iSecurity101 YM-2400SL Quick Start Manual

SPECIFICATION

Power supp y l DC 12V (24V need order)
Operation Current
850mA
Holding Current
400mA
Delay Time
0/5/10/15sec.
NO/COM(0.1A@30VDC)
Door status sensor
NO/NC/COM(0.1A@30VDC)
Lock status sensor
2600Lbs(1200kg)
Holding Force
Magnetic distance(max.)
3mm
Red shows locked; Green shows unlocked
LED
182L X 30W X 25D(mm)
Lock Size
182L X 30W X 23.6D(mm)
Armature Plate
Weight 1.2kg

DIMENSION

10
A r m at u r e

WIRING DIAGRAM

Lock
Shear Magnetic Lock
Model: YM-2400SL
Color
Red
Purple
Green
Brown
Gary
182
164
153.5
Red(+)
Black(-)
Door Release
Button
Model
9 PIN Connection
DC 12V
Purple wire of the light
Door Positions Sensor NO
Lock Positions Sensor NC
Lock Positions Sensor COM
Delay Time
0S
10
Mag n et i c L o c k
POWER
ON
DOOR
OPEN FAIL
12VDC
FAIL
PUSH SAFE
0.5A SECURE
BUTTON LOCK
TIMER
15
PB NC COM NO
0 30
SECOND
Power Supply
MAINS
KEY
ARMED
DOOR
BELL
Keypad
R
EMC
tested
Germany
Black
GND
Orange
Orange wire of the light
Dangling
※
Blue
Lock Status Sensor NO
White
Door Status Sensor COM
5S 10S
DIGITAL ACCESS KEYPAD
1 2 3
4 5 6
7 8 9
0 #
*
We create security
15S
