Summary of Contents for Aussie Surveillance SPEED DOME Series
- Page 1 SPEED DOME IP CAMERA SERIES OPERATION GUIDE...
- Page 2 Please read instructions thoroughly before operation and retain it for future reference. m2592L_LL_operation_V0.9 IMPORTANT SAFEGUARD All lead-free products offered by the company comply with the requirements of the European law on the Restriction of Hazardous Substances (RoHS) directive, which means our manufacture processes and products are strictly “lead-free”...
- Page 3 MPEG4 Licensing THIS PRODUCT IS LICENSED UNDER THE MPEG4 VISUAL PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER FOR (i) ENCODING VIDEO IN COMPLIANCE WITH THE MPEG4 VISUAL STANDARD (“MPEG-4 VIDEO”) AND/OR (ii) DECODING MPEG4 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE MPEG4 VIDEO.
-
Page 4: Table Of Contents
TABLE OF CONTENTS 1. OVERVIEW ............................1 1.1 Product Features ............................1 1.2 Package Content ............................1 1.2 Cable Overview ............................1 1.4 External Alarm Connection ........................2 1.5 Insert a Micro SD card..........................2 2. CAMERA ACCESS WITH INTERNET EXPLORER ................3 2.1 Camera Login ............................ - Page 5 3.7 Storage ..............................21 3.7.1 Memory ................................21 3.8 Trigger ..............................22 3.8.1 Trigger ................................22 3.8.2 Snapshot ................................ 23 3.9 General ..............................24 3.9.1 General ................................3.9.2 Time ................................3.9.3 Server Log ..............................25 3.9.4 Online ................................25 3.9.5 Account ................................3.9.6 Google Maps ..............................
-
Page 7: Overview
1. OVERVIEW 1.1 Product Features Quick network setup with your iOS® / Android™ mobile device External alarm I/O device connection -- For more accurate detection -- Possible to enable active event notifications to your iOS® & Android™ mobile devices (Push Video) when used with Push Video NVR series ... -
Page 8: External Alarm Connection
Remove the insulating coating of the wire, and twist it with the GND wire together to reset the camera to ifs factory values. 1 . ALARM IN Alarm input for an alarm device like magnetic contacts. 2 . ALARM OUT Alarm output for an alarm device like a siren. -
Page 9: Camera Access With Internet Explorer
2. CAMERA ACCESS WITH INTERNET EXPLORER / Android™ mobile devices with our self- ® ® ® This camera can be accessed via Microsoft Internet Explorer , and iOS developed program “EagleEyes” installed depending on different using situations. Note: For details about accessing this camera via iOS ®... - Page 11 Function Icon User Level Description...
-
Page 12: Pan- / Tilt-Move Manually
Live player Supervisor / Power User Select the image player from the drop-down list: / Normal User / Guest ActiveX QuickTime QuickTime is Apple Inc.’s multimedia software. You need to have QuickTime installed in your operating system before selecting “QuickTime”. When it is selected, you will be promoted to enter the user name and password to access the camera. -
Page 13: Event Record Search & Playback
Click to assign the point for focus adjustment. This Focus Zone function will be disabled when DPTZ is enabled. 2.4 Event Record Search & Playback This camera can only save a few recordings. Note: To save more recorded data, it’s recommended to use this camera with the compatible NVR. Click to jump to the next / previous time interval in an hour, for example, 11:00 ~ 12:00 or 14:00 Previous / Next Hour ~ 15:00, and start playing the earliest event video clip recorded during this whole hour. - Page 14 For details about “Network”, please refer to “3.2 Network” at page 8. For details about “Camera”, please refer to 3.3 Camera” at page 13. For details about “VA”, please refer to “3.4 VA” at page 20. For details about “Record”, please refer to “3.6 Record”...
-
Page 15: Network
Main Menu Sub-Menu Reference This function should be used with the mini-guard control switch for alarm system integration. For details, please check with your distributor or installer. Enable this function to reduce blurring associated with the motion of a camera during exposure. -
Page 16: Ddns
3.2.3 DDNS Select “On” when the selected network type in “Network” is “PPPOE” or “DHCP”. For details, please refer to “Advanced Network Setup” from www.surveillance-download.com/user/m2592.swf. 3.2.4 SNTP SNTP (Simple Network Time Protocol) is used to synchronize your camera time with the networked computer systems. -
Page 17: Sms
Function Description SMTP Server Enter the SMTP server address provided from your e-mail system supplier. Port Enter the port number provided from your e-mail system supplier. If this column is left blank, the e-mail server will use port 25 to send e-mails. Mail From Enter the name of the sender. -
Page 18: Filter
Click “Add” to enter the phone number, including the country code, to receive the text Recipient message. Five sets of phone numbers are allowed. Transfer Interval Set the interval time in minutes between two-message sending. The options are 0, 15, 30 & 60. Reset Counter Click to restart the text messaging, and the SMS will be sent after the specified time interval since you click this button. -
Page 19: Rtp
Check “Enable” to allow the camera to be detected among devices within the same network area, and set the identification name of the camera in “Friendly name”. When this function is activated, the other PC within the same domain as this camera will be able to search this camera in: ... -
Page 20: Ieee 802.1X
Function Description Port Range The port range used by RTP is limited, and preserving 100 ports between the start port and end port is necessary. Start Port The range of the start port is 1024 ~ 65434. End Port The range of the end port is 1124 ~ 65534. -
Page 21: Network Share
Step4: Upload the certificate(s) issued by the Certificate Authority, and save. Step5: Disconnect the camera from your PC or laptop, and connect it to the switch in the LAN environment you want to use IEEE 802.1x, and the camera will start the authentication later. 3.2.12 Network Share This function is used to assign a location in the LAN environment to save the snapshot of events. -
Page 22: Preset
3.3.2 Preset Note: Before using this function, make sure the DPTZ function is enabled. You can set new preset points (up to 16) or check existing points here. How to set a new preset point Step1: Click to where you want to see, and you’ll get a 5x zoom-in image. To slightly zoom out, draw a square from the bottom right to top left, and you’ll get a 3x image. - Page 23 Auto Pan When “Auto Pan” is selected here and clicked on the live view page, the camera will start panning. Sequence When “Sequence” is selected here and is clicked on the live view page, the camera will start patrolling each preset point defined in “Sequence”.
-
Page 24: Auto Tracking
3.3.4 Auto Tracking Set the surveillance area for auto tracking, and the tracking timeout. When the locked target is out of the pre-defined surveillance area or stops moving for a pre-defined period of time, the camera returns to the point it originally monitors. Item Description Limit 1... -
Page 25: Roi
3.3.6 ROI ROI, Region of Interest, is used to reinforce the image quality of the selected area(s). Users could specify two areas in the camera view. To edit a region, select one region and double-click it. The edit panel will be shown later. Draw an area where you want to reinforce its quality in “Live View”, and configure the picture quality from 1 ~ 10. -
Page 26: Advanced
3.3.9 Advanced Adjust the camera parameters if necessary. Item Description Fixed Shutter Shutter Speed is a function that can adjust the duration of the electronic shutter to produce optimum image quality. Select the shutter speed suitable for your environment. Slow Shutter Speed Slow shutter is used to increase the exposure time to get clearer image, for example, at night. -
Page 27: Home
Sharpness Sharpness enhances the clarity of image detail by adjusting the aperture and sharpening the edges in the pictures. Hold and drag the slider to adjust the level of sharpness from 0 ~ 10. The higher the value, the sharper the image. IRIS IRIS is used to adjust the amount of light reaching the image sensor for best image results. -
Page 28: Record
3.6 Record 3.6.1 Record In “Record Configuration”, you can: Enable or disable the alarm record function. When “Enable” is set to “No”, the alarm record function is disabled even if you enable it in other configuration pages. Select if the data should be overwritten when the memory storage is full. ... -
Page 29: Trigger
You can only record a limited number of recordings. Note: To save more recorded data, it’s recommended to use this camera with the compatible NVR. Note: To know the total recording time per recording resolution, please refer to “APPENDIX 2 RECORDING TIME TABLE”... -
Page 30: Snapshot
Here defines how the camera delivers alerts to you for any event. Item Description E-Mail Select the event type you want to receive E-mail notifications when it occurs. Then, click the title “E-Mail” (in blue) to configure the media type or profile, file format (AVC / AVI) and record time (1 ~ 5 seconds) for the event video clip. -
Page 31: General
Step3: Click “Convert” to start file conversion, and go to the path specified to store snapshots in “Network Share” to check the video file. 3.9 General 3.9.1 General To change the language of UI interface, select from the drop-down list in “Language”. “Turbo Steps”... -
Page 32: Online
To clear all system event logs, click “Clear All”. 3.9.4 Online You can check the current online user(s) with respective online information. To refresh the list, click “Reload”. To allow anonymous login, select “Enable” in “Anonymous Viewer Login”. To disable image code verification at login, select “No” in “Login with CAPTCHA Image”. 3.9.5 Account You can create a new account with different user access privilege, or delete or modify an existing account setting. -
Page 33: Google Maps
User Name Set a user name that will be used for camera access. The user name allows up to 16 alphanumeric characters. Password Set the password that will be used for remote login. The password allows up to 16 alphanumeric characters. Confirm Password Enter the password again to confirm. - Page 34 Firmware Upgrade This function is used when users need to upgrade the camera for function scalability. Note: Before using this function, make sure you have the correct upgrade files provided by your installer or distributor. Note: The event videos saved in the camera will be removed after firmware upgrade. Make sure you’ve copied important events to your PC before firmware upgrade.
-
Page 35: Appendix 1 Bit Rate Table For Reference
APPENDIX 1 BIT RATE TABLE FOR REFERENCE The data below is for reference only. The bit rates listed here may vary depending on the resolution, image quality & frame rate you choose, the complexity of your monitoring area, and how often the moving objects show in your monitoring area. Testing Environment ... - Page 36 Normal Basic QVGA Best High Normal Basic Resolution Quality Frame Rate (Dynamic) kbps (Static) kbps Best SXGA 1/15 High Normal Basic Best High Normal Basic QVGA Best High Normal Basic...
-
Page 37: Appendix 2 Recording Time Table
APPENDIX 2 RECORDING TIME TABLE Below shows the estimated total recording time for each recording resolution. The recording time per resolution is the average value collected from the both alarm trigger conditions indicated in “Testing Environment”, and is for reference only. The time may vary depending on the resolution, image quality &... -
Page 38: Appendix 3 Api Id Application For Sms Messaging
APPENDIX 3 API ID APPLICATION FOR SMS MESSAGING To allow the camera automatically sending a text message when an event happens, you need to apply an API ID from a mobile messaging company first, such as Clickatell or EVERY8D. Below shows an example of how to get an API ID from Clickatell. Note: The SMS messaging may not be totally free. -
Page 39: Appendix 4 Product Specifications
Step4: Click the link within the email to log in, and you will be prompted to validate your mobile phone number. Select “SEND ACTIVATION CODE”. The system will send an activation code to that number for verification. Check if you receive a text message from Clickatell, and enter the activation code. Step4: In your account, find “Connection Status”... - Page 40 DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP, ICMP, SMTP, FTP, HTTP, RTP, RTSP, RTCP,IPv4, Bonjour, UPnP, Supported Protocols DNS,UDP,IGMP, QoS, SNMP ONVIF Compatible YES (Profile S) Number of Online Users (1) Multiple user access levels with password (2) IP address filtering Security (3) Digest authentication (1) Internet Explorer on Windows operating system...
- Page 41 Power Consumption (±10%) PoE & PoN: 11.25W; DC Adapter: 25W Net Weight (kg) ▓ Audio Line in YES (Mono) Line out YES (Mono) * When PoE is used for power supply, the IR Turbo mode might not work properly. * The specifications are subject to change without notice. ▓...
-
Page 42: Dimensions
Dimensions APPENDIX 5 PREREQUISITES FOR NETWORK SHARE “Push Video” is an active notification system, different from traditional FTP & Email notification methods. It’s more active and stable, but also easier to be affected by your network bandwidth. A5.1 Check PC IP Address Note: The instructions below are taking Windows 7 and 8 for an example. -
Page 43: A5.2 Create "Administrator" Account
A5.2 Create "Administrator" Account It’s recommended to create a new administrator account on the PC for “Network Share” to use, or user could use the existing administrator account. Note: The instructions below are taking Windows 7 and 8 for an example. Step1: Go to "User Accounts”... -
Page 44: A5.3 Share Folder
A5.3 Share Folder Note: The instructions below are taking Windows 7 and 8 for an example. Step1: Right-click the folder you want to use to save snapshots for “Network Share”, and choose “Properties”. Step2: In “Share Properties”, select the tab of “Sharing”, and choose “Share…”. - Page 45 Step3: Choose the account you want to share with, and click “Share” to save.
