1. POSITIONING
Install the siren to the outside of the building in a position that
is clearly visible and at a height which is relatively inaccessible
to an intruder.
The siren is designed to work on any aspect wall, however for optimum performance try to avoid installing on a north facing
wall or to a wall with shadows cast by other buildings, trees and roof overhangs.
For optimum radio signal reception mount the solar siren to maximum distance of one metre from any external or internal
metalwork (drainpipes, gutters, radiators, etc).
2. PCB LAYOUT
Siren Duration Setting
Volume Setting
Power On/Off
Rechargeable 3.7V
1800mAh Lithium Battery
3. JUMPER SETUP
Volume Setting
Siren Duration
Setting
ERA Home Security Ltd
Valiant Way, Wolverhampton,
West Midlands, WV9 5GB.
Email: support@erahomesecurity.com
Solar Charged Siren
9V
Rear Cover
Start-up
Battery
Tamper Socket
Inner Tamper Switch
Learn Button
Status LED Indicator
Alarm LED Indicators
(Default)
High
Mute Low
5Min
2Min 30s
INSTALLATION
MANUAL
KIT CONTENT
Solar Siren x 1
3.7V/1800mAh Rechargeable Lithium Battery x 1
9V Alkaline Battery x 1
Fixing Pack and Installation Manual
High
Mute Low
5Min
2Min 30s
Model: ESS260R
Rear
Anti-tamper
Switch
Sirens
High
Mute Low
(Default)
5Min
2Min 30s
Advertisement
Summary of Contents for Addmore ESS260R
- Page 1 INSTALLATION MANUAL Solar Charged Siren Model: ESS260R 1. POSITIONING KIT CONTENT Solar Siren x 1 3.7V/1800mAh Rechargeable Lithium Battery x 1 Install the siren to the outside of the building in a position that 9V Alkaline Battery x 1 is clearly visible and at a height which is relatively inaccessible Fixing Pack and Installation Manual to an intruder.
- Page 2 4. USAGE Please connect the 9V Battery and press the power on/off button. Please note: after charging the battery for 12-24 hours, please remove the 9V battery. When installed as part of an ERA alarm system, the siren must be registered to the control panel only. Connecting to a Control Panel Press the learn button on the solar siren (0.5 seconds), the The siren arms 15 seconds after the control panel -...
- Page 3 6. JAMMING DETECTION Jamming detection will activate if the siren receives a constant signal for 30 seconds or 3 lots of 10 seconds within a 5 minute period. If detected, the siren will emit 10 seconds of short beeps, if the signal is still detected, a full alarm condition will occur. We recommend that you wait up to 30 days before activating the jamming detection feature to allow time for you to become familiar with the operation of your alarm system.
