ETI NETCOM ASM-1 Quick Reference Manual

PACKING LIST
QTY. PART NO. DESCRIPTION
1 23658 ASM–1 Smart Manifold, AC Power Supply
1 24303 Documentation CD ROM, ADH NETCOM and ASM–1 Smart Manifold
1 23681 ASM–1 Smart Manifold Installation Sheet (this document)
1 23678 ASM–1 Accessory Kit
2 18198 1/8" NPT to 1/4" Barbed Brass Fitting
2 23428 1/8" NPT to 3/8" Barbed Brass Fitting
4 23245 Mounting Bracket
1 17618 Power Cord
8 11040 Rack-mounting screw (#8-32)
8 10641 #8 Split Washer
CONNECTIONS
Ports are factory configured as: Port 1 – Input; Ports 3 and
4 – Outputs; Port 8 – Bleed Valve. Ports 2, 5, 6, and 7 are
factory configured as Unused. Settings may be changed,
but use these initially.
1. For the dehydrator, connect a 1/8" NPT to 3/8" fitting
to Input Port 1 using Teflon thread tape.
2. For the equipment lines, connect fittings as needed to
Output Ports 3 and 4 using Teflon thread tape. Refer to
Instruction Manual for more information.
3. Connect required data and alarm relay ports. RS-422
and RS-232 ports may require configuration changes
via the web interface. See Instruction Manual for
more information.
South Bend, Indiana USA | networketi.com
NETCOM
SMART MANIFOLD WITH AC POWER SUPPLY
MODEL ASM-1
®
4. Connect AC power cord. System can be connected
to 100 VAC – 240 VAC power without requiring any
configuration change.
5. Configure Smart Manifold as described on this
Installation Sheet, then shut off Manifold power.
6. Configure system dehydrator(s) as needed. Turn Smart
Manifold power back on.
ASM-1 INSTALLATION GUIDE | PART NO. 23681 REV A
