Summary of Contents for JOSEF DAVIDSSONS JD 27
- Page 1 JD 27/JD 227 Installation and Maintenance Manual...
-
Page 2: Table Of Contents
Technical facts What is included in the range JD 27/JD 227 wood burning range JD 27/JD 227 wood burning range dimensions and installation 7 Installation clearances 8–9 About JD 27/JD 227 10 Here is how your range works Installation and mounting... - Page 3 Congratulations on your new JD 27/JD 227! All of us at Josef Davidssons hope that, like many others around the country, you will have many happy hours in the kitchen. The JD 27/JD 227 is a fine wood stove which works equally well for cooking and for cold winter evenings.
-
Page 4: Technical Facts
Heating surface (approx. m²) 30–60 The manual contains instructions on how to mount and Weight (kg) install the JD 27 / JD 227. To ensure the function and Oven Size (WxHxD mm) 270x155x400 safety of the range, we recommend that installation be... -
Page 5: What Is Included In The Range
§15a Reading and obeying the operating DIN+ instructions/ BimschV. 1+2 Läs och följ eldningsinstruktioner i manualen Josef Davidssons Eftr. AB Jättevägen 1 333 75 REFTELE Sweden 1. Installation manual Guide to installation and maintenance of your wood 5. CE mark burning range. -
Page 6: Jd 27/Jd 227 Wood Burning Range
JD 27/JD 227 WOOD BURNING RANGE This manual contains information about installation of JD 20 and JD 227. The difference between these to models is their front. Josef Davidssons 27 Josef Davidssons 227... -
Page 7: Jd 27/Jd 227 Wood Burning Range Dimensions And Installation
JD 27/JD 227 WOOD BURNING RANGE DIMENSIONS AND INSTALLATION Here are the most important dimensions required for proper installation and optimal operation. All measurements are indicated in millimetres. 27,5 345,5 Outdoor Air Connection Ø 50mm Back view Front view Side view, rear connection... -
Page 8: Installation Clearances
Installation clearances Observe the safety clearances for installation. Lowest possible ceiling height for proper safety clearance is 2000 mm. In front of the wood stove there must be a clearance of at least 1,000 mm to flammable material. The clearances relate to installation with an insulated outlet pipe. - Page 9 Minimum distance to material above the stove: 1000mm NOTE! Cooker hood must not be above the stove due to high radiant heat Air space Lu[spalt 5-10mm Minimum distance to material above the stove: 1000mm Air space Lu[spalt 5-10mm...
-
Page 10: About Jd 27/Jd 227
This damper is used if you need General to get a little more speed on the fire when the fireplace The JD 27/JD 227 is made of heavy cast iron and the door is completely closed. firebox is lined with protective cast iron. Between the... -
Page 11: Installation And Mounting
INSTALLATION AND MOUNTING sections will reduce the draught in the chimney. The The wood stove meets the requirements for connec- maximum horizontal flue length is 500 mm, provided tion to chimneys designed for a smoke temperature of that the vertical flue length is at least 5 m. 350°C. -
Page 12: Connecting Outdoor Air To The Wood Burning Range
CONNECTING OUTDOOR AIR TO THE outdoor air to your wood stove depending on the type WOOD BURNING RANGE of house that you have. Some take air directly via the outside walls, others go down into the floor and then For optimum performance, the firebox needs around out through the foundations. -
Page 13: Replaceable Parts
REPLACEABLE PARTS HOW TO REPLACE FIREBRICK AND BACK PLATE The JD 27/JD 227 has been built for use several decades into the future, but do not forget to replace wear parts NOTE: Never unscrew the top of the stove. when necessary. Keep an eye on firebricks, grate and This will invalidate the warranty. -
Page 14: Maintenance, Sweeping The Range
First firing burn cleanly and you will get the maximum benefit from A new JD 27/JD 227 should be fired carefully the first the stove and the wood. Clean combustion will prevent few times. Then the heat-resistant paint will last longer. -
Page 15: Problem Solving
FIRING PROBLEMS AND SOLUTIONS Poor draught • The connection to the chimney stack has not been sealed properly. Ask the sweep to check that the joint between the stove and the chimney is completely tight. • The flue is sooted up. Clean the flue and firebox. •... -
Page 16: Warranty Certificate
The warranty applies from the date of delivery to the customer. Josef Davidssons Eftr AB accepts no liability for removal and installation costs for replacing a stove. Josef Davidssons Eftr AB accepts no liability for costs arising from downtime or other direct or indirect costs and damages. - Page 20 CUSTOMER SERVICE AND CONTACT DETAILS Our Customer Service offers you personal help and answers to your questions. Contact us by phone or email. Josef Davidssons, Jättevägen 1, 333 75 Reftele, SWEDEN Phone: +46 371 – 200 01 info@josefdavidssons.se josefdavidssons.se/en...
