Gardasoft Vision PP860 User Manual

Led lighting controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

Enlarged version
USER MANUAL
PP860, PP861
LED Lighting Controller
Revision 05
Gardasoft Vision Ltd
The Merchant's House, High Street,
Fen Drayton, Cambridge, CB4 5SJ, UK.
Tel: +44 1954 200343
Fax: +44 1954 204343
Web:
www.gardasoft.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PP860 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Gardasoft Vision PP860

Summary of Contents for Gardasoft Vision PP860

  • Page 1 USER MANUAL PP860, PP861 LED Lighting Controller Revision 05 Gardasoft Vision Ltd The Merchant’s House, High Street, Fen Drayton, Cambridge, CB4 5SJ, UK. Tel: +44 1954 200343 Fax: +44 1954 204343 Web: www.gardasoft.com...
  • Page 2 The user must ensure that incorrect functioning of this equipment cannot cause any dangerous situation or significant financial loss to occur. Gardasoft Vision Ltd and Gardasoft Products Ltd will not accept any liability for consequential loss of any kind. All trademarks acknowledged.

  • Page 3: Getting Started

    Gardasoft Vision also produce other controllers which are listed on our website. Connect the PP860 up to a supply and an LED lighting unit as described in “Connections”. Read the section on “Operation” and set up the PP860 to supply a small continuous current to the LED unit.

  • Page 4: Safety - English

    The PP860 does not have complete tracking isolation of inputs and outputs. Transients caused by inductive loads must be suppressed external to the PP860. 3.1.4 General The PP860 must not be used in an application where its failure could cause a danger to personal health or damage to other equipment.
  • Page 5 Überschläge, die aus Induktion resultieren können, müssen ausserhalb des PP860 abgehalten werden. 4.1.4 Generell Die Controller der PP860 Serie sollten nicht in Applikationen eingesetzt werden, in welchen ein Fehlverhalten des Gerätes gesundheitliche Schäden verursachen könnte oder technische Ausrüstung zerstören könnte.

  • Page 6: Safety - French

    GardaSoft Vision. 5.1.2 Chaleur Le PP860 peut atteindre une température très élevée. Il ne doit pas être placé à proximité d’une source de chaleur ou de matériel inflammable, ou à la portée du personnel, risque de brûlure. Respecter les puissances requises dans le manuel d’utilisation. Noter que le contrôleur peut atteindre 80°C.

  • Page 7: General Description

    0 to logic 1. Output 1 is triggered from INPUT 1, output 2 from INPUT 2, etc. Configurations can be saved in non-volatile memory so that the PP860 will resume operation after a power cycle. The pushbutton on the side of the unit is currently unused.

  • Page 8: Specifications

    35V (max) low as possible to reduce the total unit power dissipation. 15mA at V Quiescent supply current (IS) 33mA at V PP860: Maximum allowed current per continuous or channel. Average current when 20A pulsed Output current pulsing must not exceed the...

  • Page 9: Mechanical Fixing

    The PP860 can be mounted onto a flat surface using the threaded holes in the base, see diagram. The enclosure of the PP860 is used to dissipate power in the form of heat. For this reason the material to which the unit is attached must be suitable, preferably metallic with ability to dissipate the produced heat.

  • Page 10: Trigger Inputs

    Connections General The RS232 and trigger connections are made using D-type connectors. The power input and output connectors are The connectors are arranged as follows: 9.1.1 Trigger Inputs The trigger input connector is a 9-way D-type male. The trigger connector pinout is given below. Each input consists of a 1K resistor in series with an opto-isolating LED.

  • Page 11: Power Input

    Second channel negative 9.1.4 Serial Connector The RS232 connector is a standard 9-way female D-type connected as follows. A standard straight through cable can be used to connect the PP860 to a PC serial port. Function TX (output from PP860)

  • Page 12: Serial Commands

    1.5ms Current is in amps 0.2A 1.5A All responses from the PP860 are terminated with a ‘>’ character to indicate that the command is complete. If a command is invalid, one of the following error codes from Appendix A returned.

  • Page 13: General Commands

    Not set up Pulsed output Continuous output Output current (amps) Pulse width (microseconds) Delay before pulse (microseconds) VR Report the version of firmware running in the PP860 Syntax: Response: version 10.1.2 Continuous Output Mode In this case the mode of operation is selected and a single current output value defined.
  • Page 14 Set a continuous current of 0.5A on output channel 3 RS3,0.5 10.1.3 Pulsed Output Mode Set the pulse parameters. This command sets a channel to pulsed output. Note that output channel 1 can only be triggered by INPUT1 and output channel 2 can only be triggered by INPUT2, etc.

  • Page 15: Error Codes

    A. Error Codes Error codes may be displayed by the PP860. These are shown as “E nn”, where nn gives the number of the error. The error codes are: The PP860 has a thermal cutout. If the internal temperature reaches 62...
  • Page 16 • Light sensor feedback • PP900 Auto sensing lighting controller PP910 Auto sensing lighting controller with RS232 PP860, PP861 High current, high accuracy controller • 8 output channels up to 20A each • Pulses repeatable to 0.1 microseconds • RS232 configuration...
