OSP Designs MET42 Assembly Instructions Manual

Metro entry way bench w/ x back style

Advertisement

Quick Links

LIMITED WarranTy
OSP Designs Warrants, to the original purchaser its products to be free from defects in material and workmanship for a period of 90 days. Defects
and damage from misuse, abuse, negligence, alteration, accident, vandalism, rusting, acts of nature or any other event beyond the control of OSP
Designs is not covered. The warranty does not cover cosmetic damage that may result from normal use. Liability for incidental or consequential
damages is excluded. The user assumes all risk of injury resulting from use of this product. This warranty gives you specific legal rights, and you
may also have other rights which vary from state to state.
To make a warranty claim, contact Customer Service, provide model number, sales receipt and description of the problem. It is the customer's
responsibility to prepay freight on any components returned to the factory. OSP Designs will pay return freight on components covered under
terms of warranty.
Our quality standards are among the highest in the industry. Sometimes, no matter how hard we try, there are times when hardware is missing.
Our Parts Department will do everything possible to promptly remedy the problem. Contact us via email parts@officestar.net, by Fax
1-909-930-5629, or toll free parts number 1-800-950-7262, Monday through Friday 8:00 a.m. - 5:00 p.m. Pacific Time. OSP Designs P.O. Box
3520 Ontario, California 91761 USA
METRO ENTRY WAY BENCH w/ X BACK STYLE
ASSEMBLY INSTRUCTIONS
MET42
WarnInG
1. Do not use this product unless all screws and bolts are securely
tightened.
2. Check that all screws and bolts are tight every three months or as
needed.
3. Dispose of packing material properly. Do not use plastic cover as
head covering. It may cause suffocation.
4. Do not use this product as a stepladder.
5. Use this product for its intended purpose only.
6. Intended for residential use only

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MET42 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for OSP Designs MET42

  • Page 1: Assembly Instructions

    LIMITED WarranTy OSP Designs Warrants, to the original purchaser its products to be free from defects in material and workmanship for a period of 90 days. Defects and damage from misuse, abuse, negligence, alteration, accident, vandalism, rusting, acts of nature or any other event beyond the control of OSP Designs is not covered.
  • Page 2 Seat Assembly Left Side Frame Right Side Frame Backrest Front Panel Back Panel Bottom Panel Support Back...
  • Page 3 Long Bolt 60 mm Wood Screw Safety Hinge Long Wood Dowel 30 mm Wrench Wood Plug 20 mm Short Wood Dowel Medium Bolt 50 mm Short Bolt 30 mm Wood Screw NOTE: Phillips screwdriver also needed for assembly (not provided).
  • Page 4 STEP 1 Attach Seat Assembly (1) to Back Panel (6) using three Short Bolts (I). FULLY TIGHTEN SHORT BOLTS (I). STEP 2 Attach Support Back (8) to Seat Assembly (1) using one Medium Bolt (H), FULLY TIGHTEN MEDIUM BOLT (H). Further secure Seat Assembly (1) to Back Panel (6) using four Wood Screws (J).
  • Page 5 STEP 3 Insert six Long Wood Dowels (D) into Left Side Frame (2). Secure Front Panel (5) to Left Side Frame (2) using two Long Bolts (A), DO NOT FULLY TIGHTEN LONG BOLTS (A). Secure Seat Assembly (1) and Back Panel (6) to Left Side Frame (2) using two Long Bolts (A). FULLY TIGHTEN ALL LONG BOLTS (A).
  • Page 6 STEP 5 Insert eight Long Wood Dowels (D) into Right Side Frame (3), attach Right Side Frame (3) to assembly and secure using six Long Bolts (A). FULLY TIGHTEN ALL LONG BOLTS (A). STEP 6 Carefully prop open Seat Assembly (1). Attach Safety Hinge (C) to Support Back (8) and Seat Assembly (1) using four Wood Screws (B). FULLY TIGHTEN ALL WOOD SCREWS (B).
  • Page 7 STEP 7 Cover holes in Left Side Frame (2) and Right Side Frame (3) using six Wood Plugs (F) for each side frame. Carefully place Bottom Panel (7) into assembly. ATTENTION: MAKE SURE ALL SCREWS AND BOLTS ARE SECURELY TIGHTENED BEFORE USING THIS PRODUCT.
