- Page 1 Extract of SVC-17-0021_EN-REV1-0 - PRE-Installation 2012-10-12 eGate® Hot Runner System Instruction Manual / Installation Guide Company Products Technology Application SVC-17-0021_EN-Rev1.0 10 / 2012...
- Page 2 Dear customers, We would like to take this opportunity to thank you for your decision to deploy a Synventive eGate® Controller. We are proud to provide you with a high quality standard in pin electronic actuator controller systems. If you have any questions on the applications and the product as such, do not hesitate and contact us by phone or personally.
-
Page 3: Safety Instructions
1.2.1 Use compatible with the intended Purpose ● The goal of the eGate® Controller System for Hot Runners is to carefully transport the melt with electrically controlled open/close and motion/position profile from the plastification unit to the cavity with an optimum distribution concept. - Page 4 The following safety instructions and symbols and operating advice are used in this manual. They are highlighted by the respective word. The described measures are used to prevent injuries and avoid damage to the eGate® Controller System and must be followed.
-
Page 5: Warning Symbols
Warning of overhead Warning of fork lift Warning of falling load trucks operating objects Synventive Molding Solutions eGate® Instruction Manual SVC-17-0021_EN-Rev1.0 Current version at www.synventive.com - 5 - © 2012 All rights reserved Master Language is English Errors and omissions excepted... -
Page 6: Electrical Symbol
EN ISO 12100 -1:2003/A1:2009, EN ISO 12100-2:2003/A1:2009, EN 60204-1:2006, EN 61000-6-4:2007 ● (Pending Safety Approval) eGate® Controller System is CE approved according: EN55022 : 1994 A1 :1995 / A2 :1998, EN 550011:2007, EN55024.: 1998, EN61000-4-2:1993, EN61000-4-3:1996, EN61000-4-4:1995, EN61000-4-5:1995, EN61000-4-6:1996, EN61000-4-11:1994, EN61000-6-2:2005, ENV50140:1993 Synventive Molding Solutions eGate®... -
Page 7: General Safety Instructions
Safety Instructions General Safety Instructions All safety instructions shall be carefully studied before the operation of the Synventive Hot Runner System is initiated. When working with the Hot Runner System, all safety instructions contained here in must be followed. Noncompliance with safety notes and instructions could result in serious injuries. - Page 8 Clean all connectors with a spray-type commercial electrical contact cleaner / degreaser and allow them to dry fully before reconnecting. All Synventive Hot Runner Systems shall be fitted with a temperature controller to provide separate temperature adjustment for each heating zone; the controller shall have the Soft-Start function for gradual heat-up.
-
Page 9: Pre-Installation
Failure to comply with the instructions may cause serious injury. ● All safety instructions shall be carefully studied before the operation of the Synventive eGate® Controller system is launched. The eGate® contains static sensitive components that can be damaged by incorrect handling. It is expected these products will be protected from hazardous or conductive materials and/or environments that could cause harm to the unit by damaging components or causing electrical shorts. - Page 10 “Off” position via the rear Power Switch. Before connecting or disconnecting any cables switch “Off” the rear Power switch to the unit; Cables in the eGate® system and the injection mold interfaces may still be energized. Failure to do so may lead to damage of the eGate® system or injury to personnel.
- Page 11 Mandatory Before connecting or disconnecting any cables switch “Off” the rear Power switch Safety to the unit; Cables in the eGate® system and the injection mold interfaces may still instructions be energized. Failure to do so may lead to damage of the eGate® system.
-
Page 12: Grounding Check
2.1.4 eGate® Controller Interface Required Parts For the eGate® Controller system to run correctly and safely with an Injection Molding Machine (IMM), status and control signals are needed for both systems to communicate. This document describes what is needed and the wiring instruction to connect the eGate®... - Page 13 The standard L-com cable with a D-sub connector and exposed wires on the other end is used to connect the face place to the relays inside the injection molding machine. The standard L-com cable is supplied as part of the eGate® Controller Interface Kit (part number ELAIMMCK03). Doc004407.png Dry Contact Relays (Not Supplied by Synventive) You need to supply up to 10 dry contact relays.
- Page 14 2.2.1 Step 1) Install the eGate® Face Plate Connector 1) Determine the best place to drill the slot shown on the right. Make sure to select a place that is close to where the eGate® controller will be placed. NOTICE The cable length from the interface to the eGate®...
-
Page 15: Step 3) Wiring Instructions
IMM Signals (1->8) below. The dry contacts for the eGate signals to the press – Error and Injection Inhibit – are to be wired as shown on Figure Doc004413/14.png dry contact relay wiring for error and injection inhibit (9 and 10) below. - Page 16 Extract of SVC-17-0021_EN-REV1-0 - PRE-Installation 2012-10-12 Service and Maintenance / Pre-Installation 2.2.3.1 Dry Contact Relay Wiring for Press Signals (1->8) Signal from press Signal to eGate® interface Ground from press Signal to press Doc004411.png Signal to eGate® interface Signal from IMM 24 V from eGate®...
- Page 17 Extract of SVC-17-0021_EN-REV1-0 - PRE-Installation 2012-10-12 Service and Maintenance / Pre-Installation 2.2.3.3 Required Signals Wiring Schematics and Wire Color Codes Wiring from eGate® Interface Signals from IMM Release 1.0 N/O = Normally Opened (1) Brown Mold Clamped Relay 24V 500mA...
-
Page 18: Testing The Interface
Testing the Interface To test the wiring is correct and all of the signals are working the eGate® Interface Tester which can be requested from Synventive (part number ELAIMMTB01). The Interface Tester allows full check of the interface prior of the installation of the eGate system. -
Page 19: Appendix 1 Detailed Wiring Interface Schematics
Screw Position Ana Com (Blue / White) Screw Forward 3 Press +24 VDC (Purple / White) eGate Ground (Brown / White) eGate System Alarm (Black / White) System Restart Sys Alarm Rly Com (Orange / White) eGate Not Ready (Green / White) .75 A Fuse... -
Page 20: Appendix 2 Screw Position Sensor Interface
The screw position sensors are analog transducers and must provide analog output signal voltages from 0 -10 VDC. The sensors should have an accuracy of about +/- 0.28 to +/- 0.15% FS. The eGate® Controller’s analog inputs are high impedance > 100 kOhms and should not pose a loading issue in typical user applications.
