- Page 1 Your Global Automation Partner TX200 HMI/PLC Series Operating instructions...
- Page 2 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
-
Page 3: Table Of Contents
Table of Contents About this Document Target Groups Explanation of Symbols Used Other Documents Feedback about these Instructions Product Overview Product Identification Type Code List of Available Devices Standards and Approvals Special Instruction for Use Technical Specifications Technical Data Environmental Conditions/Protection Class Electromagnetic Compatibility (EMC)/Durability Dimensions 4.4.1... - Page 4 Unpacking and Packing the Device Appendix: Accessories 13.1 Mounting Material/Power Supply Connector 13.2 USB/SD Accessory Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
-
Page 5: About This Document
This symbol denotes actions that the user must carry out. ➤ ➤ RESULTS OF ACTION This symbol denotes relevant results of actions. ➥ ➤ Other Documents The following additional documents are available online at www.turck.com ■ Data sheet ■ Installation guide ■ CAD data 2018/09... -
Page 6: Feedback About These Instructions
Product model name 100002080 Product part number 1832 Year/week of production AA… Serial number number V… Internal version ID of the product Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 7: Type Code
Type Code TX 2 07 – P3 CV 01 Produktfamilie Serie Bildschirmdiagonale Produktfamilie Serie Größe Turck HMI/PLC TX200 Serie 7" Visualisierung Kommunikation Visualisierung Kommunikation 00 ohne SPS Funktionalität XX ohne Visualisierungsfunktionalität NN ohne Kommunikation P3 CODESYS V3 Runtime CV CODEYS V3 TargetVisu Runtime... -
Page 8: Special Instruction For Use
For applications requiring compliance with EN 61131-2 and specifically in reference to 10 ms voltage dips, the minimum power supply voltage is 18 VDC. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 9: Environmental Conditions/Protection Class
Environmental Conditions/Protection Class Environmental conditions Operating temperature (surrounding air temperature) -0…+50 °C (vertical installation) EN 60068-2-14 Storage temperature -20…+70 °C EN 60068-2-1 EN 60068-2-2 EN 60068-2-14 Operating and storage humidity 5…85 % RH non-condensing EN 60068-2-30 Vibrations 5…9 Hz, 7 mm EN 60068-2-6 9…150 Hz, 1 g Shock... - Page 10 25 °C). NOTE Extended use in environments where the surrounding air temperature is 40 °C or higher may degrade backlight quality/reliability/durability. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com...
-
Page 11: Dimensions
Dimensions 4.4.1 TX207 Fig.2: Dimensions TX207 Model TX207 176 mm/6.90” 136 mm/5.35” 29 mm/1.14” 147 mm/5.79” 187 mm/7.36” 5 mm/0.19” 2018/09... -
Page 12: Installing The Hmi
Thickness of the case on which the equipment is mounted: 1,5 mm to 6 mm ū Max. surface roughness where the gasket is applied: ≤ 120 µm Fig.3: HMI TX200 – Mounting Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 13: Mounting Of The Hmi
Mounting of the HMI NOTE For all installation notes, please refer to the Installation Guide provided with the product. Place the fixing brackets contained in the fixing kit as follows: ➤ ➤ Fig.4: Mouting the fixing brackets Screw each fixing screw until the bezel corners get in contact with the HMI. ➤... -
Page 14: Connecting
Ethernet port 0 (10/100/1000 Mbit) Ethernet port 1 (10/100 Mbit) RS485 + CAN port configuration (DIP switches) RS485 + CAN port configuration (DIP switches) Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 15: Serial Interfaces/Can Interface
Serial Interfaces/CAN Interface 6.1.1 RS232 (X4) Fig.6: RS232 interface RS232 COM 1 COM 4 6.1.2 RS485/CAN (X2 and X3) Fig.7: RS485/CAN interface RS485 Port n.c. CAN 0 Terminating resistor CAN-H CAN-L Terminating resistor COM 2 Terminating resistor n.c. Terminating resistor Y (TX+) Z (TX-) A (RX+) -
Page 16: Rs485 (Can Port Configuration - Dip Switches S1 And S2)
FAT, FAT32 Max. size Limited by the FAT32 specification ≤ 4 GB for one single file ≤ 32 GB in total Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 17: Connecting The Power Supply
Connecting the Power Supply The power supply terminal block is shown in the figure below. Fig.9: Power supply terminal block NOTE Ensure that the power supply has enough power capacity for the operation of the equipment. Grounding the device The unit must always be grounded to earth with A minimum of 1.5mm². Grounding helps to limit the effects of noise due to electromagnetic interference on the control system. -
Page 18: Battery
When the battery is fully charged, it ensures a period of 3 months of data back-up at 25 °C. NOTE Dispose of batteries according to local regulations. Fig.11: Battery position TX207 Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 19: Special Instruction For Use
CODESYS (≥ V 3.5.12.0) and the package “TXxxx HMI/PLC series” for the HMI/PLCs have to be installed on a PC computer running Microsoft Windows. The CODESYS software as well as the CODESYS package for the HMI/PLCs can be downloaded from www.turck.com. 10.2 Programming with TX VisuPro For programming the HMI/PLCs with TX VisuPro, the software tool has to be installed on a PC computer running Microsoft Windows. -
Page 20: Adapting The System Settings
Mode includes all options available in User Mode and additionally includes commands dedicated to system upgrade and recovery not available when running in User Mode. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 21: Access The System Settings In User Mode
11.1 Access the System Settings in User Mode NOTICE! System modification during operation Undefined machine states due to device restart or loss of functionality! Do not modify the system/network settings during operation. ➤ ➤ Always stop the machine and disconnect the HMI when modifying the system ➤... -
Page 22: Unpacking And Packing The Device
Standard user has some limitations. Unpacking and Packing the Device Fig.13: Unpacking TX104/TX107 To repack the unit, please follow the instructions backwards. Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com... -
Page 23: Appendix: Accessories
USB 2.0 EXTENSION USB 2.0 extension cable, male (A) to female (A), with active ACTIVE 5M repeater, 5 meters NOTE Further accessories like field bus nodes, bus and supply cables, junction boxes, power supplies etc. can be found on www.turck.com. 2018/09... - Page 24 30 subsidiaries and over 60 representations worldwide! 100002667 | 2018/09 *100002667* www.turck.com...
