Portable Bluetooth Keyboard
(V-BTK380)
Thank you for purchasing the Valore Portable Bluetooth Keyboard (V-BTK380).
Stay funky with the trendy colours of the Valore Portable Bluetooth Keyboard. It is so slim that its
presence is almost unfelt while carrying it.
Important: Please read the user manual thoroughly before using your Portable Bluetooth
Keyboard.
Specifications:
• Interface: Interface standard MICRO
• Operating range: 10m
• Modulation: GFSK
• Operating voltage :3.0 - 4.2 V
• Working current: < 2.5mA
• Standby current: < 0.3mA
• Sleep current: < 40uA
• Charging current: ≥ 200mA
• Standby time: > 30 days
• Charge time: < 2 hours
• Battery type: Lithium battery capacity: 110mA
• Sustainable Working time: 44 hours
• Lithium battery life: 3 years
• Lithium Specifications (L x W x H): 3.0 x 25 x 25mm
• Key force: 80 ± 10g
• Key life: 5 million hits
• Working temperature: -10 ~ +55°C
UNDERSTANDING THE PRODUCT
Package Contents:
• Foldable Bluetooth keyboard
• Keyboard protective case
• Micro USB charging cable
①
②
③
① Bluetooth connect button
② On/Off switch
③ Micro USB charging port
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Valore V-BTK380
Summary of Contents for Valore V-BTK380
- Page 1 (V-BTK380) Thank you for purchasing the Valore Portable Bluetooth Keyboard (V-BTK380). Stay funky with the trendy colours of the Valore Portable Bluetooth Keyboard. It is so slim that its presence is almost unfelt while carrying it. Important: Please read the user manual thoroughly before using your Portable Bluetooth Keyboard.
- Page 2 START USING BLUETOOTH KEYBOARD 1) Operating System - Press “Fn” + “iOS” for iOS - Press “Fn” + “Windows” for Windows operating system - Press “Fn” + “Android” for Android 2) Operating System Charging the Bluetooth keyboard When the battery is low, the power LED indicator starts flashing, indicating that the Bluetooth keyboard requires charging.
- Page 3 Bluetooth switch to turn on Bluetooth function. The tablet now automatically searches for any nearby Bluetooth devices. Step 5: Find (Valore-BTK380) and click “Connect”. Step 6: Enter the password displayed on the screen to begin connection with the Bluetooth keyboard.
- Page 4 Solar power indicator: When the Bluetooth keyboard is utilising stored energy from the solar panel as power source, the “Solar” LED indicator lights up. Charge indicator: When the Bluetooth keyboard is being charged via the Micro USB cable provide, the “Charge” LED indicator lights up.
- Page 5 All information, trademarks, logos, graphics, and images (“Materials”) provided on this user manual are copyrighted or trademarked and are the property of Valore Lifestyle Pte Ltd. Any unauthorized use of any material contained on the instruction manual may violate copyright laws, trademark laws, laws of privacy and communications statutes.The trademarks, service marks and logos used and displayed in the Materials are...
