Installation, Operating and Servicing
Instructions
Panther SuperPass Hot Cupboard
P10SP6PT
P8SP4PT
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________
IS 576 ECN 3872
Page 1 of 10
Advertisement
Table of Contents
Summary of Contents for Lincat Panther SuperPass Series
- Page 1 Installation, Operating and Servicing Instructions Panther SuperPass Hot Cupboard P10SP6PT P8SP4PT Please make a note of your product details for future use: Date Purchased:_________________________ Model Number:__________________________ Serial Number:__________________________ Dealer:_________________________________ _______________________________________ IS 576 ECN 3872 Page 1 of 10...
-
Page 2: Table Of Contents
WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol is used whenever there is a risk of damaging your Lincat product. NOTE: This symbol is used to provide additional information, hints and tips. -
Page 3: Warnings And Precautions
WARNINGS AND PRECAUTIONS This appliance must be installed, commissioned and serviced by a qualified person in accordance with national and local regulations in force in the country of installation. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified person. -
Page 4: Installation And Commissioning
INSTALLATION AND COMMISSIONING This appliance must be earthed. An equipotential bonding terminal is provided to allow cross bonding with other equipment. If replacing the plug connect the terminals as follows: Green and Yellow wire Earth Blue wire Neutral N Brown wire Live Means of isolation with at least 3mm contact separation in all poles must be incorporated into the fixed wiring of this appliance. -
Page 5: Identification Symbols
IDENTIFICATION SYMBOLS Bain Marie Green neon will illuminate to show power to the controls. LH and RH tanks are identified with the marking below. Control has 6 positions 30-103 Deg C Crisp ‘N’ Hold is just an isolating on/off switch Crisp ‘N’... - Page 6 Fig 3 On/Off button Digital readout ‘Set’ button Adjust ‘+’ Adjust ‘-‘ Element ‘On’ symbol The electronic controller for the cupboard has a range of 20 Deg C to 99 Deg C, and is factory set at 85 Deg C. On switching the unit on (A), the digital readout (B) displays the current temperature within the cupboard.
- Page 7 Water Boiler wells Ensure the water boiler wells are filled with water before turning on. Ensure the wells water levels are maintained during operation. Switch on the power using the On/Off switch next to the electronic controller. The switch neon illuminates to indicate power. The electronic controller for the water boiler wells has a range of 20 Deg C to 99 Deg C, and is factory set at 82 Deg C.
-
Page 8: Cleaning
CLEANING Do not use a water jet or steam cleaner, and do not immerse this appliance. Clean all panels with warm water and mild detergent; do not use abrasive materials. Dry with a soft cloth. To access the inside of the cupboard for cleaning, remove the doors as shown overleaf. -
Page 9: Fault Finding
FAULT FINDING Please refer to the Service Helpdesk number on the final page of this manual. SPARE PARTS LIST Part Number Description CA143 Castor DS29 Door slide EC17 Electronic controller EL136 Bain Marie element 1kW EL232 Cupboard element 2.5kW EL307 Water boiler element 3Kw FA106 Cupboard fan... -
Page 10: Service Information And Guarantee
All available on serial plate Type number Serial number Lincat reserve the right to carry out any work under warranty, given reasonable access to the appliance, during normal working hours, Monday to Friday, 08:30 to 17:00. GUARANTEE This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is in addition to, and does not diminish your statutory or legal rights.
