Summary of Contents for delviro energy Zip Cloud Flush Mount
- Page 1 ZIP CLOUD FLUSH MOUNT INSTALLATION MANUAL www.delviro.com info@delviro.com 1.877.502.3434...
-
Page 2: General Instructions
Restricted Access Area. To prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal or other sharp objects. delviro energy 94 Brockport Drive, Toronto, Ontario M9W 7J8 info@delviro.com | 1.877.502.3434... -
Page 3: Installation Instructions
INSTALLATION Zip Cloud Flush Mount Installation Instructions Steps 1. Disconnect the electrical power on the electrical panel prior to installing the zip cloud fixture. 2. Remove the existing light fixture (if existing). The only thing left on the ceiling should be the junction box with existing AC wire conductors and ground wire (Fig. - Page 4 INSTALLATION Zip Cloud Flush Mount Installation Instructions 5. Remove the 3 black head screws in the upper part (Fig. 3) and also in the lower part (Fig. 4). There are nylon washers which help to prevent electrical shorting of the metal screw head with the metal board. Ensure one has removed 6 black head screws and nylon washers in Fig.
- Page 5 INSTALLATION Zip Cloud Flush Mount Installation Instructions 7. Find the orange luminaire disconnect (Fig. 9) and remove (disconnect) the male portion. Now set the LED panel upside down on a piece of cardboard and ensure the board does not get scratched by anything. The female portion should be left in the fixture.
- Page 6 INSTALLATION Zip Cloud Flush Mount Installation Instructions 11. Take note of the red lines on the mounting angles (Fig. 11). Use the lines as a guide when placing the LED half moon plates back into the fixture. First connect the orange luminaire disconnect together - should like like Fig. 9.
