- Page 1 Vehicle Access Control Pedestrian Access Control Safety & Security Equipment T: +61 7 3205 1123 www.rotech.com.au e: info@rotech.com.au SENTINEL AG BOOM GATE Mechanical Quick Set-Up Instructions (V0118)
- Page 2 NOTE: The Quick Set-Up Mechanical Installation Instructions below provide basic information for setting up the AG Automatic Boom Gate. FOR MOST SITUATIONS CHANGES TO FACTORY SETTINGS ARE NOT NECESSARY For more detailed installation information please refer to the full set up instructions document. QUICK SET-UP MECHANICAL INSTALLATION The following quick set-up instructions are extracts from various sections of the complete Mechanical Installation Instructions:...
- Page 3 IMPORTANT: Set Up Boom Gate Handing BEFORE fixing the boom gate to the concrete base (See Page 21 Chapter 10.4) MECHANICAL INSTALLATION 10.1 10.2 10.3 The AG Boom Gates are supplied as Standard DX handing. 19 19...
- Page 4 RELEASE AND LOCK PROCEDURE 2x360° 2x360° FIG. 1 FIG. 2 RELEASE AND MANUAL OPERATION RESTORING AUTOMATIC OPERATION...
- Page 5 Boom Gate Handing (fig. 8) AG boom gates are supplied as standard DX handing (see Fig 8) For non standard SX installations unlock the boom gate (see chapter 21) Before removing the spring, make a note of the holes that the spring is fitted to as they will be the same holes on the non standard side.
- Page 6 opening tension (fig. 13) adjust springs so that the pole is balanced in this position - then tighten the lock nuts. Springs for most applications should be connected bottom hole (A) and top hole (1). Ingrassare Grease Ingrassare Grease 22 22...
- Page 8 immediately. NOTE AP open command (terminal block). (NC) and PED NOTE NOTE NOTE Tempo di chiusura automa ca Automa c closing...
