OWNER'S MANUAL
LED LCD MONITOR
(LED Monitor*)
* LG LED Monitor applies LCD screen with LED backlights.
Please read this manual carefully before operating your set and
retain it for future reference.
32UK550
www.lg.com
Copyright © 2018 LG Electronics Inc. All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 32UK550 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG 32UK550

Summary of Contents for LG 32UK550

  • Page 1 OWNER’S MANUAL LED LCD MONITOR (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 32UK550 www.lg.com Copyright © 2018 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. LICENSE ............2 The terms HDMI and HDMI High-Definition Multimedia Interface, OPEN SOURCE SOFTWARE NOTICE and the HDMI Logo are trademarks or registered trademarks of INFORMATION ..........

  • Page 3: Information

    Supported Drivers and Software LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com.

  • Page 4: Product And Button Description

    Product and Button Description Moving and Lifting the Monitor When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or damaged and to ensure safe transportation, regardless of its shape or size. • Place the monitor in the original box or packing material before attempting to move it. •...

  • Page 5: Adjusting The Stand Height

    Installing on a Table Adjusting the Stand Height • Lift the monitor and place it on the table in an upright position. Place the monitor at least 100 mm away from Place the monitor mounted on the stand base in an upright position. the wall to ensure sufficient ventilation.

  • Page 6: Installing The Wall Mount Plate

    Using the Kensington Lock Installing the Wall Mount Plate The connector for the Kensington security system is located at the bottom of the monitor. This monitor meets the specifications for the wall mount plate or other compatible devices. For more information on installation and usage, refer to the Kensington lock owner’ s manual or visit the website NOTE at http://www.kensington.com.
  • Page 7 Wall Mount Plate Back of the Monitor NOTE • A non-VESA standard screw may damage the product and cause the monitor to fall. LG Electronics is not liable Wall Mount Plate for any accidents relating to the use of non-standard screws. •...

  • Page 8: Using The Monitor

    USING THE MONITOR DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. • Illustrations in this manual may differ from the actual product. NOTE Press the joystick button, go to Settings Input, and then select the input option. •...

  • Page 9: Connecting Av Devices

    Connecting AV Devices HDMI Connection HDMI transmits digital video and audio signals from your AV device to the monitor. NOTE • Using a DVI to HDMI / DP (DisplayPort) to HDMI cable may cause compatibility issues. • Use a certified cable with the HDMI logo attached. If you do not use a certified HDMI cable, the screen may not display or a connection error may occur.

  • Page 10: User Settings

    USER SETTINGS NOTE • Your monitor’ s OSD (On Screen Display) may differ slightly from that shown in this manual. Activating the Main Menu Press the joystick button on the bottom of the monitor. Move the joystick up/down and left/right to set the options. Press the joystick button once more to exit the main menu.
  • Page 11 Main Menu Features Main Menu Description Input Sets input mode. Power Off Power Off Turns off the monitor. Settings Configures the screen settings. Exit Input Settings Game Sets the game mode for gaming. Exit Exits the main menu. Game Menu Settings To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the Settings.
  • Page 12 Quick Settings Settings > Quick Settings Description Brightness Adjusts the color contrast and brightness of the screen. Contrast Adjusts the volume level. Volume NOTE • You can adjust Mute / Unmute by moving the joystick button to in the Volume menu. The user can adjust it to red, green, or blue by customization.
  • Page 13 Picture NOTE • The Picture Mode that can be set depends on the Input signal. [Picture Mode on SDR (Non-HDR) signal] Settings > Picture Description Custom Allows the user to adjust each element. The color mode of the main menu can be adjusted. Reader Optimizes the screen for viewing documents.
  • Page 14 [Picture Mode on HDR signal] Settings > Picture Description HDR Vivid Optimized the screen for HDR vivid colors. HDR Standard Optimized the screen for HDR. HDR Game Optimized the screen for HDR Games. HDR Cinema Optimized the screen for HDR video. Picture Mode NOTE •...
  • Page 15 Settings > Picture Description Brightness Adjusts the brightness of the screen. Contrast Adjusts the contrast of the screen. Sharpness Adjusts the sharpness of the screen. Optimized picture quality is displayed when a user wants crystal clear images. It is effective for high quality High video or game.
  • Page 16 Settings > Picture Description Provides sharper images when connected to a device supporting ULTRA HD Deep Color. 4K@60 Hz Support Format (HDMI ULTRA HD Deep Color On) Color Depth / Chroma Sampling Resolution Frame rate (Hz) 8 bit 10 bit YCbCr 4:2:0 YCbCr 4:2:2 59.94...
  • Page 17 Settings > Picture Description Sets a response time for displayed pictures based on the speed of the screen. For a normal environment, it is recommended that you use Fast. For a fast-moving picture, it is recommended that you use Faster. Setting to Faster may cause image sticking.
  • Page 18 Settings > Picture Description The higher the gamma value, the darker the image becomes. Likewise, the lower the gamma Mode 1, Mode 2, Mode 3 value, the lighter the image becomes. Gamma If you do not need to adjust the gamma settings, select Mode 4. Mode 4 The user can adjust it to red, green, or blue by customization.
  • Page 19 General Settings > General Description Sets the menu screen to the desired language. Language High Saves energy using the high-efficiency SMART Energy Saving feature. Saves energy using the low-efficiency SMART Energy Saving feature. Disables the SMART Energy Saving feature. SMART ENERGY SAVING NOTE •...
  • Page 20 Settings > General Description OSD Lock This feature disables the configuration and adjustment of menus. Enables OSD Lock. Disables OSD Lock. NOTE • All features are disabled except Brightness, Contrast, Volume, Input List, Aspect Ratio, OSD Lock and Information. OSD Size User can select OSD Size to Large or Small.

  • Page 21: Troubleshooting

    TROUBLESHOOTING Nothing is displayed on the screen. • Is the monitor's power cord plugged in? Check if the power cord is correctly plugged into the power outlet. • Is the power LED on? Check the power cable connection and press the power button. •...
  • Page 22 Have you installed the display driver? Be sure to install the display driver from the display driver CD (or diskette) that comes with your display. Or, you can also download the driver from our web site: http:// www.lg.com. • Make sure to check if the graphics card supports Plug and Play function.

  • Page 23: Product Specification

    PRODUCT SPECIFICATION Color Depth 8-bit / 10-bit color is supported. Max Resolution 3840 x 2160 @ 60 Hz Resolution Recommended Resolution 3840 x 2160 @ 60 Hz Power Rating 19 V 3.3 A On mode: 39 W Typ. (ENERGY STAR® standard)* Power Sources 50 W Typ.
  • Page 24 Factory Support Mode (Preset Mode, PC) HDMI Display Modes (Resolution) Horizontal Frequency(kHz) Vertical Frequency(Hz) Polarity(H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1152 x 864 54.347 60.05 1280 x 720 1280 x 800 49.702 59.810 1280 x 1024...
  • Page 25 DisplayPort Display Modes (Resolution) Horizontal Frequency(kHz) Vertical Frequency(Hz) Polarity(H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1152 x 864 54.347 60.05 1280 x 720 1280 x 800 49.702 59.810 1280 x 1024 63.981 60.02 1600 x 900...

  • Page 26: Power Led

    HDMI Timing (Video) Factory support mode(Preset Mode) Horizontal Frequency(kHz) Vertical Frequency(Hz) Remarks 480p 31.5 720p 45.0 1080p 67.5 2160p When HDMI ULTRA HD Deep Color is set to ON Power LED Mode LED Color On Mode White (For a few seconds) Sleep Mode Off Mode...
  • Page 27 ENERGY STAR is a set of power-saving guidelines issued by the U.S.Environmental Protection Agency(EPA). This device can be used in all regions. Read the owner's manual (CD) carefully and keep it at hand. Please note that the label attached to the product provides information for technical support. As an ENERGY STAR Partner LGE U.
