E- Mic In F- Optical Out Connecting to the speaker, headphone or mic 1. Connect the speaker, headphone or mic to your EVGA Nu Audio. 2. Reconnect your power cord to the PC. Driver Installation With the hardware installed, it is now time to install the audio driver.
OP-Amp Rolling A great feature of the EVGA NU Audio card is the capability for future upgrades and modification by swapping op-amps, sometimes referred to as 'OP-Amp Rolling'. For this we have provided two sockets, U613 and U564, as shown on the plain view:...
Software Installation Thank you for purchasing the EVGA NU Audio Card! This guide will walk you through where to find software for your audio card, how to install the software, and a basic walkthrough of the NU Audio software and features.
Page 5
EVGA NU Audio Software The NU Audio software offers you control over the volume, input/output ports, EQ options, RGB LED lighting, and some basic settings. A. EVGA.com Link – The EVGA tab links directly to our website at EVGA.com. B. Sound Menu – Located at the top, the Sound Menu houses the Volume and EQ menus.
Page 6
P. Sound Menu Toggle – The arrows switch between the Main Volume menu and the EQ menu. EQ Menu The EVGA NU Audio Card software features a customizable EQ menu, which allows for up to 30 profiles. Each profile allows you to label one of the six categories to sort your EQ profiles in any way, and five profiles in each category, which may be named and customized.
Page 7
EQ process itself. RGB LED Lighting The EVGA NU Audio Card features 10-Mode RGB lighting, including Audio Reactive Lighting. All lighting controls are available within the NU Audio software.
Page 8
NU Audio Card. A. The software can be installed, even if the NU Audio card is not present, so the first step is to check if the card is installed properly and the SATA power connector is connected. If you have any further issues, please contact EVGA Customer Service.
