INSTRUCTION MANUAL

LED22GFRDA

Table of Contents

Need help?

Do you have a question about the LED22GFRDA and is the answer not in the manual?

Questions and answers

gerardo

May 19, 2025

Cual es el codigo para desbloquear los canales

1 comments:

Mr. Anderson

May 23, 2025

The code to unlock channels for the TEC LED22GFRDA is a password, but the specific code is not provided in the context.

This answer is automatically generated

Summary of Contents for TEC LED22GFRDA

Page 1 INSTRUCTION MANUAL LED22GFRDA...
Page 3: Table Of Contents
Contents Safety Precautions ..............................4-8 Overview(Front View) / Accessories ......................... 9 Overview(Back View) ............................10 Remote control ..............................11-12 Basic Operation ..............................13 OSD Menu 1. PICTURE Menu ............................14 2. SOUND Menu ............................... 15 .
Page 4: Safety Precautions
Safety Precautions Preface TECO LED/LCD colour television Safety Information...
Page 5 Safety Precautions Safety Information This LED/LCD television is for indoor use only.
Page 6 Safety Precautions Safety Information...
Page 7 Safety Precautions Safety Information power button is in the OFF postion)
Page 8 Safety Precautions Important Information If a television is not positioned in a sufficiently stable location, it can be potentially hazardous due to falling Many injuries, particularly to children, can be avoided by taking simple precautions such as: • Using cabinets or stands recommended by the manufacturer of the television •...
Page 9: Overview(Front View) / Accessories
Overview Front View LED Indicator Remote Control Sensor (keep clear) INPUT: Display the input source menu. MENU: Display/exit the OSD menu. CH+/-: Scan through channels. VOL+/-: Adjust the volume. PLAY: Play / Pause the disc playing EJECT: Eject the disc. : Turn on/standby the TV set.
Page 10: Overview(Back View)
Overview Back View HDMI Headphone VIDEO L-in R-in POWER PC AUDIO IN POWER: Connect to the power. HEADPHONE: Connect it to your headphone or other audio equipment. Video: Connect it to video output terminal of DVD. L/R in: Connect them to audio output terminals of DVD, shared with YPbPr. PC AUDIO IN: Connect it to the audio output terminal of PC.
Page 11: Remote Control
Remote Control : Turn the TV on/standby. : Load/eject DVD disc. MUTE: Press to mute the sound, press again or press VOL+ to unmute. SLEEP: Standby time ATUO : Auto adjust in PC mode. FAV: Display the favorite channel list. FAV+/-: : Scan the favourite channel.
Page 12: Remote Control
Remote Control VOL +/-: Adjust the volume. CH / : Scan through channels. ASPECT: Change the screen display mode. AUDIO: Change the audio language in DTV mode. PMODE: Select the picture mode. SMODE: Select the sound mode. Media/DVD program . : Play/Pause : Fast reverse.
Page 13: Basic Operation
Basic Operation Power on/off 1. Connect to the power supply with an adaptor. 2. -To turn on the TV Press button on the TV or remote control. -To turn off the TV Press button on the TV or remote control. Input Source select YPBPR Press INPUT button on the TV set or remote control to display the...
Page 14: Osd Menu
OSD Menu 1. Picture menu Description Picture Mode: Select your desired picture mode from Dynamic, Standard, Mild and User. Brightness: Adjust image black level. Contrast: Adjust image contrast. Sharpness: Adjust the sharpness(Gray and invalid in VGA/PC mode). Colour: Adjust image colour from black and white. Tint: Control the tint ( NTSC mode only).
Page 15: Sound Menu
OSD Menu OSD Menu 2. Sound menu Description Sound Mode: Select your desired sound mode from Standard, Movie, Music, Speech and User. Bass: Adjust the level of the lower-pitched sounds. Treble: Adjust the level of the higherpitched sounds. Balance: Adjust the audio output between left and right speakers. Surround: Turn on/off the surround sound function.
Page 16 OSD Menu 3. Channel menu(In ATV/DTV mode) Australia Description Channel Management: Enter the Channel management menu to edit the channels. Delete: Press RED button to sign the channels you want to delete, it will hint you when you exit. Lock: User must set the “Lock enable”(Feature-Lock- Lock enable) at ON to active this function.
Page 17 OSD Menu Country: Select the country. When the Child Lock is on, please enter the Password (Lock Password in Feature menu) to start Auto and Manual Search. Auto Search: Press OK button to enter the Auto Search menu, select search mode, and press OK button to start auto search.
Page 18: Feature Menu
OSD Menu 4. Feature menu Description Lock: This menu allows you to lock certain features of the television so that they can not be used or viewed. For example if you don’t want certain channels viewed by children or if the television is to be used in a hotel and you want certain channels be locked.
Page 19 OSD Menu OSD Menu Hotel Mode - Enter the Hotel Setting menu. Hotel Lock: Turn on/off the Hotel Lock function. Channel Lock: Disable the Channel menu in OSD. Picture Lock: Disable the Picture menu in OSD. Sound Lock: Disable the Sound menu in OSD. Feature Lock: Disable the Feature menu in OSD.
Page 20: Setup Menu
OSD Menu 5. SETUP menu Description OSD Timer: Lets you adjust the amount of time the On Screen Menu stays on the screen before disappearing. PC Setup: Change the PC Settings in PC mode. Auto Adjust: Setup the parameter of the screen automatically. H/V-Position: Adjust the transverse/vertical position of the screen.
Page 21: Multimedia Operation
Multimedia Operation Multimedia Operation Basic Operation 1). Press the INPUT button on the remote control to display the input source menu, select Media source by the buttons, and press OK button to enter the Multimedia menu as shown below. 2). Insert USB device, and select the Media mode form Photo, Music, Movie and eBook, then you will find the name of the device display on the screen as shown below.
Page 22: Multimedia Operation
Multimedia Operation Multimedia Operation 1. Photo Play the photo OK button to change. Press button to select the option on the table, and press Note: You could press OK button to display the option table when it disappears. Play/Pause the photo playing. Stop and exit the full screen program.
Page 23 Multimedia Operation 3. Movie Play the movie button to select the option on the table, and press OK button to change. Press Note: You could press OK button to display the option table when it disappears. Play/Pause the movie playing. Stop and exit the full screen program.
Page 24: Recording Operation
Recording Operation PVR settings Press the MENU button select Feature-PVR/Timeshift menu, press OK button to enter the menu as below. 1). Partition Select USB device informations Format: Press RED button to format the selected USB device. Set Default Partition: Press GREEN button to set the focus partition as the default partition .The recorders are stored in the default partition.
Page 25: Recording Operation
Recording Operation 5). Record List Display the Record list menu. Delete: Press RED button to delete the selected record plan. 6). Recorder Start Press OK button to start recording, as the function of the REC button on the remote control. EPG and Timer Record Press EPG button on the remote control to display the EPG menu.
Page 26 Recording Operation Recording Press REC button on the remote control to start recording in DTV mode. Press a message window appears. Select “OK” item, and press OK to exit recording Note: a. Please make sure the USB device is on the TV. b.
Page 27: Dvd Operation
DVD Operation Press the Power button on the TV or the remote control, then press the INPUT button to select DVD mode. If there is no disc in the DVD player the screen will show "NO DISC". Insert Disc according to picture next to disc slot. Do not touch the playing surface.
Page 28 DVD Operation...
Page 29 DVD Operation...
Page 30: Dvd Operation
DVD Operation Spdif Setup Spdif out Spdif off Spdif /RAW is for amplifiers with a built in digital decoder. Spdif/PCM is selected for amplifiers with no built in digital decoder. - - Spdif Setup Page - - Spdif Output Spdif Off Spdif/RAW Spdif/Pcm Setup Spdif...
Page 31: Dvd Operation
DVD Operation Volume or NO disc...
Page 32: Dvd Operation
DVD Operation...
Page 33: Dvd Operation
DVD Operation...
Page 34: Dvd Operation
DVD Operation...
Page 35: Troubleshooting
Troubleshooting...
Page 36: Specifications
Specifications 21.5” LCD Panel Panel Size Max. Resolution 1920 x 1080 VIDEO Input Connector YPbPr AUDIO (L/R) PC AUDIO HDMI Output Connector HEADPHONE COAX Main Voltage Power 100 x 100mm Mounting Bracket (VESA) Mounting Screw Size Note: Specifications are subject to change without prior notice.
Page 37 Did you know? TECO Australia’s product range also includes:  Top Load Clothes Washers  Front Load Clothes Washers  Twin Tub Clothes Washers  Auto Sensing Condenser and Vented Clothes Dryers  Refrigerators  Chest and Vertical Freezers  Bar Fridges ...
Page 39 REPAIRS, SERVICE & WARRANTY It is hazardous for anyone installing, removing, altering, repairing, servicing or testing of this appliance. Only an Authorised Service Person can carry out servicing or repairs to this appliance. IF SERVICE IS REQUIRED: If you have a problem, and the problem persists after you have made the checks mentioned in this manual, contact: TECO Australia’s Service on 1300 660 037 (8:30am - 4pm Mon~Fri AEST) For warranty details please visit ww...
Page 40 www.teco.com.au EBG-PV...
