PII-2G
Quick Installation Guide
Industrial 2-Port PoE Injector
www.westermo.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PII-2G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Westermo PII-2G

  • Page 1 PII-2G Quick Installation Guide Industrial 2-Port PoE Injector www.westermo.com...
  • Page 2 PoE injector, which applies power to Ethernet RJ- 45 data pairs for powered devices (PDs), PII-2G has the IEEE 802.3at and IEEE 802.3af standard and industrial grade EMC standards as well as offering 2-channels Gigabit high power connection.
  • Page 3: The Front Panel

    1,2,3,6 Data Pair powering Note: If the PD can’t be powering by PII-2G, then it may not be fully compliant with the IEEE802.3 PoE standard. It is recommended to use legacy power injector which feeds power directly to the PD device.
  • Page 4 Einführung Vielen Dank für den Kauf des PII-2G Power over Ethernet (PoE) Injektor. Der PII-2G ist ein moderner und kosteneffizienter Hochleistungs-PoE Injektor; Er versorgt das Powered Device (PD) über die Ethernet RJ-45 Datenleitungs, gemäß den Power over Ethernet Standards IEEE 802.3at und IEEE 802.3af. Er besitzt 2 PoE -Kanäle und ist besonders für den drahtlosen Fernzugriff oder Videoüberwachungs- Anwendungen geeignet, bei...
  • Page 5 Note PII-2G Alternative A 1,2,3,6 Datenleitungs-Paar überträgt den Strom Beachte: Wenn das PD vom PII-2G nicht mit Strom versorgt werden kann, ist es vielleicht nicht voll kompatibel zum IEEE802.3 PoE Standard. In dem Fall wird eine konventionelle direkte Spannungsversorgung empfohlen.
  • Page 6: Contenu De La Boite

    Le type d'alimentation Alternative A, spécifié dans la norme IEEE 802.3at, est employé par le PII-2G, ça veut dire que l'alimentation est injecté à travers des paires de données. Dans ce guide d'installation rapide, il vous est proposé de réaliser une connexion avec un périhérique (PD), son alimentation avec le PII-2G, et l’installation du PII-2G.
  • Page 7: Face Avant

    1,2,3,6 Data Pair powering Remarque: Si le PD ne peut pas être alimenté par le PII-2G, alors il ne peut pas être entièrement conforme à la norme PoE IEEE 802.3. Il est dans ce cas recommandé d’utiliser une alimentation indépendante plus puissante pour alimenter l’injecteur directement.
  • Page 8: Contenido Del Embalaje

    Alimentando el PII-2G El PII-2G soporta un amplio rango de tensión de entrada DC (46 a 57V) suministrados a través de un terminal extraíble de 4 pins, aparte de una conexión adicional de masa. La figura siguiente muestra el conexionado del PII-2G:...
  • Page 9: Panel Frontal

    (PD) no recibe alimentación, por favor revise si cumple las especificaciones IEEE 802.3af / 802.3at y si funciona de la misma forma que el PII-2G. Si se utilizan distintos cables en el PD que los utilizados en el inyector PoE, la alimentación no se establecerá.
  • Page 12 Germany Sweden info@westermo.de info.sverige@westermo.se www.westermo.de www.westermo.se For complete contact information, please visit our website at www.westermo.com/contact or scan the QR code with your mobile phone. 2014-11 Westermo Teleindustri AB, Sweden – A Beijer Electronics Group Company...
