Foreword
Dear user, we sincerely appreciate your choosing ZOTYE and T300 will bring you to the fan of driving.
All the Zotye Auto models manufactured by the Company have obtained the compulsory product certification of China (namely, 3C certification).
Please read the manual carefully and thoroughly to better enjoy the fun of driving.
ZOTYE T300 is equipped with advanced technologies and various high-end features. The manual is applicable to all existing models of ZOTYE
T1300. The features and functions introduced in the manual may be different from those of your vehicle. The manual provides you with operation
and caution information. Correct operation and maintenance ensure safe driving and prolong service life.
As ZOTYE vehicles are being improved continuously, ZOTYE INTERNATIONAL AUTOMOBILE TRADING CO., LTD (herein after refer to
as "the company") reserves the right of changing the manual without notice in advance.
The accompanying Three-guarantee Service and Warranty Certificate describe various rights of vehicle warranty and regular maintenance. Please
read the manual to understand your rights and responsibilities. Besides, Quick Start Guide, Navigation, Entertainment System and
Communication System, Tye-net Operation Guide.
In case of any question during operation of vehicle or when reading the manual or other driver's manuals, please contact with ZOTYE authorized
service station (herein after referred to as "authorized service station ") or dial ZOTYE hotline 400-900-9900.
The manual is an indispensable part of the vehicle. Keep the manual and other driver's document at hand for reference at any time. In case of
transferring the vehicle to another user, do not forget the manual.
Thanks for your support to ZOTYE and wish you pleasant and safe journey.
ZOTYE INTERNATIONAL AUTOMOBILE TRADING CO., LTD
Aug. 17
