clean the hob after each use. This will prevent spillages from burning. -
Page 25: Hob Surround
All manuals and user guides at all-guides.com Hob surround To prevent damage to the hob surround, follow the advice below: Only use warm water with a little soap Never use sharp or abrasive products Do not use the glass scraper Fixing malfunctions Malfunctions are generally caused by minor faults. -
Page 26: Normal Noises Heard During Appliance Operation
All manuals and user guides at all-guides.com Display Malfunction Measure The electronic system has Wait until the electronic system has cooled down overheated and the sufficiently. Then press any symbol on the hob. corresponding hotplate If the indication continues, notify the technical assistance has been switched off service. -
Page 27: After-Sales Service
All manuals and user guides at all-guides.com Sizzling This noise is produced by pans which are composed of different superimposed materials. The noise is caused by the vibration of the contact surfaces of the various superimposed materials. This noise comes from the cookware. - Page 28 All manuals and user guides at all-guides.com 9000308415 (1W094N) 00 8810...
