Phoenix CAM Owner's Manual

Owner's Manual — Phoenix CAM
Low amp draw, balanced airflow characteristics and maximum velocity of 2700 FPM are what propel the
Phoenix to rise above the competition.
The unique /3 horsepower design of the Phoenix Centrifugal Air Mover, coupled with a two-speed switch,
allows the restoration technician to deliver the most airflow using the fewest amps.
Maximum amp draw on high speed is 2.8 amps. This drops to a mere 2.4 amps on low speed. It is now
possible to fit as many as four Phoenix Centrifugal Air Movers onto a typical 5 amp household circuit.
The Phoenix CAM is lightweight, stackable, has a power indicator lamp, large three-position switch, and
superior cord management.
The Phoenix housing is durable, washable, and chemical resistant. It features multiple operating positions
allowing it to be angled up from horizontal to 45° and 90°.
The Phoenix Centrifugal Air Mover
• 2-Speed /3 Horsepower Motor with automatic-
reset thermal protection.
2.8 Amps on High Speed
2.4 Amps on Low Speed
• Maximum Velocities 2700 FPM
• Balanced Exhaust Airflow
• Directional Airflow
Horizontal, 45° Angle, 90° Angle
• Durable, rugged, chemical resistant housing, fan
wheel, and controls design.
• Operator interface conveniently located for easy
access, featuring: power indicator lamp and large
three-position switch.
• Phoenix exclusive Pilot Light and Sealed Switch are
recessed to prevent damage.
• Ergonomic carry handle and power cord storage.
• Non-marking, anti-skid, rubber feet.
Specifications subject to change without notice.
Toll-Free 1-800-533-7533
PO Box 8680 • Madison, WI 53708
Installation, Operation & Service Instructions
Read and Save These Instructions
Phoenix Centrifugal Air Mover
PN 4027508

www.usephoenix.com • sales@thermastor.com
TS-479 Rev. A 7/08
