Summary of Contents for AMD Geode LE-363
- Page 1 All manuals and user guides at all-guides.com LE-363 3.5 inch Embedded Motherboard User’s Manual Edition 1.0 2005/9/16...
- Page 2 All manuals and user guides at all-guides.com LE-363 User’s Manual Copyright Copyright 2004 - 2005. All rights reserved. This document is copyrighted and all rights are reserved. The information in this document is subject to change without prior notice to make improvements to the products.
- Page 3 All manuals and user guides at all-guides.com LE-363 User’s Manual Packing List Please check the package before you starting setup the system Hardware: LE-363 little board x 1 Cable Kit: 44-pin 40-pin 44-pin 44-pin ATA33 IDE Cable x 1 USB Cable x 1 COM port &...
- Page 4 All manuals and user guides at all-guides.com LE-363 User’s Manual Index Chapter 1 <Introduction>...............6 1.1 <Product Overview> ..............6 1.2 <Product Specification> ..............7 1.3 <Mechanical Drawing>..............9 1.4 <Block Diagram> .................10 Chapter 2 <Hardware Setup> ............11 2.1 <Connector Location>..............11 2.2 <Jumper Location & Reference> ..........12 2.3 <Connector Reference>..............13...
-
Page 5: Table Of Contents
All manuals and user guides at all-guides.com LE-363 User’s Manual A.2 <Floppy Port>................34 A.3 <IrDA Port>.................34 A.4 < VGA Port >................34 A.5 <Serial Port>................35 A.6 <LAN Port>.................35 A.7 <PS/2 Keyboard & Mouse Port>..........35 A.8 < USB Interface >................35 A.9 < LPT Prot >……………………………………………..36... -
Page 6: Chapter 1
Chapter 1 <Introduction> 1.1 <Product Overview> LE-363 is the 3.5 inches embedded motherboard with AMD Geode GX533 platform, with onboard VGA, AC97 audio, dual LAN and DC 12V input interface. Based on the AMD Geode GX533 processor, the board provides many advanced features for reduced power consumption, fanless design and high cost/price rate of production. -
Page 7: Product Specification
Fan speed, CPU temperature and voltage monitoring Monitor VGA Display Interface Chipset AMD Geode GX533 built-in VGA controller with 2D engine Memory BIOS selectable up to 4/8/12/16 MB shard with system memory Display Type CRT, LCD monitor with analog display... - Page 8 All manuals and user guides at all-guides.com LE-363 User’s Manual Introduction Ethernet Interface Controller Dual PCI based REALTEK 8100B controller Type 10Base-T / 100Base-TX, auto-switching Fast Ethernet Full duplex, IEEE802.3U compliant Connector Two external RJ45 jack on I/O panel Audio Interface...
-
Page 9: Mechanical Drawing
All manuals and user guides at all-guides.com LE-363 User’s Manual Introduction 1.3 <Mechanical Drawing> Mechanical Drawing... -
Page 10: Block Diagram
All manuals and user guides at all-guides.com LE-363 User’s Manual Introduction 1.4 <Block Diagram> AMD Geode GX533 Processor VGA monitor TTL/LVDS LCD DDR SO-DIMM up to 512MB PCI/33Mhz Ultra DMA33 IDE USB1.1 X 2 Arbitor IT8209 8100B AC97 Audio CS5535... -
Page 11: Chapter 2
All manuals and user guides at all-guides.com LE-363 User’s Manual Hardware Setup Chapter 2 <Hardware Setup> 2.1 <Connector Location> CN_IR Mini PCI CD IN CN_USB JFRNT CN_LVDS CN_AUDIO CN_COM2 CN_LPT CN_LCD JRTC CN_SPWR CN_JVLCD CN_12V CN_INV CN_DIO DC_IN JCRT/TFTSEL SYSFAN... -
Page 12: Jumper Location & Reference
All manuals and user guides at all-guides.com LE-363 User’s Manual Hardware Setup 2.2 <Jumper Location & Reference> Jumper Function JRTC RTC/CMOS Setting JVLCD LCD Driving Voltage Setting JCRT/TFTSEL Select CRT/TFT Setting JRTC JVLCD JCRT/TFTSEL Jumper Location & Reference... -
Page 13: Connector Reference
All manuals and user guides at all-guides.com LE-363 User’s Manual Hardware Setup 2.3 <Connector Reference> 2.3.1 <Internal Connector> Connector Function Remark DIMM Onboard 200-pin DDR SO-DIMM socket Standard 44-pin primary IDE connector Slim 26-pin slim type floppy connector Slim CN_12V... -
Page 14: Cpu & Memory Setup
Hardware Setup 2.4 <CPU & Memory Setup> 2.4.1 <CPU> The board integrates AMD Geode GX533 400MHz processor with special design for power appliance. It requires only 8.4W power consumption at most, and is totally designed for fanless system. 2.4.2 <Memory>... -
Page 15: Cmos Setup
All manuals and user guides at all-guides.com LE-363 User’s Manual Hardware Setup 2.5 <CMOS Setup> The board’s data of CMOS can be setting in BIOS. If the board refuses to boot due to inappropriate CMOS settings, here is how to proceed to clear (reset) the CMOS to its default values. -
Page 16: Enhanced Ide & Cf Interface
All manuals and user guides at all-guides.com LE-363 User’s Manual Hardware Setup 2.6 <Enhanced IDE & CF Interface> The board supports one Ultra DMA33 IDE interface, dual channel for 2 ATAPI devices. The board also provides a Compact Flash Type I socket on secondary IDE channel and one onboard type I/II PCMICA Card Bus on the solder side. -
Page 17: Floppy Port
All manuals and user guides at all-guides.com LE-363 User’s Manual Hardware Setup 2.7 <Floppy Port> The board provides a slim type floppy port; please use the 26-pin ribbon cable in the package to connect the floppy device. Floppy rear side... -
Page 18: Ethernet Interface
All manuals and user guides at all-guides.com LE-363 User’s Manual Hardware Setup 2.8 <Ethernet Interface> The board integrates two PCI based Ethernet controller with REALTEK 8100B, full compliance with IEEE 802.3u 100Base-T specifications and IEEE 802.3x Full Duplex Flow Control. -
Page 19: Onboard Display Interface
LE-363 User’s Manual Hardware Setup 2.9 <Onboard Display Interface> The board integrates AMD Geode GX533 processor with built-in 2D video engine, to provide onboard DB15 VGA connector, 24-bit TTL and 18-bit/24-bit LVDS interface. The built-in 2D video engine supports following specified functions: ●High-performance 2D graphics controller... - Page 20 All manuals and user guides at all-guides.com LE-363 User’s Manual Hardware Setup In order to setup the LCD display well, please check the jumper setting before you use. Jumper: JVLCD Type: onboard 3-pin header JVOLT Mode +3.3V Default setting Connector: CN_INV...
- Page 21 All manuals and user guides at all-guides.com LE-363 User’s Manual Hardware Setup Connector: CN_LVDS ( for 24bit Signal channel LVDS panel ) Type: 40-pin header (40 x 2 pitch 2.0 mm) Connector model: Hirose DF13- 40DP-1.25V Signal (18-bit) Signal (24-bit)
- Page 22 All manuals and user guides at all-guides.com LE-363 User’s Manual Hardware Setup Connector: CN_LVDS ( for 18bit Signal channel LVDS panel ) Type: 40-pin header (40 x 2 pitch 2.0 mm) Connector model: Hirose DF13-40DP-1.25V Signal (18-bit) Signal (24-bit) LCDVCC...
- Page 23 All manuals and user guides at all-guides.com LE-363 User’s Manual Hardware Setup Connector: CN_LCD Type: onboard 2 x 20-pin header with housing, pitch=2.0mm Signal Signal ENAVDD ENBKL LCDVCC LCDVCC FPD0 FPD1 FPD2 FPD3 FPD4 FPD5 FPD6 FPD7 FPD8 FPD9 FPD10...
- Page 24 LE-363 User’s Manual Hardware Setup LCD Installation Guide: Preparing the LE-363, LCD panel and the backlight inverter. Please check the datasheet of the panel to see the voltage of the panel, and set the jumper JVLCD to +5V or +3.3V.
- Page 25 All manuals and user guides at all-guides.com LE-363 User’s Manual Hardware Setup After hardware setup well, you need to select the panel type in the BIOS. Panel Type Support List: Panel Number Resolution 640 x 480 800 x 600 1024x 768...
-
Page 26: Onboard Audio Interface
All manuals and user guides at all-guides.com LE-363 User’s Manual Hardware Setup 2.10 <Onboard Audio Interface> The board provides onboard AC97 audio interface with REALTEK ALC201A codec. Please use attached audio cable in the package to have Line-out, Line-in and MIC-in interfaces. -
Page 27: Serial Port
All manuals and user guides at all-guides.com LE-363 User’s Manual Hardware Setup 2.11 <Serial Port> The board provides one RS232 COM port on real I/O panel with DB9 as COM1, onboard CN_COM2 RS232 serial port and one onboard parallel connector. -
Page 28: Gpio Interface
All manuals and user guides at all-guides.com LE-363 User’s Manual Hardware Setup 2.12 <GPIO Interface> The board offers 8-bit digital I/O to customize its configuration to your control needs. For example, you may configure the digital I/O to control the opening and closing of the cash drawer or to sense the warning signal from a tripped UPS. -
Page 29: Power Supply
All manuals and user guides at all-guides.com LE-363 User’s Manual Hardware Setup 2.13 <Power Supply> 2.13.1 <Power Input> The board requires DC 12V input with onboard DC jack or 4-pin 12V DC connector. Connector: CN_12V Type: 4-pin standard ATX2.0 +12V power connector... -
Page 30: Switch And Indicator
All manuals and user guides at all-guides.com LE-363 User’s Manual Hardware Setup 2.14 <Switch and Indicator> The JFRNT provides front control panel of the board, such as power button, reset and beeper, etc. Please check well before you connecting the cables on the chassis. -
Page 31: Chapter 3
All manuals and user guides at all-guides.com LE-363 User’s Manual BIOS Setup Chapter 3 <BIOS Setup> The single board computer uses the Award BIOS for the system configuration. The Award BIOS in the single board computer is a customized version of the industrial standard BIOS for IBM PC AT-compatible computers. - Page 32 All manuals and user guides at all-guides.com LE-363 User’s Manual (This Page is Left For Blank)
-
Page 33: Appendix A
All manuals and user guides at all-guides.com LE-363 User’s Manual I/O Pin Assignment Appendix A <I/O Pin Assignment> A.1 <IDE Port> Connector: IDE Type: 44-pin (22 x 2) box header Description Description Reset Ground Ground Ground IOW-/STOP Ground IOR-/HDMARDY Ground... -
Page 34: A.2
All manuals and user guides at all-guides.com LE-363 User’s Manual A.2 <Floppy Port> Connector: FDD Type: 26-pin connector Description Description INDEX DSKCHG MTR0 STEP Ground WRITE DATA Ground WRITE GATE Ground TRACK 0 Ground RDATA- Ground A.3 <IrDA Port> Connector: CN_IR... -
Page 35: A.5
All manuals and user guides at all-guides.com LE-363 User’s Manual I/O Pin Assignment A.5 <Serial Port> Connector: COM1 Type: 9-pin D-sub male connector on bracket Description Description Ground A.6 <LAN Port> Connector: RJ45_1/2 Type: RJ45 connector with LED on bracket Description A.7 <PS/2 Keyboard &... - Page 36 All manuals and user guides at all-guides.com LE-363 User’s Manual A.9 < LPT Port > Connector: CN_LPT Type: 26-pin (13 x 2) header for LPT Ports Description Description PSTB- PRO0 PRO1 PRO2 PRO3 PRO4 PRO5 PRO6 PRO7 ACK- BUSY SLCT...
-
Page 37: Appendix B
All manuals and user guides at all-guides.com LE-363 User’s Manual Flash BIOS Appendix B <Flash BIOS> B.1 BIOS Auto Flash Tool The board is based on Award BIOS and can be updated easily by the BIOS auto flash tool. You can download the tool online at the address below: http://www.award.com... - Page 38 All manuals and user guides at all-guides.com LE-363 User’s Manual (This Page is Left For Blank)
-
Page 39: Appendix C
All manuals and user guides at all-guides.com LE-363 User’s Manual System Resources Appendix C <System Resources> C.1 <I/O Port Address Map> I/O Port Address Map... - Page 40 All manuals and user guides at all-guides.com LE-363 User’s Manual...
-
Page 41: C.2
All manuals and user guides at all-guides.com LE-363 User’s Manual System Resources C.2 <Memory Address Map> I/O Port Address Map... -
Page 42: C.3
All manuals and user guides at all-guides.com LE-363 User’s Manual Contact Information C.3 <System IRQ & DMA Resources> C.3.1 <IRQ> C.3.2 <DMA> Contact Information... -
Page 43: Appendix D
All manuals and user guides at all-guides.com LE-363 User’s Manual System Resources Appendix D <Programming GPIO’s> The GPIO can be programmed with the MSDOS debug program using simple IN/OUT commands. The following lines show an example how to do this. -
Page 44: Appendix E
All manuals and user guides at all-guides.com LE-363 User’s Manual Contact Information Appendix E <Programming Watchdog Timer > The watchdog timer makes the system auto-reset while it stops to work for a period. The integrated watchdog timer can be setup as system reset mode by program. -
Page 45: Contact Information
All manuals and user guides at all-guides.com LE-363 User’s Manual System Resources Contact Information Any advice or comment about our products and service, or anything we can help you please don’t hesitate to contact with us. We will do our best to support you for your projects and business.
