Summary of Contents for Advantek Networks ANS-2402G
- Page 1 All manuals and user guides at all-guides.com 24 Port Fast Ethernet With 2 Port Gigabit Switching Hub User’s Manual Model # ANS-2402G...
- Page 2 All manuals and user guides at all-guides.com FCC Warning This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC Rules. These limitations are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 All manuals and user guides at all-guides.com Table of Contents Introduction to the Switching Hub …………………………………………………... 4 1.1 General Description ………………………………………………………………………..4 1.2 Features …………………………………………………………………………………….4 1.3 The Front Panel ……………………………………………………………………………4 1.4 Uplink Port ………………………………………………………………………………….5 1.5 The Rear Panel …………………………………………………………………………….5 1.6 What items come with...
- Page 4 All manuals and user guides at all-guides.com Learning ……………………………………………………….6 Filtering Forwarding …………………………………………………………………..6 Store Forward …………………………………………………………………………7 Product Specification ………………………………………………………………….8 1 Introduction to the Switching Hub 1.1 General Description This device is a high-performance 24 port Fast Ethernet with 2 port Gigabit Ethernet switching hub capable of 10, 100 and 1000Mbps auto-negotiation operation.
- Page 5 All manuals and user guides at all-guides.com 1.3 The Front Panel Functional LED Description Description When Gigabit switching hub connects to power, this LED will be on. When Broadcast Storm occurs, this LED will blink. 1….24 Fast Ethernet Port LED numbers. 25, 26 Gigabit Port LED numbers.
-
Page 6: Switch Operation
All manuals and user guides at all-guides.com is ready. 2.2 Installing The hub does not require install device driver. Users can immediately use any of the features of this product simply by attaching the cables and connecting the power, then turn on the switch. 2.2.1 Desktop Installation To locate the switching hub on the desktop and place the hub on a clean, flat desk or... - Page 7 All manuals and user guides at all-guides.com The switching hub is implemented with a MAC address table which is composed of many entries. Each entry is used to store the address information of network nodes on the network, including MAC address, port ID, etc. The information is the most important base to do packet filtering and forwarding.
-
Page 8: Product Specifications
All manuals and user guides at all-guides.com Keep Ethernet cables away from sources of electrical noise such as radios, transmitters, broadband amplifiers, power lines and fluorescent lighting fixtures. Water or moisture can not enter the unit Air flow around the unit and through the vents in the side of the case is not restricted Never stack units more than eight high if freestanding Do not place objects on top of any unit of stack... - Page 9 All manuals and user guides at all-guides.com Port x 2, 10M, 100M, 1000M, Link, Activity Filtering / warding Rate : 10Mbps : 14,880pps / 14,880pps 100Mbps : 148,800pps / 148,800pps 1000Mbps: 1,488,000pps / 1,488,000pps Operating Temperature 0-45 C (32-113 F) Operating Humidity 10% - 90% Power Supply...
