Summary of Contents for TelergyHD THD709QC-64-IP
- Page 1 THD709QC-64-IP Quick Reference Guide V1.1 TelergyHD Quick Reference Guide Please do read this user manual before you operate the TelergyHD . ~ 1 ~...
-
Page 2: Table Of Contents
THD709QC-64-IP Quick Reference Guide V1.1 Contents 1 Safety instructions ....................3 2 Accessory List ......................3 3 Hardware ....................... 4 4 Remote Control ...................... 5 5 System Connection ....................7 5.1 Rear Panel Connection ................7 5.2 Side Panel Connection ................. 8 6 Technical Specifications .................. -
Page 3: Safety Instructions
THD709QC-64-IP Quick Reference Guide V1.1 1 Safety instructions Please keep the TelergyHD in a horizontal position. Do not put any heavy stuff on the top of the device. Please use the provided power adapter. Do not use a damaged power cable and plug. -
Page 4: Hardware
THD709QC-64-IP Quick Reference Guide V1.1 3 Hardware Front Panel IR led Standby key Power led Net led Side Panel TF Card USB1 USB2 Rear Panel S/P DIF HDMI output Optical output DC in IR in Micro USB... -
Page 5: Remote Control
THD709QC-64-IP Quick Reference Guide V1.1 4 Remote Control 【Note】: Functions of the remote control maybe different for different Apps, you may need to use an external mouse to operate it. ~ 5 ~... - Page 6 THD709QC-64-IP Quick Reference Guide V1.1 4 Remote Control Go in and out of Standby Red button. Functionality depends on the application Green button. Functionality depends on the application Yellow button. Functionality depends on the application Blue button. Functionality depends on the application Up/down direction key.
-
Page 7: System Connection
5.1 Rear Panel Connection IR Cable Power Input Amplifier Storage Devices Internet Connection Note: Before powering on, Please switch the signal input of the TV to correct source. Tips: The TelergyHD supports Wi-Fi, enter Settings →Network to set-up Wi-Fi. ~ 7 ~... -
Page 8: Side Panel Connection
THD709QC-64-IP Quick Reference Guide V1.1 5.2 Side Panel Connection USB Device Tips: Please according to the above diagram insert the TF Card in the right direction. Please insert the USB device after matching interface correctly. ~ 8 ~... -
Page 9: Technical Specifications
THD709QC-64-IP Quick Reference Guide V1.1 6 Technical Specifications ARM Quad 64-bit Cortex-A53 up to 1.5GHz Android OS Android 6.0 Video output HDMI, AV Optical Audio output H.265 10-bit 4K*2K@60fps, H.264 AVC/MVC Video format 4K*2K@30fps, VP9, AVS+, MPEG1/2/4 ASP, WMV/VC- 1, RealVideo8/9/10 and other video formats... -
Page 10: Troubleshooting
THD709QC-64-IP Quick Reference Guide V1.1 7 Troubleshooting Issue Possible reason Solution Ensure the availability of the The power cord is not power supply at the mains No display on TV connected properly or there socket. Re-insert the power plug after power ON... -
Page 11: For More Information
THD709QC-64-IP Quick Reference Guide V1.1 8 For more information http://www.telergyhd.com/ Please visit ~ 11 ~... - Page 12 FCC Caution： This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
