D5231E
INSTRUCTION MANUAL
INSTRUCTION MANUAL
SIL 2 Switch / Proximity
Detector Repeater,
Open Collector Output
DIN-Rail and Termination Board,
Model D5231E
D5231E - SIL 2 Switch/Proximity Detector Repeater, O.C. Output
G.M. International ISM0172-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D5231E and is the answer not in the manual?

Questions and answers

Summary of Contents for G.M. International D5231E

  • Page 1 D5231E INSTRUCTION MANUAL INSTRUCTION MANUAL SIL 2 Switch / Proximity Detector Repeater, Open Collector Output DIN-Rail and Termination Board, Model D5231E D5231E - SIL 2 Switch/Proximity Detector Repeater, O.C. Output G.M. International ISM0172-1...

  • Page 2: Technical Data

    Characteristics General Description: The Switch/Proximity Detector Repeater type D5231E is a unit with eight independent channels suitable for applications requiring SIL 2 level (according to IEC 61508) in safety related systems for high risk industries. The unit can be configured for switch or proximity detector (EN60947-5-6 NAMUR), NO or NC input and for NO or NC floating solid-state relay (photo-MOS) isolated output compatible with logic circuits.

  • Page 3: Ordering Information

    + Common positive Input for Ch 1 to 8 Common Output channel 1 to 8 + Common positive Input for Ch 1 to 8 Common Output channel 1 to 8 G.M. International ISM0172-1 D5231 - SIL 2 Switch/Proximity Detector Repeater, O.C. Output...
  • Page 4 Ci device + C cable ≤ 50 % of Co and Li device + L cable ≤ 50 % of Lo). If the cable parameters are unknown, the following value may be used: Capacitance 180pF per meter (60pF per foot), Inductance 0.60µH per meter (0.20µH per foot). D5231 - SIL 2 Switch/Proximity Detector Repeater, O.C. Output G.M. International ISM0172-1...

  • Page 5: Function Diagram

    Function Diagram HAZARDOUS AREA ZONE 0 (ZONE 20) GROUP IIC SAFE AREA, ZONE 2 GROUP IIC T4 MODEL D5231E 10 - Supply 24 Vdc Common voltage free positive Contact Proximity connection Common Ch. 1 to 8 In 1 Out 1...

  • Page 6: Operation

    Any unauthorized modification must be avoided. Operation The Switch/Proximity Detector Repeater type D5231E is a unit with eight independent channels suitable for applications requiring SIL 2 level (according to IEC 61508) in safety related systems for high risk industries. The unit can be configured for switch or proximity detector (EN60947-5-6 NAMUR), NO or NC input and for NO or NC floating solid-state relay (photo-MOS) isolated output compatible with logic circuits.
  • Page 7 General Notes: SWC5090 Software can be downloaded for free at www.gmintsrl.com PPC5092 Adapter is needed to interface PC to D5231E module. The PC supplies the module via USB, therefore operating power supply (24 Vdc) is not Input / Output status real-time monitor strictly needed when configuring the module.

  • Page 8: Parameters Details

    Supported Modbus parameters: Parameters details: D5231E communicates via Modbus RTU RS-485 protocol. Below are all available registers. Address Description Notes Address 17: Supported ModBus Baudrates G.M. Factory Code Index Baudrate Instrument Code 4800 Option Code Identification Data 9600 Hardware Release...
