ZXSDR BS8802 C100
ZXSDR CDMA Basestation-8802
User Guide
Version: 1.00
ZTE CORPORATION
NO. 55, Hi-tech Road South, ShenZhen, P.R.China
Postcode: 518057
Tel: +86-755-26771900
Fax: +86-755-26770801
URL: http://ensupport.zte.com.cn
E-mail: support@zte.com.cn

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZXSDR BS8802 C100 and is the answer not in the manual?

Questions and answers

Related Manuals for Zte ZXSDR BS8802 C100

Summary of Contents for Zte ZXSDR BS8802 C100

  • Page 1 ZXSDR BS8802 C100 ZXSDR CDMA Basestation-8802 User Guide Version: 1.00 ZTE CORPORATION NO. 55, Hi-tech Road South, ShenZhen, P.R.China Postcode: 518057 Tel: +86-755-26771900 Fax: +86-755-26770801 URL: http://ensupport.zte.com.cn E-mail: support@zte.com.cn...
  • Page 2 ZTE CORPORATION is prohibited. Additionally, the contents of this document are protected by contractual confidentiality obligations. All company, brand and product names are trade or service marks, or registered trade or service marks, of ZTE CORPORATION or of their respective owners.

  • Page 3: Table Of Contents

    Content FCC & IC STATEMENT ................... I FCC Radiation Exposure Statement ............. I About This Manual ..................I Chapter 1 System Description ..............1-1 1.1 System Background ................... 1-1 1.2 System Position ....................1-1 1.3 Appearance ....................... 1-2 1.4 System Functions....................1-3 1.5 System Features ....................
  • Page 4 6.1.2 Safety Symbols ..................6-1 6.1.3 Safety Specifications ................6-3 6.2 Installation Preparation ..................6-6 6.3 Chassis Installation .................... 6-6 6.3.1 Pole-Mounting a ZXSDR BS8802 C100 ............. 6-6 6.3.2 Wall-Mounted Installation................ 6-10 6.3.3 Ceiling-Mounting the ZXSDR BS8802 C100..........6-15 6.4 Cable Installation....................6-19 6.5 GPS Antenna Feeder System Installation ............

  • Page 5: Fcc & Ic Statement

    FCC & IC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. And this device must accept any interference received, including interference that may cause undesired operation.

  • Page 7: Fcc Radiation Exposure Statement

    FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 4m between the radiator & your body. This equipment generates RF electromagnetic energy during transmit mode. This radio is designed for and classified as “Occupational Use Only”, meaning it must be used only during the course of employment by individuals aware of the hazards, and the ways to minimize such hazards.

  • Page 9: About This Manual

    About This Manual Purpose This manual describes the features and operation of ZXSDR BS8802 C100 CDMA indoor multi-carrier Pico Base Transceiver Station. Intended Audience This document is intended for: Engineering technical engineer Installation engineer Prerequisite Skill and Knowledge To use this document effectively, users should have a general understanding of the CDMA technology.
  • Page 10 Typeface Meaning Bold Menus, menu options, function names, input fields, radio button names, check boxes, drop-down lists, dialog box names, window names. CAPS Keys on the keyboard and buttons on screens and company name. Note: Provides additional information about a certain topic. Checkpoint: Indicates that a particular step needs to be checked before proceeding further.

  • Page 11: Chapter 1 System Description

    Station, with low cost and low power. It is based on ALL-IP architecture, which facilitates the construction of flexible cross-area network modes and virtual wireless network. ZXSDR BS8802 C100 is mainly used to cover a particular indoor area and provide CDMA service access. In addition, ZXSDR BS8802 C100 can manage radio resources in conjunction with remote BSC.

  • Page 12: Appearance

    ZXSDR BS8802 C100 User Guide Figure 1-1 Position of ZXSDR BS8802 C100 in CDMA system ZXSDR BS8802 C100 is in the position of wireless access, connecting the mobile station and Base Station Controller (BSC). Its corresponding system interfaces are: Abis interface ZXSDR BS8802 C100 communicates with BSC through the Abis interface.

  • Page 13: System Functions

    IP capturing, public network traversing, simple transmission back path, several clock synchronization, and easy installation, etc. ZXSDR BS8802 C100 is based on all-IP platform design. A single site can support three carriers and one pseudo pilot maximally, including one 1x carrier, two DO carriers, and one 1x pseudo pilot.

  • Page 14: Table 1-1 Zxsdr Bs8802 C100 Functions

    It is applicable to small-capacity indoor scenarios, and can be mounted on the wall, pole or ceiling, etc. Table 1-1 shows the main functions provided by ZXSDR BS8802 C100. Table 1-1 ZXSDR BS8802 C100 Functions Function Category...

  • Page 15: System Features

    Zero footprint Since it hardly occupies any indoor space, there is no need to rent equipment room especially. To mount the ZXSDR BS8802 C100 on the wall, ceiling or pole can greatly reduce the fee on renting and coordination. Low requirements on power supply SJ-20110329145303-001|2011–10–25 (R1.1)

  • Page 16: External Interfaces

    For a building with several ZXSDR BS8802 C100 devices, only one GPS/RGPS needs to be installed. Adopt the power splitter or one ZXSDR BS8802 C100 device as main server, which then distributes clock to other ZXSDR BS8802 C100 devices. It is simple in installation and saves GPS\RGPS, feeder cable, and costs.

  • Page 17: Standards Complied

    12–13V DC DC input 1.7 Standards Complied ZXSDR BS8802 C100 complies with the following standards: 3GPP2 C.S0063-A, cdma2000 High Rate Packet Data Supplemental Services 3GPP2 C.S0063-0, cdma2000 High Rate Packet Data Supplemental Services 3GPP2 A.S0008-A.Interoperability Specification (IOS) for High Rate Packet Data...
  • Page 18 ZXSDR BS8802 C100 User Guide TIA/EIA/IS-95-A, Mobile Station-Base Station Compatibility Standard for Dual-Mode Wideband Spread Spectrum Cellular Systems. ANSI J-STD-008, Personal Station-Base Station Compatibility Requirement for 1.8 to 2.0 GHz Code Division Multiple Access (CDMA) Personal Communications System, 1996. TIA/EIA/TSB-58, Administration Parameter Value Assignments for TIA/EIA Wideband Spread Spectrum Standards, 1995.

  • Page 19: Chapter 2 System Structure

    As a highly integrated ultra-small base station, ZXSDR BS8802 C100 integrates the radio frequency part, baseband section, power section, and control section to achieve the functions of the whole base station. ZXSDR BS8802 C100 is featured by high integration and small size. The product is forward-looking and competitive. The system diagram is...

  • Page 20: Pra Structure

    The external transmitting and receiving antenna consists of two independent RF antennae. 2.2 PRA Structure PRA, as the core unit of ZXSDR BS8802 C100, consists of radio frequency unit, baseband unit, control unit, clock unit, and power unit. Figure 2-2 shows the PRA structure of ZXSDR BS8802 C100.

  • Page 21: Signal Processing Flow

    Power Provides system power distribution. 2.3 Signal Processing Flow The internal signal processing flow of ZXSDR BS8802 C100 is as below: Forward link processing The business data from BSC enters the baseband unit through the control unit, and then for CDMA modulation and intermediate frequency processing. After the power amplification of TX unit RF link, it is sent to the antenna for transmission.
  • Page 22 ZXSDR BS8802 C100 User Guide This page intentionally left blank. SJ-20110329145303-001|2011–10–25 (R1.1) ZTE Proprietary and Confidential...

  • Page 23: Chapter 3 Indices

    Dimension: 260 mm ×180 mm ×58 mm (L×W×H) Weight: less than 2 Kg (standard, excluding power adapter and installation kits) 3.2 Capacity Indices ZXSDR BS8802 C100 capacity indices is shown as Table 3-1. Table 3-1 ZXSDR BS8802 C100 Capacity Indices...

  • Page 24: Power Indices

    Noise: Noise of working environment: less 65 dBA. 3.7 RF Indices RF indices of the ZXSDR BS8802 C100 comply with 3GPP2 C.S0010-C, Recommended Minimum Performance Standards for cdma2000 Spread Spectrum Base Station and 3GPP2 C.S0032-A, Recommended Minimum Performance Standards for CDMA2000 High Rate Packet Data Access Network.
  • Page 25 -15.5 dB to -14.5 dB. Pilot channel: Rho > 0.97 Wave quality of DO channels MAC channel: Rho > 0.912 DATA channel: Rho > 0.97 Radio frequency Front End SWR < 2.0 SJ-20110329145303-001|2011–10–25 (R1.1) ZTE Proprietary and Confidential...

  • Page 26: Table 3-3 1.9 Ghz Transmitter Indices

    ZXSDR BS8802 C100 User Guide Table 3-3 illustrates the 1.9 GHz transmitter indices. Table 3-3 1.9 GHz Transmitter Indices Name Index Operating band 1.9 GHz (Band Class 1) Transmitter output frequency tolerance ± 0.01 ppm Occupied channel bandwidth 1.25 MHz...
  • Page 27 3 dB, and the FER is less than 1.5%. Conducted spurious emissions and < -80 dBm, measured within the BTS receive band radiated spurious emissions < -60 dBm, measured within the BTS transmit band Radio frequency Front End SWR < 2.0 SJ-20110329145303-001|2011–10–25 (R1.1) ZTE Proprietary and Confidential...

  • Page 28: Bts Clock Technical Parameters

    ZXSDR BS8802 C100 User Guide Table 3-5 illustrates the 1.9 GHz receiver indices. Table 3-5 1.9 GHz Receiver Indices Name Index Operating band 1.9G Hz (Band Class 1&14) Receiver sensitivity < -121 dBm When the lower limit is the receiver sensitivity and the upper Receiver dynamic range limit (noise level) equals - 55 dBm/1.23 MHz (Eb/N0 =...
  • Page 29 Chapter 3 Indices Clock system performance Frequency difference: < 0.05 ppm Phase difference: < 10 us SJ-20110329145303-001|2011–10–25 (R1.1) ZTE Proprietary and Confidential...
  • Page 30 ZXSDR BS8802 C100 User Guide This page intentionally left blank. SJ-20110329145303-001|2011–10–25 (R1.1) ZTE Proprietary and Confidential...

  • Page 31: Chapter 4 Networking

    4.1 Overview The transmission link between ZXSDR BS8802 C100 and BSC uses IP packets. Therefore, ZXSDR BS8802 C100 networking can make full use of the rich IP network resources. In this way, the investment on dedicated circuit transmission network is saved.

  • Page 32: Mobile Data Network

    Disadvantage: Few operators have their own data network. 4.4 Public Network Resource As the signals are IP-based, ZXSDR BS8802 C100 can make full use of public network resources such as the Internet to transmit signals. The networking mode is as shown in Figure 4-3.

  • Page 33: Chapter 5 Application

    Special Applications Solution..................5-3 5.1 Overview As a compact, highly effective, and quiet indoor pico cell BTS, ZXSDR BS8802 C100 is mainly used for indoor coverage. It can be fixed on wall and is harmonious with various indoor decoration styles. Moreover, its ultra low power output makes it meet the strict environment protection requirement.

  • Page 34: Enterprise Application

    ZXSDR BS8802 C100 User Guide Therefore, ZXSDR BS8802 C100 can be used as an important means for family coverage. Figure 5-2 shows the solution. Figure 5-2 Family Coverage 5.3 Enterprise Application In this solution, ZXSDR BS8802 C100 covers enterprise area with radio signals so that all employees in motion can perform communication based on various services in real time.

  • Page 35: Hot Spot And Blind Area Coverage

    ZXSDR BS8802 C100 can assist an emergency vehicle to realize a perfect coverage. In addition, as ZXSDR BS8802 C100 is flexible and convenient to handle, it can also provide perfect solution in blind areas which are difficult to be covered by common solution, for example, elevator, underground parking lot, and metro platform.
  • Page 36 ZXSDR BS8802 C100 User Guide This page intentionally left blank. SJ-20110329145303-001|2011–10–25 (R1.1) ZTE Proprietary and Confidential...

  • Page 37: Chapter 6 Hardware Installation

    Observe related equipment precautions and special safety instructions during maintenance, provided by ZTE. Some important safety instructions are discussed in this chapter. ZTE shall not bear any liabilities incurred by violation of universal safety operation requirements, or violation of safety standards for designing, manufacturing, and equipment usage.
  • Page 38 ZXSDR BS8802 C100 User Guide Safety Symbol Meaning High temperature: Surface is hot and may cause personal injury if touched. Laser: Beware of strong laser beam. Microwave: Beware of strong electromagnetic field. No smoking: Smoking is forbidden. No Flammables: No flammable materials can be stored.

  • Page 39: Safety Specifications

    Friction caused by human body activities is the root cause of electrostatic charge accumulation. Static voltage carried by a human body in a dry environment can be up to 30 kV, and can remain in there for a long time. An operator with static electricity SJ-20110329145303-001|2011–10–25 (R1.1) ZTE Proprietary and Confidential...
  • Page 40 ZXSDR BS8802 C100 User Guide may discharge electricity through a component when he/she touches the conductor and causing damage. Wear an antistatic wrist strap (the other end of wrist strap must be well grounded) before touching the equipment or holding a plug-in board, circuit board, Integrated Circuit (IC) chip or other devices, to prevent human static electricity from damaging sensitive components.
  • Page 41 Do not conduct internal maintenance or equipment debugging without prior permission. Replacing parts or changing equipment may incur extra danger, therefore, do not replace parts or change the equipment without prior permission. To ensure safety, please contact ZTE in case of any problem. SJ-20110329145303-001|2011–10–25 (R1.1) ZTE Proprietary and Confidential...

  • Page 42: Installation Preparation

    6.3.1 Pole-Mounting a ZXSDR BS8802 C100 Context The diameter of the pole used to install a ZXSDR BS8802 C100 must range from 20 mm to 110 mm. Prerequisites The operator is responsible for providing and installing poles while ZTE corporation supplies relevant components and parts for pole-mounted installation only.

  • Page 43: Figure 6-1 Fixing The Power Adapter Bracket Onto The Pole

    Chapter 6 Hardware Installation Steps 1. Make sure that the UP on the power adapter bracket of the ZXSDR BS8802 C100 faces upward. Bind the power adapter bracket onto the pole with two bar clamps, as shown in Figure 6-1.

  • Page 44: Figure 6-2 Fixing The Installing Bracket

    Figure 6-2 Fixing the Installing Bracket 1. Fixing screws 2. Installing bracket 3. Power adapter bracket 4. Embed the four hooks at the back of the ZXSDR BS8802 C100 into the four slots of the installing bracket, as shown in Figure 6-3.

  • Page 45: Figure 6-3 Hanging The Zxsdr Bs8802 C100

    Chapter 6 Hardware Installation Figure 6-3 Hanging the ZXSDR BS8802 C100 5. Use two screws to fix the ZXSDR BS8802 C100, as shown in Figure 6-4. Figure 6-4 Fixing the ZXSDR BS8802 C100 – End of Steps – Result Figure 6-5 shows the ZXSDR BS8802 C100 installed on a pole.

  • Page 46: Wall-Mounted Installation

    ZXSDR BS8802 C100 User Guide Figure 6-5 Pole-Mounted Installation 6.3.2 Wall-Mounted Installation 6.3.2.1 Wall-Mounting an Overlapped ZXSDR BS8802 C100 and Power Adapter Context If no sufficient room is available, the power adapter bracket and the installing bracket can overlap to save room, as shown in Figure 6-6.

  • Page 47: Figure 6-7 Inserting The Installing Bracket

    Figure 6-7 Inserting the Installing Bracket 1. Fixing screws 2. Installing bracket 3. Power adapter bracket 5. Insert the four hooks at the back of the ZXSDR BS8802 C100 into the four slots of the installing bracket, as shown in Figure 6-8.

  • Page 48: Figure 6-8 Hanging The Zxsdr Bs8802 C100

    ZXSDR BS8802 C100 User Guide Figure 6-8 Hanging the ZXSDR BS8802 C100 6. Use two screws to fix the ZXSDR BS8802 C100, as shown in Figure 6-9. Figure 6-9 Fixing the ZXSDR BS8802 C100 – End of Steps – 6.3.2.2 Separately Wall-Mounting the ZXSDR BS8802 C100 and Power Adapter...

  • Page 49: Figure 6-10 Separately Wall-Mounted Zxsdr Bs8802 C100 And Power Adapter

    Figure 6-11 Deciding the Installation Positions of the Installing Bracket 3. Use a percussive drill to drill Φ6X40mm holes according to the marked installation positions, and insert the expansion bolts delivered with the ZXSDR BS8802 C100 into the holes. 6-13 SJ-20110329145303-001|2011–10–25 (R1.1)

  • Page 50: Figure 6-12 Hanging The Zxsdr Bs8802 C100

    5. Fix the installing bracket on the wall with fixing screws according to its installation positions. 6. Embed the four hooks at the back of the ZXSDR BS8802 C100 into the four slots of the installing bracket, as shown in Figure 6-12.

  • Page 51: Ceiling-Mounting The Zxsdr Bs8802 C100

    Chapter 6 Hardware Installation Figure 6-13 Fixing the ZXSDR BS8802 C100 – End of Steps – 6.3.3 Ceiling-Mounting the ZXSDR BS8802 C100 Context In view of the endurable weight, the cement ceiling is chosen for ceiling installation. Figure 6-14 shows the ceiling installation mode.

  • Page 52: Figure 6-14 Ceiling Installation

    Figure 6-15 Marking Installation Hole Positions of the Auxiliary Installing Part 2. Remove the auxiliary installing part and use a percussive drill to drill three Φ6X40mm holes. Then install the expansion bolts delivered with the ZXSDR BS8802 C100 into the holes.

  • Page 53: Figure 6-16 Ceil-Mounting The Bracket

    4. Fix the ceiling-mounted bracket onto the auxiliary installing part with three screws, as shown in Figure 6-16. Figure 6-16 Ceil-Mounting the Bracket 5. Use four screws to fix the power adapter bracket at the back of the ZXSDR BS8802 C100, as shown inFigure 6-17. 6-17 SJ-20110329145303-001|2011–10–25 (R1.1) ZTE Proprietary and Confidential...

  • Page 54: Figure 6-17 Fixing The Power Adapter Bracket

    ZXSDR BS8802 C100 User Guide Figure 6-17 Fixing the Power Adapter Bracket 6. Embed the four hooks at the back of the ZXSDR BS8802 C100 into the four slots of the ceil-mounted bracket. 7. Fix the ZXSDR BS8802 C100 with two screws, as shown in Figure 6-18.

  • Page 55: Cable Installation

    Chapter 6 Hardware Installation Figure 6-18 Fixing the ZXSDR BS8802 C100 – End of Steps – 6.4 Cable Installation After installing the ZXSDR BS8802 C100 chassis, connect the cables. The cables to be connected are as follows: Ethernet cable Power cable GPS cable 6.5 GPS Antenna Feeder System Installation...

  • Page 56: Figure 6-19 U-Shaped Clamp Installation

    ZXSDR BS8802 C100 User Guide It is recommended to have a pole with a diameter between 30 mm ~ 60 mm (48 mm is recommended). The antenna should not be installed during rain and heavy wind. The pole binding with GPS antenna connected to GND is required.

  • Page 57: Figure 6-20 Gps Antenna Vertical Installation

    U-shape clamp with Hole 1 and Hole 3, or Hole 4 and Hole 6 on the installation support. Then cover a spring wash and flat washer respectively on these holes and fasten them with M6 screws, as shown in Figure 6-22. 6-21 SJ-20110329145303-001|2011–10–25 (R1.1) ZTE Proprietary and Confidential...

  • Page 58: Figure 6-21 Gps Antenna Rack Installation Support

    ZXSDR BS8802 C100 User Guide Figure 6-21 GPS Antenna Rack Installation Support • 1~6 hole position Figure 6-22 GPS Rack Installation (Horizontal Placement) 4. Fix the GPS antenna to the GPS settled clamp. Screw down the bolt (M4x14) to firmly fix the antenna.

  • Page 59: Figure 6-23 Gps Antenna Fixed Horizontally

    2. Use the design template for marking holes on the wall. Then drill holes on the wall according to the size of the expansion anchor bolts that are to be used. Figure 6-24 shows the design template. 6-23 SJ-20110329145303-001|2011–10–25 (R1.1) ZTE Proprietary and Confidential...

  • Page 60: Figure 6-24 Design Template For Marking Holes

    ZXSDR BS8802 C100 User Guide Figure 6-24 Design Template for Marking Holes 3. Insert the expansion bolts, and hammer them to fix properly. 4. Install the GPS antenna rack to the corresponding bolt position. 5. Insert a spring washer and flat washer onto expansion bolts and use the M6 nut to fix the rack on the wall firmly.

  • Page 61: Gps Feeder Cable Selection Principle

    3. If 150 m the feeder length ≤ 300 m, then select an 1/2" feeder cable + 7/8" feeder cable +1/2" feeder cable. 4. If the feeder length is more than 300 m, contact the local representative office of ZTE Corporation.
  • Page 62 ZXSDR BS8802 C100 User Guide This page intentionally left blank. 6-26 SJ-20110329145303-001|2011–10–25 (R1.1) ZTE Proprietary and Confidential...
