Summary of Contents for Mega Slam Hoops Pro Gym 72
- Page 7 Wall Frame Attachment STEP #1 Wall hanging location is the responsibility of the customer and/or installer. It is the responsibility of the customer and/or installer to determine how many of the frame’s 12 mounting holes must be used to safely secure the wall mount goal for play.
- Page 8 Lower Brackets STEP #3 Attach the (2) lower brackets to the frame assembly using the following: Bolt “B” - 12mm x 1.5” (2) “J” - 12mm steel washer (4) “I” - 12mm hex nut (2) Do not overtighten as this is a pivot point of the system.
- Page 9 Height Actuator & Height STEP #6 Indicator to Bracket Assembly Attach the height actuator & height indicator to the upper bracket assembly using the following. Bolt “A” - 16mm x 10.75” (1) “F” - 16mm steel washer (2) “E” - 16mm hex nut (1) Height Indicator (1) Sleeve is inserted through the actuator, and bolt D slides through the sleeve.
- Page 10 Rim Attachment STEP #9 Attach the rim to the backboard using the following: Bolt “3” - 10mm carriage bolt (4) “4” - 10mm steel washer (4) “1” - 10mm flange nut (4) Make sure rim is level before tightening. Rim Plate Attachment STEP #10 Attach the rim plate to the rim using the following:...
