Apantac TAHOMA MiniQ Hardware Manual

Multiviewers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TAHOMA MiniQ
Multiviewers
HARDWARE MANUAL
Version 1.0
Dated: November 19, 2012
© 2012 Apantac LLC - All rights reserved
The contents of this document are provided in connection with Apantac LLC ("Apantac") products. Apantac makes no
representations or warranties with respect to the accuracy or completeness of the contents of this publication and reserves the right
to make changes to specifications and product descriptions at any time without notice.
APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA
PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ●
INFO@APANTAC.COM
●
WWW.APANTAC.COM
Page 1 of 31

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TAHOMA MiniQ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Apantac TAHOMA MiniQ

Summary of Contents for Apantac TAHOMA MiniQ

  • Page 1 © 2012 Apantac LLC - All rights reserved The contents of this document are provided in connection with Apantac LLC (“Apantac”) products. Apantac makes no representations or warranties with respect to the accuracy or completeness of the contents of this publication and reserves the right to make changes to specifications and product descriptions at any time without notice.

  • Page 2: Table Of Contents

    APPENDIX B: External DC POWER SUPPLIES ........29   CONTACT APANTAC ................31   APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ● INFO@APANTAC.COM ●...

  • Page 3: Trademarks

    All other trademarks are the property of their respective holders. Notice: Copyright © 2012 Apantac LLC. All rights reserved. All information in this manual is subject to change without notice. No part of the document may be reproduced or transmitted in any form, or by any means, electronic or mechanical, including photocopying or recording, without the express written permission of Apantac LLC.

  • Page 4: Limitation Of Liability

    WARRANTY STATEMENT Apantac LLC (herein after referred to as “Apantac”) warrants to the original purchaser of the products manufactured by Apantac (the “Product,”) will be free from defects in material and workmanship for a period of three (3) year from the date of shipment of the Product to the purchaser.

  • Page 5: Extended Warranty Options

    Apantac equipment. Services and Repairs Outside the Warranty Period 21BU Apantac makes its best offer to repair products that are outside the warranty period, provided the product has not reached its end of life. Disclaimer 22BU Use of this product is limited to the intended design purpose.

  • Page 6: Introduction To Tahoma Miniq Multiviewers

    4B   INTRODUCTION TO TAHOMA MiniQ MULTIVIEWERS The Apantac Tahoma MiniQ Multiviewer platform displays multiple auto-detecting video inputs at different formats on a high resolution display up to resolutions of 1920x1200. The Tahoma MiniQ Platform combines the display of video windows, audio meters, label/UMD, tallies, alarms...

  • Page 7: Tahoma Miniq Product

    Inputs Inputs Inputs Inputs Inputs Inputs Inputs Inputs Inputs APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ● INFO@APANTAC.COM ● WWW.APANTAC.COM Page 7 of 31...

  • Page 8: Technical Specifications

    • Supports multiple languages (including 2 byte characters) • Supports SDI output (optional) APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ● INFO@APANTAC.COM ● WWW.APANTAC.COM...
  • Page 9 1280x1024 1360x768 1280x800 1400x1050 1600x1200 1680x1050 1366x768 1920x1080 1920x1200 APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ● INFO@APANTAC.COM ● WWW.APANTAC.COM Page 9 of 31...
  • Page 10 UMD protocols. The UIM can support third-party TCP/IP, UDP as well as serial protocols. The UIM can also act as an SNMP agent for the Apantac Tahoma Multiviewers. APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ●...

  • Page 11: Specifications

    SPECIFICATIONS 24B     APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ● INFO@APANTAC.COM ● WWW.APANTAC.COM Page 11 of 31...
  • Page 12 Figure 1 - show the front panel of a single MiniQ. Figure 2 - show the rear panel of a single MiniQ. APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ●...
  • Page 13 Figure 3 - show the front view of a fully configured MiniQ-3U-FR frame Figure 4 - show the rear view of a fully configured MiniQ-3U-FR frame APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ●...

  • Page 14: Product Contents - "What's In The Box

    HDMI to DVI adapter 1 per MiniQ module Terminal block for GPI 1 per MiniQ module APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ● INFO@APANTAC.COM ●...
  • Page 15 Note: The MiniQs airflow is from front to back. Figure 5 - Rack mount and airflow for Tahoma MiniQ APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ●...
  • Page 16 Direction of Cascading – Right to Left Figure 6 - Cascading and IP addresses of multiple MiniQ’s in a MiniQ-3U-FR APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ●...
  • Page 17 The MiniQ-3U-FR has 2 hot swappable AC power supplies. They are universal power supplies for 90V to 250V operation APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ●...

  • Page 18: Operation

    RJ45 to VGA Receiver • HDMI-1-R for HDMI extension • DVI-1-LR for DVI extension APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ● INFO@APANTAC.COM ● WWW.APANTAC.COM...

  • Page 19: Miniq Multiviewer Setup Examples

    MiniQ MULTIVIEWER SETUP EXAMPLES Figure 7 - Single MiniQ modules installation with Ethernet connection. APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ● INFO@APANTAC.COM ●...
  • Page 20 Figure 8 - Multiple MiniQ Modules installation with a MiniQ-1U-FR rackmount. APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ● INFO@APANTAC.COM ● WWW.APANTAC.COM Page 20 of 31...
  • Page 21 Figure 9 - A fully configured MiniQ in a MiniQ-3U-FR frame setup. Using t-Link to cascade multiple modules together to form a 2 x 16 setup APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ●...
  • Page 22 Figure 10 - A fully configured MiniQ in a MiniQ-3U-FR frame setup. Using t-Link to cascade multiple modules together to form a 4 x 8 setup APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ●...
  • Page 23 Figure 11 - A fully configured MiniQ in a MiniQ-3U-FR frame setup. Using t-Link to cascade multiple modules together to form a 8 x 14 setup APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ●...

  • Page 24: Accessories

    Rack mount RJ45-DB9 converter for RS232 serial connection Terminal Block CD, manual APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ● INFO@APANTAC.COM ● WWW.APANTAC.COM Page 24 of 31...

  • Page 25: Appendix A: Connectors

    Data 1- Data 1+ Data 2- Data 0+ Data 0- APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ● INFO@APANTAC.COM ● WWW.APANTAC.COM Page 25 of 31...
  • Page 26 • 1 GND Pin # Function GPI Power Alarm APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ● INFO@APANTAC.COM ● WWW.APANTAC.COM Page 26 of 31...
  • Page 27 Figure 15 - GPI-IN Wiring diagram. Connect this terminal block to the RJ50 to DB9 cable shown in Figure 14. APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ●...
  • Page 28 RJ50 to DB9 cable shown in Figure 33. Note: All LED are standard LEDs, all resistors are 150 ohms APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ●...

  • Page 29: Appendix B: External Dc Power Supplies

    V out (110% - 140%) Short Circuit Protection Automatic recovery after short circuit fault removed APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ● INFO@APANTAC.COM ●...
  • Page 30 MATERIAL FLAMMABILITY: UL 94V-0     B         APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ● INFO@APANTAC.COM ● WWW.APANTAC.COM Page 30 of 31...

  • Page 31: Contact Apantac

    Phone: +1 503 616 3711 Fax: +1 503 389 7921 Email: support@apantac.com www.apantac.com APANTAC, LLC. ● 7556 SW BRIDGEPORT ROAD ● PORTLAND, OR 97224, USA PHONE +1 503 616 3711 ● FAX +1 503 389 7921 ● INFO@APANTAC.COM ● WWW.APANTAC.COM Page 31 of 31...
